TECHNICAL SPECIFICATION

Speedheater model 1100-04T
Made in Sweden by Speedheater System AB.
in accordance with EN 60335-1, EN 60335-2-45.
Connection
1-phase AC with earth.
Volts Watts
220-240 2200
Heating element
4 x 550 W IR-tube made of quartz glass.
Anti-overheat reset button
This machine has two protections against overheating, one on each half.
This function is to protect the machine against overheating. It will not protect the paint removal surface from overheating.
Measurements
IR-machine
Total length :
370 mm
Width : 330 mm
Height : 220 mm
Heating time on painted surface
Indoors 20-40 seconds.
Outdoors 30-90 seconds.
The heating time may vary depending on the surface and weather conditions.
Heating temperature
The temperature on a heated surface is approx. 100-200 C in normal use and according to instructions.
Heating at higher temperatures increases the risk for fire and damage to the components in the machine.
ON/OFF switch
Amps
9.2
Weight : 4.950 g
o
Connection cable
3x1.5 kvmm rubber cable
length 4 meters (13 ft).
Heat surface
L ength :
340 mm
Width : 320 mm
Batch - and ID-number
Reset-button for anti-overheat function
U-bolt
ENG 2
