- Page 1 ASSEMBLY INSTRUCTIONS Quadro A Leg Counter Table Sizes: 1200x700 1800x700 Tools Required: Power screwdriver; Allen key set (provided) 2 persons required for installation www.jasonl.com.au Need help! 1 of 7 1300 527 665 Call us on...
- Page 2 ASSEMBLY INSTRUCTIONS Quadro A Leg Counter Table COMPONENTS Table top x1 Leg Quadro A x2 Upper Beam x1 Lower Beam x1 Plastic bracket x4 Feet x4 SCREWS M8x20MM CSK x4 M8x20MM Socket head x4 M6x20MM Socket head x4 M6x30MM Socket head x4 Allen key x2 Colour of the beam is always black, regardless desk...
- Page 3 ASSEMBLY INSTRUCTIONS Quadro A Leg Counter Table STEP 01 STEP 02 STEP 03 TOP VIEW Use fixed beam (C) and secure beam Using Allen Key provided, attach 2 plastic brackets per Using Allen Key provided, attach M8x20MM using screws provided to suit desk leg (D) (as per picture above) using M6x20MM (I) Socket head (H)- screw socket half way into Socket head screw.
- Page 4 ASSEMBLY INSTRUCTIONS Quadro A Leg Counter Table STEP 06 STEP 05 TOP VIEW Attach Upper Beam (C) to legs (B) using nut insert in legs. See point Frame looks like this. Using Allen Key, attach Upper Beam (C) with Sockets (G). attached www.jasonl.com.au Need help!
- Page 5 ASSEMBLY INSTRUCTIONS Quadro A Leg Counter Table STEP 07 Frame looks like this. Using Allen Key. Tighen Sockets (G) on the Lower Beam (D) using Allen Key (J). Insert plastic spacers to improve regidity. Attach two Sockets (G) to the side of the lower side beams (as shown in the picture). www.jasonl.com.au Need help! 5 of 7...
- Page 6 ASSEMBLY INSTRUCTIONS Quadro A Leg Counter Table STEP 08 TABLE TOP BOTTOM VIEW nut insert nut insert Place desktop ontop of frame. Nut inserts in top will align with plastic joiner brackets using M6x30MM (J) sockets attached top to frame. www.jasonl.com.au Need help! 6 of 7...
- Page 7 ASSEMBLY INSTRUCTIONS Quadro A Leg Counter Table If purchase with wheels: WHEELS ASSEMBLY DONE! Replace Feet on the bottom of each leg with wheels (F) www.jasonl.com.au Need help! 7 of 7 1300 527 665 Call us on...
