- Page 1 ASSEMBLY INSTRUCTIONS Quadro A Leg Desk Sizes: 1400x800 1600x800 Tools Required: Power screwdriver; Allen key set (provided) 2 persons required for installation www.jasonl.com.au Need help! 1 of 6 1300 527 665 Call us on...
- Page 2 ASSEMBLY INSTRUCTIONS Quadro A Leg Desk COMPONENTS Table top x1 Legs Quadro A x2 Beam x1 Plastic bracket x4 SCREWS M8x20MM CSK x2 M8x20MM Socket head x2 M6x20MM Socket head x4 M6x30MM Socket head x4 Allen key x2 Colour of the beam is always black, regardless desk frame colour. www.jasonl.com.au Need help! 2 of 6...
- Page 3 ASSEMBLY INSTRUCTIONS Quadro A Leg Desk STEP 02 STEP 01 Using Allen Key provided, attach 2 plastic brackets per leg (D) Using Allen Key provided, attach M8x20MM Socket head (F)- (as per picture above) using M6x20MM (G) Socket head screw screw socket half way into leg for both legs (B) www.jasonl.com.au Need help!
- Page 4 ASSEMBLY INSTRUCTIONS Quadro A Leg Desk STEP 03 Adjust extendable beam (C) to desired length using markers and secure beam at that length using screws provided 2000 1900 1800 1700 1600 1500 1400 1300 1200 www.jasonl.com.au Need help! 4 of 6 1300 527 665 Call us on...
- Page 5 ASSEMBLY INSTRUCTIONS Quadro A Leg Desk STEP 05 STEP 04 TOP VIEW Attach beam (C) to legs (B) using nut insert in legs. Frame looks like this. Using Allen Key, attach beam (C) with Socket (E) See point attached www.jasonl.com.au Need help! 5 of 6 1300 527 665...
- Page 6 ASSEMBLY INSTRUCTIONS Quadro A Leg Desk STEP 06 TABLE TOP BOTTOM VIEW nut insert nut insert Place desktop ontop of frame - with cutout at the back of the desk. Nut inserts in top will align with plastic joiner brackets using M6x30MM (H) sockets attached top to frame.
