Lighter weight:
5Kg (10 lbs) lighter than the previous model
Smaller Size:
Height reduced by 52mm (2 inches)
All New Water
Circulation System:
A new light weight ultra compact hi power water pump small enough to operate externally
for easy cleaning and maintainance.
The new pump has a fully automatic self priming function that will automaticall try to clear
trapped air. If it can not do so after several attempts it will shut down and warn the user.
With optional low cost attachments, the new pwater pump system allows you to use your Lite
with virtually any small pool, spa or bath tub.
The new pump system operates from very safe low voltage for total safety.
WARNING:
These chemicals are very corrosive and can damage the stainless steel heat exchanger tank.
Bacteria grows much more slowly in very cold water so there is no need to use such harsh chemicals.
Half a small cup of a standard bathroom disinfectant or mouth wash will safely control bacteria.
OWNER'S MANUAL FOR iCOOL RECOVERY SYSTEMS
iCool Lite
2014 Model
OWNER'S MANUAL
New Features for 2014:
Do not use this machine with Chlorine, Bromide or Salt!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for iCoolsport iCool Lite
Summary of Contents for iCoolsport iCool Lite
- Page 1 Lite 2014 Model OWNER’S MANUAL New Features for 2014: Lighter weight: 5Kg (10 lbs) lighter than the previous model Smaller Size: Height reduced by 52mm (2 inches) All New Water Circulation System: A new light weight ultra compact hi power water pump small enough to operate externally for easy cleaning and maintainance.
- Page 2 PERFORMANCE Your iCool Lite has impressive performance for such a small system, but naturally it can not cool a pool as fast as our much larger iCools. You can expect cooling of at least 3 to 5 degrees C per hour and it may cool even faster depending your basic setup and local conditions.
-
Page 3: Important Safety Advice
As you gain experience using an ice bath system you will learn to overcome this quickly and easily. ABOUT PUMPS. Water flow through your iCool Lite is produced by a high-quality long life circulating type pump that is fitted into the lower pool connecting hose. For total safety it operates at 12 volts DC and is completely water proof. - Page 4 QUICK START GUIDE The following is a quick start guide to get your iCool up and running quickly, however you should read the entire manual to get the most out of your iCool. STEP 1 Before you fill the pool you must connect the PUMP MODULE and the 2 hoses provided to the inlet and outlet fittings on the Lite unit.
- Page 5 If the safety system is working normally, pressing the test button will cause the main power switch to shut down instantly. After this test, reset the main switch to ON to begin normal operation. OWNER’S MANUAL FOR iCOOL RECOVERY SYSTEMS All iCool Lite Models from January 2013 iCoolsport.com Page 5...
- Page 6 STEP 4 TURN ON THE MAIN POWER SWITCH YOUR SYSTEM SOFTWARE WILL BEGIN LOADING Your iCool has a full colour high-resolution touchscreen that Eliminates all switches and provides complete control over your iCool system in a user-friendly and intuitive manner. It also Provides a substantial amount of additional information to assist you.
- Page 7 IN AN EMERGENCY YOU CAN STOP ALL FUNCTIONS IMMEDIATELY BY TOUCHING THE “ALL STOP” BUTTON however, if the cabinet is hot, the fan may continue to run until the cabinet has cooled. OWNER’S MANUAL FOR iCOOL RECOVERY SYSTEMS All iCool Lite Models from January 2013 iCoolsport.com Page 7...
- Page 8 IF THE ICOOL STATUS LIGHT TURNS RED WHEN YOU START THE COOLING CYCLE. The can only occur if the water temperature in the pool is already be lower than the cooling temperature you set. In this case the iCool will automatically attempt to heat the water to match the temperature you have set. iCOOL lights to indicate activation of the heating mode.
-
Page 9: Detailed Operation
OWNER’S MANUAL FOR iCOOL RECOVERY SYSTEMS All iCool Lite Models from January 2013 iCoolsport.com Page 9... - Page 10 TEMPERATURE SETTINGS When your iCool starts up, you are offered 3 different ways to choose a water temperature setting. Whichever method you choose it eventually takes you to the main run screen. If you make no setting, the system will automatically insert 15°C.(around 59ºF) In this case you would navigate directly to the main run screen in order to access and start the...
-
Page 11: Set Countdown
This button starts the cancelled by pressing once countdown again. A red dot indicates that it is active OWNER’S MANUAL FOR iCOOL RECOVERY SYSTEMS All iCool Lite Models from January 2013 iCoolsport.com Page 11... -
Page 12: External Lighting
YOU CAN ALSO DISPLAY THE MAIN CLOCK, SHOWING THE TIME OF DAY IN FULL-SCREEN MODE IF REQUIRED BY TOUCHING THE DISPLAY CLOCK FULL 14:10 SCREEN BUTTON. TO GO BACK TO THE PREVIOUS SCREEN TOUCH THE BACK 1 BUTTON. 2:41 ExTERNAL LIGHTING THIS MODEL DOES NOT HAVE ROOM LIGHTING STEREO SOUND SYSTEM THIS MODEL DOES NOT HAVE A SOUND SYSTEM... - Page 13 To unlock the system and returned to normal, repeat the procedure. Touch and hold the iCool icon for more than 10 seconds. The lock will disappear and all functions will return to normal. OWNER’S MANUAL FOR iCOOL RECOVERY SYSTEMS All iCool Lite Models from January 2013 iCoolsport.com Page 13...
- Page 14 IF YOUR SCREEN FREEZES OR FAILS TO RESPOND As with all computers and computer controlled devices it is possible that occasionally the system could freeze due to data or software conflicts. Your iCool has 2 computers that monitor and communicate with each other.
-
Page 15: Specifications
40KG 88 Lbs DIMENSIONS H. - W. - D. in mm. 240x420x300 545x475x290 545x475x290 DIMENSIONS H. - W. - D. Inches 10x16.5x11.8 21.5x18.7x11.4 21.5x18.7x11.4 OWNER’S MANUAL FOR iCOOL RECOVERY SYSTEMS All iCool Lite Models from January 2013 iCoolsport.com Page 15... - Page 16 Thank you for choosing iCool the world’s most popular ice bath therapy and recovery systems. Published 2014 by iCool (Australia) Pty Ltd iCool HK (China) Ltd. iCool is a Regestered Trade Mark worldwide. Contact: info@icoolsport.com...
