- Page 1 Owner’s Manual Compact Range 2024 Series 5 www.icoolsport.com | support@icoolsport.com...
- Page 3 Table of contents Your iCoolSport Compact Quick Set Up Getting Started Safety Technical Support...
- Page 4 Your iCoolSport Compact...
-
Page 5: Remote Control
Superfast Cooling HD Touch Screen www.icoolsport.com | support@icoolsport.com All models feature as standard a big bright & great looking The Compact Series 5 range are the latest version our the HD touch screen, the industries biggest, clearest and best. - Page 6 Identify your Compact This manual is intended to help you get started with your Compact Range machineand to know your device’s features, specifications and operating instructions. First let’s identify your product. Below are some guidelines to help you determine your exact model series and your machine’s voltage. Identify your model Included with your Compact* Your device’s model name is printed on the front cover of your...
- Page 7 The high quality Quick Connect water fittings we supply are a patented design available only from one specailist manufacturer. Therefore, colours in your kit may vary. fittings may be replaced by LIGHT GREEN fittings for example. Front View Left Side View Compact Series 4 COOL Product Model...
-
Page 8: Specifications
Specifications MODEL COOL COOL Dual Temp Power Line Voltage Manufactured in 110V or 220V Manufactured in 110V or 220V Cooling / Heating 5200 Watts / Chill Only 5200 Watts / 5400 Watts Running Power 220V (& Max.) 5 Amps (12 Amps) 6.5 Amps (13 Amps) Running Power 110V (&... - Page 9 XP Dual Temp ICEMAN Manufactured in either 110V or 220V Manufactured in either 110V or 220V Manufactured in either 110V or 220V 7200 Watts / Chill Only 7200 Watts / 7100 Watts 7800 Watts / Chill Only 7.5 Amps (14 Amps) 7.5 Amps (14 Amps) 7.5 Amps (14 Amps) 14 Amps (28 Amps)
- Page 10 Quick Set up...
-
Page 11: Prepare For Set Up
Contact support@icoolsport.com if your machine fails to chill properly after an extreme heat event. On very hot climates over 45ºC, it may not be possible to run Water Condensation the system at full power due to the excessive heat. -
Page 12: Assembly Connection
Compact chillers have quick connect fittings that are compatible with the same fittings on all iCoolSport pools Range. In this case you only need what is supplied in your kit. If you wish to connect your machine to your own pool or bath tub we can supply special plumbing devices that can add the convenience of these same quick connectors to your own pool ot tub. - Page 13 To keep the pool water Using your machine as a Your own bath, spa or tub while cleaning the filter remote chiller for a MiPod If using your own bath tub, there are options to connect it to your chillers A Ball valve is included with If ordered as a MiPod quick connect hoses.
-
Page 14: Power Connection
Power Connection Next connect the chiller to the mains power. You must make absolutely sure that you do not connect your Compact machine to the wrong voltage or this will cause serious damage not covered under warranty. Please check the voltage on the name plate above the power IN socket - it is either a 220 volt model or a 110 volt model. - Page 15 3. SWITCH ON Voltage To connect the screen to your chiller, plug the DC cable to 220 Volts your screen and to a nearby power outlet, then connect the Blue Data cable to the RJ45 socket behind the screen Turn the Main Power Switch to ON to start the unit. and the other end to the Ethernet socket in your chiller as shown in the diagrams below.
- Page 16 The iCoolSport User Interface...
-
Page 18: User Interface
User Interface The iCoolSport user interface is the most advanced in the industry. Completely redesigned to provide completely automatic start up and run operations, water flow correction and multiple safety features plus intelligent power management. 1. Start Up & Software Loading 2. - Page 19 “ Water flow started”. vibration and a low motor sound should be heard. If you don't hear this please contact support@icoolsport.com Starting System: after a few seconds, the refrigeration compressor motor will start. This sound is easily recognisable.
-
Page 20: Basic Settings
Basic Settings The new user interface looks and works like a smartphone. You can change settings for temperature units, speaker volume and energy saving by clicking on the menu icon. THE HOME SCREEN LAYOUT Light/Dark mode The Main Operating Screen (or Home Screen) allows you to see the current temperature of your pool, machine and the You can change the display mode pre-selected temperature. - Page 21 SYSTEM INFOMATION To LOCK your touch screen. All information about your machine is available in the Menu. You can prevent others from using your machine or making changes by locking your screen with a 4-digit passcode. Go to MENU icon (top left) and select INFO To set a passcode, go to the MENU icon (top left) and select The screen will show..
- Page 22 WiFi Set Up You can connect your machine to your local WiFi network to remotely operate it from any smartphone, tablet or computer connected to the same network. Step 1 Step 3 Choose WiFi from the MAIN MENU of your iCool. Next, click When the scan is complete, a list of available WiFi Networks WiFi WIZARD.
- Page 23 Local network remote operation. Step 7 A GREEN notification will appear when the connection is successful. Open any web browser on your smartphone, tablet or computer and type this IP Address into your browser bar and press ENTER. You should now see your iCool’s screen on your device and you can now operate all the functions of your iCool from this device as long as they are both connected to the same WiFi network.
- Page 24 Safety...
-
Page 25: Important Safety Warnings
Particular care must be taken on all surfaces on or near Please be sure all users of the pools are familiar with baths. iCoolsport can not accept any liability for injury this function. Make sure all operators and users know or death from users slippingon wet surfaces in and where the ORANGE button is to remove all power. - Page 26 BUILT-IN SAFETY SYSTEMS ADVICE ABOUT POOL CHEMICALS Your iCool has many essential safety features to The high quality water pump provided with your protect against such things as: machine is especially designed for the purpose. The pumps we provide are resistant to chlorine and salt water at normal concentrations, the use of any A loss of water flow chemicals should be kept within the range normally...
-
Page 27: Maintenance
Maintenance We recommended cleaning your Compact machine often to avoid dust and debris building up and reducing performance or causing other problems. For best results, use a microfibre cloths and mild cleaners to clean your unit. Operation Operation in Very Cold Weather The ideal operation temperature is indoors between 10 &... -
Page 28: Technical Support
Technical Support... - Page 30 Water Flow Issues To protect the pump and the titanium heat exchanger tanks, the system will not allow operation unless the water flows correctly. If water does not flow smoothly or if there is air trapped in the system for more than 2 minutes, the safety system will first attempt to fix it by causing the pump to surge a few times, but if that fails it will direct a shut down for safety.
- Page 31 If none of the above works, please email the iCool Support the temperature at which the water freezes. team with pictures of your entire set up, your pool, your water level and all hoses connected so we can help solve your issue quickly for you support@icoolsport.com.
-
Page 32: Operating Issues
OFF and ON first to see if that solves the issue. amount needed is marked on a certificate fixed to the heat If the issue persists, please contact iCool Support. exchanger tank inside the machine. support@icoolsport.com Most Compact machines require 350 grams of R290. -
Page 33: Screen Freeze
If you’re operating via the optional 13” Remote Touch screen and the screen does not connect to your chiller, make sure support@icoolsport.com that the data cable is correctly plugged to the chiller and to the back of the screen. You can also try turning the unit OFF and ON again and waiting for 30 seconds. -
Page 34: Obtaining Warranty Service
Technical Support Before contacting iCoolsport, please make sure you have read through the entire manual. Most issues can usually be fixed via email, alternatively, we can offer a factory repair or we can assist in arranging for a local repair agent to do repair works. We will always do our best to get back to you on the same day, however please allow for time zone differences. - Page 35 Support Request Form iCool-certified Repairs Customer Name/Last Name: To get iCool-certified repairs from our iCool Head Office in QLD, Australia, simply send your product to us and we’ll assess the issue for you. Phone Number: Cost All freight costs will be at your charge (except return freight for Email address: approved warranty claims).
- Page 36 125 Olympic Circuit Southport Queensland Australia 4215 Tel: +61 7 5591 7646 info@icoolsport.com...
