Keypad with MIFARE proximity card reader
CR-MF5
EN
Firmware version 1.00
cr-mf5_en 11/23
SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND
tel. +48 58 320 94 00
www.satel.pl

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CR-MF5 and is the answer not in the manual?

Questions and answers

Related Manuals for Satel CR-MF5

Summary of Contents for Satel CR-MF5

  • Page 1 Keypad with MIFARE proximity card reader CR-MF5 Firmware version 1.00 cr-mf5_en 11/23 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
  • Page 2 Changes, modifications or repairs not authorized by the manufacturer shall void your rights under the warranty. SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.

  • Page 3: Table Of Contents

    CONTENTS Features ........................... 4 Description ........................5 LED indicators ......................5 Function key ....................... 6 PUSH IN terminals ...................... 6 Connecting the keypad to the computer ................6 CR SOFT program ......................7 Starting out ......................... 7 4.1.1 Setting the administrator password ..............7 4.1.2 Changing the password ..................
  • Page 4 CR-MF5 SATEL 5.2.1 Installation in short ..................... 30 5.2.2 Description of terminals for keypad in the INTEGRA system ......30 5.2.3 Mounting the keypad in the INTEGRA system ........... 31 5.2.4 Programming the keypad in the INTEGRA system ..........32 Programming in the DLOADX program ...............
  • Page 5 SATEL CR-MF5 Blocking the door ......................48 Unblocking the door ....................48 Restoring the door to normal operation mode ............. 48 Changing the code ...................... 48 Firmware update ......................48 10. Specifications ......................... 48...

  • Page 6: Features

    CR-MF5 SATEL The CR-MF5 keypad can operate as: • INT-SCR partition keypad in the INTEGRA alarm system, • ACCO-SCR keypad with proximity card reader in the ACCO access control system, • keypad with proximity card reader in systems of other manufacturers, •...

  • Page 7: Description

    SATEL CR-MF5 2. Description LED indicators. keys for entering the code. function key. 2.1 LED indicators red LED. green LED. yellow LED. The LED indicators have different functions depending on the operating mode.

  • Page 8: Function Key

    (e.g. ACCO-USB by SATEL). Follow the instructions in the converter manual. Do not connect more than 24 access control devices provided with the MIFARE card reader (CR-MF5 and CR-MF3) to the converter. The CR SOFT program may not be able to support more devices correctly.

  • Page 9: Cr Soft Program

    The program is used to program the settings of access control devices provided with the MIFARE card reader (CR-MF5 and CR-MF3) and to program MIFARE cards (the SO-PRG programmer is required). You can download it from www.satel.pl.

  • Page 10: Changing The Password

    CR-MF5 SATEL 4.1.2 Changing the password 1. Click on the menu bar. The menu will be displayed. 2. Click “CHANGE PASSWORD”. The “CHANGE PASSWORD” window will be displayed. 3. In the “Old password” field, enter the current password. 4. In the “New password” field, enter the new password (1-16 digits, letters or special characters).

  • Page 11: Program Window

    SATEL CR-MF5 2. Click “CONFIGURATION”. The “Configuration” window will be displayed. 3. Click the “Program language” field. The list of languages will be displayed. 4. Click the language to be used. 5. Click “SAVE”. The “CONFIGURATION” window will be closed.

  • Page 12: List Of Projects

    CR-MF5 SATEL List of projects All projects to which you have access are displayed on the list. Click a project to open it. Tool bar for the list of projects Project-related buttons and functions are displayed on the tool bar.

  • Page 13: Tabs

    SATEL CR-MF5 Tabs Click a tab to display the settings available in the tab. PROJECT – project details. SYSTEM – system settings: INTERFACES – communication interfaces settings. TOKEN SETTINGS – MIFARE cards settings. DEVICES – list of access control devices in the project and their settings.

  • Page 14: Menu

    CR-MF5 SATEL - click to write data to the access control devices or the programmer. This button is displayed when a project is open and the program is connected with the access control devices / programmer. - click to display the menu.

  • Page 15: Message Window Settings

    (e.g. controller or control panel) which decides whether to grant access or not. You can select: INTEGRA/ACCO – access control devices and cards will be used in one of the SATEL systems: INTEGRA alarm system or ACCO access control system.

  • Page 16: Importing A Project

    CR-MF5 SATEL 2. Click the type of project you want to create. The “Enter project master key (OSDP)” window will be displayed. 3. Enter the master key (32 hexadecimal characters) or click to generate a random master key. 4. Click “SET”. The “Enter project master key (OSDP)” window will be closed.

  • Page 17: Deleting A Project

    SATEL CR-MF5 2. In the “Path” field, enter the file path or click to indicate the file location in the system window. 3. In the “Password” field, enter the password for the file you are importing. 4. Click “IMPORT”. The project successfully imported will be displayed on the list of projects.

  • Page 18: Programming The Interface Settings

    CR-MF5 SATEL If several devices have the same OSDP address, it is impossible to establish connection with the devices. 5. Click “CONNECT”. The program will connect with the devices. If the devices are new to the project, they will be added to the project (“DEVICES” tab).

  • Page 19: Programming The Card Settings

    Token settings for the INTEGRA/ACCO on-line system SATEL token key – card number access key for all types of cards. After a project has been created, it is the same as the Master key. You can change it.

  • Page 20: Token Settings For Other On-Line System Or Standalone System

    For the MIFARE Classic card types, only the key’s 6 lower bytes are used. If you enable the No encryption option, the SATEL token key will be cleared. Program the same settings in the INTEGRA alarm system / ACCO access control system.
  • Page 21 SATEL CR-MF5 Sector number – number of the data sector in which the card number is to be written. You can enter a number from 0 to 16. This parameter applies to the Sector Serial Number (SSN) mode. Block – number of the block in the sector in which the card number is to be written. You can enter a number from 0 to 2.

  • Page 22: Programming The Access Control Device Settings

    CR-MF5 SATEL Application ID – application identifier that indicates the directory containing the card number file. You can enter 6 hexadecimal characters (3 bytes). File ID – number of the file with card number. Offset – card number’s first byte position in the file. You can enter a number from 0 to 99.

  • Page 23: Description Of The "Devices" Tab

    SATEL CR-MF5 Description of the “DEVICES” tab tool bar for the list of devices. list of devices. Tool bar for the list of devices Device-related buttons and functions are displayed on the tool bar. - click to add a device to the project without connecting with the device (see: “Adding to the project a device not connected to the computer”).

  • Page 24: Keypad Settings

    Product – type of access control device. Serial number – serial number of the device. It is uploaded after connection is established with the device. You will find it on the label inside the device enclosure (marked as Satel MNI).
  • Page 25 SATEL CR-MF5 After presenting the card – the card ID is sent immediately after it is read. After moving the card away – the card ID is sent after the card has been moved away from the reader. Signal identifier sending – way of signaling the card ID sending: According to system –...

  • Page 26: Changing The Device's Osdp Address

    CR-MF5 SATEL Door status input – settings of the input that controls the door status (IN1): Unused – input is not used. NC – input supports a detector provided with the NC (normally closed) type output. NO – input supports a detector provided with the NO (normally open) type output.

  • Page 27: Deleting A Device From The Project

    SATEL CR-MF5 Deleting a device from the project 1. Click a device on the list to select it. 2. Click . The device will be deleted. 4.3.8 Managing users This function is available after opening a Standalone system type project. You can manage the users in the “USERS”...
  • Page 28 CR-MF5 SATEL field – click to change the user’s code (see: “Changing the user’s code”) or delete the code (“Deleting the user’s code”). Card – if the user has no card, the button is displayed in the field – click to add a card to the user (see: “Adding a card to the user”).
  • Page 29 SATEL CR-MF5 4. Click “SET”. The “Change code” window will be closed. Deleting the user’s code 1. Click the user’s code (shown as dots). The “Change code” window will be displayed. 2. Click „DELETE”. The “Change code” window will be closed. In the “Code” column, the button will be displayed.

  • Page 30: Deleting A User From The Project

    CR-MF5 SATEL 2. Click the card that you want to add to the user. 3. Click “ADD”. The “Change card” window will be closed. In the “Card” column, the number of the new card will be displayed. Deleting the user’s card 1.

  • Page 31: The Int-Scr Keypad In The Integra System

    SATEL CR-MF5 2. Click “EXPORT”. The “Export project” window will be displayed. 3. In the “Password” field, enter the password to secure the file you are exporting (1-16 digits, letters or special characters). 4. Disable the Editing settings option if the system settings are to be unavailable after the file is imported (the “System”...

  • Page 32: Installation In Short

    − select INT-SCR as the additional interface type. − set the keypad address for the purpose of the SATEL bus. It must be a unique address in the range from 0 to 31 (different from that of the other devices connected to the same control panel bus).

  • Page 33: Mounting The Keypad In The Integra System

    SATEL CR-MF5 common ground CLK/D0 clock [INT-SCR interface] NC type door status input NO type request-to-exit input not used BELL OC type output 5.2.3 Mounting the keypad in the INTEGRA system 1. Place the enclosure base against the wall and mark the location of mounting holes.

  • Page 34: Programming The Keypad In The Integra System

    CR-MF5 SATEL 8. If the request-to-exit button is to be used, connect it to the IN2 and COM terminals. We recommend using a monostable button. 9. You can connect the BELL terminal (OC type output) e.g. to the alarm control zone.

  • Page 35: Keypad Settings

    SATEL CR-MF5 Keypad settings Name – individual name of the device (up to 16 characters). Partition – partition operated by the keypad. Lock [Lock feature] – if the option is enabled, the keypad can control access to a single door (the following parameters are available: Lock features, Relay ON time, Max.
  • Page 36 CR-MF5 SATEL Fixed ON time – OFF if door closed [ON, close→off] – the relay output will be turned on until the door is closed (door status input is reconnected to common ground), however not longer than for the Relay ON time.
  • Page 37 SATEL CR-MF5 control panel is sending events to the monitoring station, but unauthorized persons should not be aware of the alarm being generated. The option is available if the PANIC alarm option is enabled. Alarm 3 incorrect codes [3 wrong codes] – if this option is enabled, using an incorrect code / card three times will generate an alarm.

  • Page 38: Using The Int-Scr Keypad

    CR-MF5 SATEL Auto-backlight No – if you select this option, the backlight will only go on after a key is pressed / card is presented. Zone violation – if you select this option, the backlight will additionally go on if a selected zone is violated.

  • Page 39: Sound Signaling

    SATEL CR-MF5 Flashing of the LEDs successively from left to right indicates no connection with the control panel (e.g. connection made incorrectly). Flashing of the LEDs successively from right to left indicates no communication with the control panel (connection made correctly but the device has not been identified).

  • Page 40: [Code] / Holding The Card

    CR-MF5 SATEL • clear alarm, • gain access (turn on the keypad relay), • toggle the state of 25. BI switch type outputs, • turn on the 24. MONO switch type outputs, • confirm the guard round, • temporarily block the partition.

  • Page 41: Generating The Alarm From The Keypad

    SATEL CR-MF5 Generating the alarm from the keypad The installer can permit generating alarms from the keypad. To generate an alarm: fire alarm – press and hold for 3 seconds, medical (auxiliary) alarm – press and hold for 3 seconds, panic alarm –...

  • Page 42: Installation In Short

    3.4. Program the keypad settings (p. 20): − select ACCO-SCR as the additional interface type. − set the keypad address for the purpose of the SATEL bus. The keypad with address 0 will operate as terminal A (entry terminal). The keypad with address 1 will operate as terminal B (exit terminal).

  • Page 43: Description Of Terminals For Keypad In The Acco System

    SATEL CR-MF5 6. Mount the keypad and start it (p. 41). 7. Program the keypad settings in the ACCO Soft program (ACCO NET system) or in the ACCO-SOFT-LT program (p. 42): The ACCO Soft program in version 1.9 (or newer) enables programming of all the required settings (ACCO NET system).

  • Page 44: Connecting Using The Acco-Scr Interface

    CR-MF5 SATEL 5. Connect the keypad to the controller (see: “Connecting using the ACCO-SCR interface” or “Connecting using the RS-485 bus (OSDP)”). 6. You can connect the BELL terminal (OC type output) e.g. to the controller input. 7. Connect the power to the +12V and COM terminals. The keypad can be powered directly from the controller or from a power supply.

  • Page 45: The Keypad In Other Manufacturer's System

    SATEL CR-MF5 7. The keypad in other manufacturer’s system 7.1 Installation in other manufacturer’s system The keypad must be connected to a device that supports the OSDP protocol or the Wiegand interface. Disconnect power before making any electrical connections. 7.1.1 Installation in short 1.

  • Page 46: Mounting The Keypad In Other Manufacturer's System

    CR-MF5 SATEL Terminal Description not used not used not used DATA/D1 data (1) [Wiegand interface] RS-485 bus terminal [OSDP] RS-485 bus terminal [OSDP] tamper output +12V +12 VDC power input common ground CLK/D0 data (0) [Wiegand interface] programmable input [Wiegand interface]...

  • Page 47: Installation Of The Standalone Door Control Module

    SATEL CR-MF5 8.2 Installation of the standalone door control module Disconnect power before making any electrical connections. 8.2.1 Installation in short 1. Open the keypad enclosure. 2. Connect the keypad to the computer (p. 6). 3. Program the keypad in the CR SOFT program.

  • Page 48: Mounting The Standalone Door Control Module

    CR-MF5 SATEL Terminal Description not used BELL OC type output 8.2.3 Mounting the standalone door control module 1. Place the enclosure base against the wall and mark the location of mounting holes. 2. Drill the holes in the wall for wall plugs (anchors).

  • Page 49: Using The Standalone Door Control Module

    SATEL CR-MF5 8.3 Using the standalone door control module Most features are available on using the code or proximity card by the user. Managing users and adding codes and proximity cards to the users can be done in the CR SOFT program (see: “Managing users”...
  • Page 50 2. Enter the code and press 3. Enter the new code and press 9. Firmware update 1. Download the device firmware update program from the support.satel.pl website. 2. Start the downloaded program. 3. Click 4. In the window that will be displayed, indicate the COM port through which communication with the device is to take place, then click “OK”.
  • Page 51 SATEL CR-MF5 Maximum humidity ......................93±3% Dimensions ....................47 x 158 x 30 mm Weight ..........................129 g...
