DIMENSIONAL / PERFORMANCE DATA
Figure 7.1 - Unit Dimensions (inches)
Table 7.1 - Performance Data / Mounting Height
Model Size Voltage
240V 5.7
AMP057 j
208V 4.3
240V 9.0
AMP090
208V 6.8
j Capacity, airflow, temperature rise and throw values also correspond to low stage of AMP090
Heating Capacity Airflow
kw BTU/HR CFM
19,437
425
14,578
30,690
550
23,018
Temp Rise Heat Throw
m 3 hr
°F °C ft
42.3 23.5
722 20
31.8 17.6
51.7 28.7
934 26
38.8 21.5
2-529.0
Min. Height Suggested
(USA/Canada) Max. Height
m ft m ft
6/8 1.8/2.4 8
6.1
6/8 1.8/2.4 8
6/8 1.8/2.4 10
7.9
6/8 1.8/2.4 10
Weight
m lbs
2.4
48
2.4
3
52
3
7
