- Page 1 Owner’s Manual Turbo Range Series 5 www.icoolsport.com | support@icoolsport.com...
- Page 3 Table of contents Your Turbo Installation Set Up Get Started Safety Procedures Technical Support...
- Page 4 Your Turbo...
- Page 5 What’s new in Series 5 The Turbo machine is designed to provide both cooling and heating for large recovery pools & spa baths. It is now the most popular machine in the world for this purpose. A large number are already operating successfully in stadiums, colleges &...
- Page 6 Identify your Turbo This manual is intended to help you get started using the Turbo Range of cooling units. To know your device’s features, specifications and operation instructions, you will first need to identify your product. Below are some guidelines to help you determine your model, your series and your serial number. Included with your Turbo Identify your model Your device’s model name is printed on your order/invoice.
- Page 7 Cabinet Cabinet is constructed from high quality marine grade aluminium to Lifting Handles prevent rust and save weight. All metal parts are coated with high grade heat cured epoxy paint to Built in strong lifting handles for ease resist extreme conditions. of placement.
- Page 8 We welcome your feedback and suggestions and we offer support for general inquiries and information for specific countries on our website at www.icoolsport.com TurboCool 2 & TurboCool 2 XP Dimensions Dimensions 241.00 mm 9.49 in...
- Page 9 Specifications TurboCool Turbo Dual Temp Turbo Hot Turbo XP Cooling Power 15,400 Watts 15,400 Watts 8,900 Watts 20,000 Watts Heating Power Chill Only 15,200 Watts Chill Only Chill Only Run (& Max.) Power 14.8 Amps (20 Amps) 14.8 Amps (20 Amps) 9 Amps (15 Amps) 17.1 Amps (20 Amps) 208-220 Volts...
- Page 10 Quick Set up...
- Page 11 Prepare for set up Outdoor Operation To make setup as smooth as possible, please follow The best location for maximum performance is outside the building in an area with good fresh ventilation. The Turbo should be protected carefully the instructions outlined below. Do not start from direct rain, hail, snow and sun.
- Page 12 Other key points Please read this manual in full before starting or commencing installation. iCool can provide as much technical support as you need to place and connect your set up. Simply contact us for more information or for any specific request regarding your set up. Water Condensation Access Limitations Please note that your unit is a very powerful chiller and...
- Page 13 Good Airflow Water Leak Testing is Essential Please ensure your Turbo is placed at a minimum distance of As your pool has been transported over distance it is 300mm on all sides away from any obstacle, wall or structure to essential that you check to make sure none of the many allow proper airflow.
- Page 14 Basic Connections Turbos can be mounted anywhere within 70 meters of your pool and can be either level with the pool or up to 12 meters above or below the pool using an option high lift pump (separate special order). Installation must be completed by a certified plumber, builder or installer and they must follow iCool’s guidelines and instructions.
- Page 15 Optional items on TR Pools with spa jets Please refere to TR Pool manual for more information Water flow direction 50mm PVC Pressure Pipes From TURBO to POOL OPTIONAL WATER FILTER 50mm PVC If no filter, connect Pressure Pipes bottom of Turbo to top of pump directly From POOL WATER...
- Page 16 Power Connection Turbos require only standard single phase power, one flow and one return water pipe and a data cable (supplied) to connect to the wall mounted remote control touch screen. The pump must also be connected to the electronic side of the Turbo and works must be completed by a certified electrician, builder or installer.
- Page 17 220volt 110volt 20 amps 40 amps 50mm PVC Pressure Pipes From TURBO to POOL OPTIONAL WATER FILTER 50mm PVC If no filter, connect Pressure Pipes bottom of Turbo to top of pump directly From POOL DATA CABLE CIRCULATION PUMP CABLE to TURBO (20 mtrs supplied) twisted pair cable...
- Page 18 Screen Connection Turbos come with a 20m data cable. For longer distance, please use STP or UTP cable for reliable connection. DATA CABLE WIRING TO CIRCUIT BOARD The blue Data cable must be wired into the bottom circuit board located inside the electronic side panel of your turbo. The blue data cable supplied is 20metres long.
- Page 19 DATA CABLE WIRING TO SCREEN The blue Data cable must be connected to the DATA - DB9 Male Connector on the screen. The screen must also be connected to the power via the DC power cable supplied. DB9 Male connector (included in screen) Connect blue data cable here RS232 RS485...
- Page 20 Pump Connection Turbos come with a QB035 Davey water circulation pump that must be wired to the circuit board. PUMP WIRING TO CIRCUIT BOARD The water circulation pump must be wired into the top circuit board located inside the electronic side panel of your turbo. 208-240V supply will output from the board to the pump.
- Page 21 Fill with water Fill pool with water and allow enough space to handle water displacement and prevent overflow when users enter the pool. Fill with a hose Drain Valve A permanent water connection is not required. Simply fill with Make sure the gate valves are open to allow correct water flow a hose to at least cover the biggest inlet or water skimmer to the Turbo machine and return to the pool.
- Page 22 Started...
- Page 23 Electrical Power Management Your iCool machine is connected to the building’s main power system by a qualified engineer during the initial installation. The installer will normally connect each Turbo to a separate combined circuit breaker and RCD safety device switch on the building’s electric power board. Your Turbo also has a built in circuit breaker and RCD safety device.
- Page 24 Please note: the TurboCool will automatically cool water down (min of 5ºC); The TurboHot will heat water up to max 45ºC; the A few seconds later, the iCoolsport logo will appear and you Turbo Dual Temp version will automatically select if it needs to will see “Starting your iCool...”.
- Page 25 The Start Up Sequence performs the following steps: The Turbo has a sophisticated computer control system that senses and manages all parameters necessary to reduce electric power consumption to the minimum possible while Introducing Air Flow: first, the main airflow fan will start to still maintaining the set temperature accurately at sporting carry away the heat from the cooling process..
- Page 26 Basic Settings The new user interface looks and works much like a smartphone. You can change all settings by clicking on the menu button of your screen. Please note: If your pool has spa massage jets, these can be started and stopped by pressing the Jets Button located on top of your pool (press once to start, press again to stop).
- Page 27 LOCK TIMER You can also lock your screen by entering a 4-digit passcode. This will limit the access to the settings of the chiller. Your iCool Turbo has a built in SESSION TIMER. Touch the blue MENU button to reveal all available options on your machine To set a passcode, go to MENU >...
- Page 28 Safety Procedures...
- Page 29 Important Safety Warnings ELECTRIC SHOCK PROTECTION POWER SUPPLY VOLTAGE LIMITATIONS iCools can only be connected to the voltage marked on the machine. They are manufactured as 208-240V All iCool machines have built-in electrical safety machines, and they are not multi-voltage. Using a residual earth leakage protection systems however it different voltage may cause severe damage.
- Page 30 Particular care must be taken on all surfaces on or near main electronics box under the smoked glass cover on baths. iCoolsport will not accept any liability for injury the right hand side of the Turbo. or death in and around the ice bath due to: 1.
- Page 31 Maintenance It is recommended to clean your Turbo often to avoid rust and dust building up and reducing performance or causing other problems. For best results, use a microfibre cloth to clean your unit. It is the pool owner’s responsibility to ensure that your pool or spa complies with your local rules. Operation Operation in Very Cold Weather You must absolutely protect the unit from rain, rust, dust, dirt,...
- Page 32 Technical Support...
- Page 34 Water Flow Issues To protect the pump and the titanium heat exchanger tanks, the system will not allow operation unless the water flows correctly. If water does not flow smoothly or if there is air trapped in the system for more than 2 minutes, the safety system will first attempt to fix it by causing the pump to surge a few times, but if that fails it will direct a shut down for safety.
- Page 35 Turbo Unable to Fix Water Flow Heat Exchange Tanks Frozen Issue Solid An explanation will appear in the middle of the screen to notify if you set the temperature below about 7ºC or 45ºF, it is you the machine has stopped. occasionally possible in certain climatic conditions for the heat exchange tanks to freeze solid.
- Page 36 Operating Issues In the unlikely event that your system shuts itself down for any reason, you must identify and correct the problem that has caused the safety system to operate before allowing anyone to use the iCool. Never restart without identifying and correcting any fault. Turbo Not Cooling or Heating Loss of refrigerant is normally only possible due to severe over heating or damage due to rough handling during transport...
- Page 37 Software Not Loading Condensation If the software doesn’t load for any reason, we recommend Please note that your unit is a very powerful chiller and turning the unit OFF and ON first to see if that solves the issue. condensation will occur inside of it. Water may leak at the If the issue persists, please contact iCool Support.
- Page 38 Technical Support Before contacting iCoolsport, please make sure you have read through the entire manual. Most issues can usually be fixed via email, alternatively, we can offer a factory repair or we can assist in arranging for a local repair agent to do repair works. We will always do our best to get back to you on the same day, however please allow up to 72 hours due to time zone differences.
- Page 39 Support Request Form iCool-certified Repairs Customer Name/Last Name: To get iCool-certified repairs from our iCool Head Office in Queensland, Australia, simply send your product to us and we’ll assess the issue for you. Phone Number: Cost All freight costs will be at your charge (except return freight for Email address: approved warranty claims).
