ASSEMBLY INSTRUCTIONS
Quadro A Leg
Need help!
Counter Frame
Call us on
1300 527 665
Sizes:
1000x1000
1200x700
1200x1200
1400x700
1600x700
1800x700
2000x700
Tools Required:
Power screwdriver; Allen key set (provided)
2 persons required for installation
Page 1 of 8
