Overlay Frame - U-Line Echelon 2175WC Installation Manual

Overlay Frame

(2175WCOL Units Only)
Frame Preparation
An overlay frame covers the door frame to give a built-in
appearance. Appropriate hardware and a copy of these
instructions will be included in the unit.
IMPORTANT
The thickness of the wood overlay frame must be 3/4".
The door frame must not weigh more than 20 lbs.
1. Create an overlay frame to the dimensions shown in
Figure 13.
3/4"
13/16"
1/8"
1/8"
Figure 13
IMPORTANT
Rear View of wood frame for right-hand hinge shown.
Use mirror image for left-hand hinges.
06/2006
2175WC/2175WCOL Wine Captain
Relief Notch for Pivot Plate
(Right Hand Hinge Shown)
Rear View
of
Wood Frame
27-3/4"
21-1/2"
23-3/4"
2. Typical routing dimensions
are shown in Figure 14.
3. Create a relief for pivot plate by cutting notch in top
corner and coinciding back corner of overlay frame.
Refer to Figure 15 for exact specifications.
13/32"
0.177" Dia. (#16 Drill)
3/8"
13/16"
Top View
30"
1/8"
13/16"
1-17/32"
7/16"
13/16"
5/16" Dia.
x 1/2" Deep
Back View
Figure 15
Route notch in top corner of overlay frame as shown (see
Top and Side Views). Top of notch is entire depth of
frame, front to back.
Width: 13/16"
Depth: 1/8"
Route notch in backside of top corner of overlay frame
(see Back and Side Views).
Width: 13/16"
Depth: 1/8"
9
®
3/4"
1-1/8"
11/16"
(Ref.)
7/16"
(Ref.)
5/32"
3/8"
Figure 14
x 11/16" Deep
3/8"
Door Bottom:
5/16" Dia. x 1/4" Deep
Chamfer 1/32" x 45°
Bottom View
13/32" 1/8"
1/32" R
1/8" R
Side View
www.U-LineService.com
1-13/16"
2-1/4"
13/32"
1/8"
3/4"
