Obtain power cords

WARNING
Do not attempt to modify or use AC power cords that are not the exact
type required.
Because power cords are not supplied for the server power supplies, you must obtain power cords
that meet the following criteria:
•
The cord must be rated for the available AC voltage and have a current rating that is at least
125% of the current rating of the server.
•
The connector that plugs into the wall outlet must be a grounding-type plug designed for use in
your region. It must have certification marks showing certification by an agency acceptable in
your region.
•
The connector that plugs into the AC receptacle on the server power supply must be an
IEC 320, sheet C13, type female connector.
• The cord must be less than 4.5 meters (14.76 feet) long, and it must be flexible <HAR>
(harmonized) or VDE certified cordage to comply with the server safety certifications.

Turn on video monitor and server

WARNING
The push-button on/off power switch on the front panel of the server
does not turn off the AC power. To remove AC power from the server,
you must unplug each power cord from each power supply or wall
outlet.
1. Make sure all external devices, such as a video monitor, printer, keyboard, and mouse
(optional) have been connected.
2. Remove drive protection cards (if present) from the removable media drives.
3. Turn on your video monitor and printer.
4. For each power supply present in the server, plug the female end of each power cord into the
power supply input receptacle on the back of the chassis (your server may be configured with
either three or four power supplies).
NOTE
To plug in a power cord, push and hold the spring-loaded safety interlock
mechanism toward the edge of the power supply. Then plug the power cord
into the exposed inlet receptacle, and release the safety interlock.
5. For each power supply present in the server, plug the power cord into a properly grounded
power outlet.
