- Page 1 ASSEMBLY INSTRUCTIONS Quadro A Need help! Boardroom Frame Call us on 1300 527 665 Sizes: 2400 x 1200 3000 x 1200 3600 x 1200 Tools Required: Power screwdriver; Allen key set (provided) 2 persons required for installation Page 1 of 6...
-
Page 2: Need Help
Quadro A Need help! Boardroom Frame Call us on 1300 527 665 COMPONENTS Table top x2 Leg Quadro A x2 Connector frame x1 Beam x4 Plastic bracket x16 SCREWS M8x20MM CSK x8 M8x20MM Socket head x8 M6x20MM Socket head x16... - Page 3 ASSEMBLY INSTRUCTIONS Quadro A Need help! Boardroom Frame Call us on 1300 527 665 STEP 02 STEP 01 Using Allen Key provided, attach 4 plastic brackets per leg (E) Using Allen Key provided, attach M8x20MM Socket head (G)- (as per picture above) using M6x20MM (H) Socket head screw.
- Page 4 ASSEMBLY INSTRUCTIONS Quadro A Need help! Boardroom Frame Call us on 1300 527 665 STEP 03 Adjust extendable beam (D) to desired length using markers and secure beam at that length using screws provided 2000 1900 1800 1700 1600...
- Page 5 ASSEMBLY INSTRUCTIONS Quadro A Need help! Boardroom Frame Call us on 1300 527 665 STEP 04 TOP VIEW STEP 05 Attach beam (D) to legs (B) and Connector frame (C) Frame looks like this. Using Allen Key, attach beam (D) with Socket (F) using nut insert in legs.
- Page 6 ASSEMBLY INSTRUCTIONS Quadro A Need help! Boardroom Frame Call us on 1300 527 665 STEP 06 Place desktops on top of frame. Wood Screws to be drilled into the underneath Top. Page 6 of 6...
