- Page 1 ASSEMBLY INSTRUCTIONS Quadro Square Leg Counter Table Size: 1400 x 700 1600 x 700 Tools Required: Power screwdriver; Allen key set (provided) 2 persons required for installation www.jasonl.com.au Need help! 1 of 7 1300 527 665 Call us on...
- Page 2 ASSEMBLY INSTRUCTIONS Quadro Square Leg Counter Table COMPONENTS Table top x1 Legs Quadro Square x2 Beam x1 Plastic bracket x4 Feet x4 SCREWS M8x20MM CSK x2 M8x20MM Socket head x2 M6x20MM Socket head x4 M6x30MM Socket head x4 Allen key x2 Colour of the beam is always black, regardless desk frame colour.
- Page 3 ASSEMBLY INSTRUCTIONS Quadro Square Leg Counter Table STEP 02 STEP 01 TOP VIEW Using Allen Key provided, attach 2 plastic brackets per leg (D) (as per Using Allen Key provided, attach M8x20MM Socket head (G)- picture above) using M6x20MM (H) Socket head screw. Screw the feets screw socket half way into leg for both legs (B) (E) to the bottom of each leg (B) www.jasonl.com.au...
- Page 4 ASSEMBLY INSTRUCTIONS Quadro Square Leg Counter Table STEP 03 Adjust extendable beam (C) to desired length using markers and secure beam at that length using screws provided 2000 1900 1800 1700 1600 1500 1400 1300 1200 www.jasonl.com.au Need help! 4 of 7 1300 527 665 Call us on...
- Page 5 ASSEMBLY INSTRUCTIONS Quadro Square Leg Counter Table STEP 05 STEP 04 TOP VIEW Attach beam (C) to legs (B) using nut insert in legs. Frame looks like this. Using Allen Key, attach beam (C) with Socket (F) See point attached www.jasonl.com.au Need help! 5 of 7...
- Page 6 ASSEMBLY INSTRUCTIONS Quadro Square Leg Counter Table STEP 06 TABLE TOP BOTTOM VIEW nut insert nut insert Place desktop ontop of frame. Nut inserts in top will align with plastic joiner brackets using M6x30MM (I) sockets attach top to frame. www.jasonl.com.au Need help! 6 of 7...
- Page 7 ASSEMBLY INSTRUCTIONS Quadro Square Leg Counter Table If purchase with wheels: WEELS ASSEMBLY DONE! Replace Feet (E ) on the bottom of each leg (B) with wheels (E ) www.jasonl.com.au Need help! 7 of 7 1300 527 665 Call us on...
