ASSEMBLY INSTRUCTIONS
Quadro A Leg
Counter Table
Sizes:
2400L x 700D mm
2800L x 700D mm
3200L x 700D mm
3600L x 700D mm
Tools Required:
Power screwdriver; Allen key set (provided)
2 persons required for installation
Need help!
Call us on
1300 527 665
www.jasonl.com.au
1 of 9
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Jason.L Quadro A Leg Counter Table
Summary of Contents for Jason.L Quadro A Leg Counter Table
- Page 1 ASSEMBLY INSTRUCTIONS Quadro A Leg Counter Table Sizes: 2400L x 700D mm 2800L x 700D mm 3200L x 700D mm 3600L x 700D mm Tools Required: Power screwdriver; Allen key set (provided) 2 persons required for installation www.jasonl.com.au Need help! 1 of 9 1300 527 665 Call us on...
- Page 2 ASSEMBLY INSTRUCTIONS Quadro A Leg Counter Table COMPONENTS Table top x2 Leg Quadro A ( Half leg cross beam ) x2 Intermediate Leg Quadro A (Half leg cross beam ) x1 Leg wood add on x6 Leg bottom beam x3 Upper beam x2 Lower beam x2 Plastic bracket x8...
- Page 3 ASSEMBLY INSTRUCTIONS Quadro A Leg Counter Table STEP 02 STEP 01 TOP VIEW Using Allen Key provided, attach 2 plastic brackets (F) per exterior leg (B) (as Using Allen Key provided, attach M8x20MM Socket head (I)- per picture above) using M6x20MM (J) Socket head screw. Attach 4 plastic screw socket half way into legs.
- Page 4 ASSEMBLY INSTRUCTIONS Quadro A Leg Counter Table STEP 03 Adjust extendable beams (D) to desired length using markers and secure beams at that length using screws provided. 2000 1900 1800 1700 1600 1500 1400 1300 1200 www.jasonl.com.au Need help! 6 of 9 1300 527 665 Call us on...
- Page 5 ASSEMBLY INSTRUCTIONS Quadro A Leg Counter Table STEP 04 Adjust extendable beams (E) to desired length. Remove plastic inserts Loosen 2 bolts on beam using allen key Extent lower beam to the same distance as upper beam Insert plastic inserts back into the beams www.jasonl.com.au Need help! 7 of 9...
- Page 6 ASSEMBLY INSTRUCTIONS Quadro A Leg Counter Table STEP 05 TOP VIEW STEP 06 Attach Upper Beams (D) to legs using nut insert. Frame looks like this. Using Allen Key, attach Upper Beams (D) with Sockets (H). See point attached Need help! www.jasonl.com.au 1300 527 665 Call us on...
- Page 7 ASSEMBLY INSTRUCTIONS Quadro A Leg Counter Table STEP 07 Using Allen Key. Tighen Sockets (H) on the Lower Beam (E) using Allen Key (L). Insert Frame looks like this. plastic spacers to improve regidity. Attach two Sockets (I) to the side of the lower side beams (as shown in the picture).
- Page 8 ASSEMBLY INSTRUCTIONS Quadro A Leg Counter Table STEP 08 TABLE TOP BOTTOM VIEW nut insert nut insert Place desktops (A) ontop of frames. Nut inserts in top will align with plastic joiner brackets using M6x30MM (K) sockets attached tops to frames.
- Page 9 ASSEMBLY INSTRUCTIONS Quadro A Leg Counter Table If purchase with wheels: WEELS ASSEMBLY DONE! Replace Feet on the bottom of each leg with wheels (G) www.jasonl.com.au Need help! 11 of 9 1300 527 665 Call us on...
