- Page 1 AquapHOx® Logger Underwater O , pH, T Meter MANUAL Version V1.13 www.pyroscience.com...
- Page 2 AquapHOx® Logger | Manual AquapHOx® Logger Underwater O , pH, T Meter Document Version 1.13 The AquapHOx® Loggers are released by: PyroScience GmbH Kackertstrasse 11 52072 Aachen Germany Phone +49 (0)241 5183 2210 +49 (0)241 5183 2299 Email info@pyroscience.com www.pyroscience.com...
-
Page 3: Table Of Contents
AquapHOx® Logger | Manual TABLE OF CONTENT Introduction ............................... 4 Overview ..............................5 Optical Port ............................5 Built-In Temperature Sensor ......................5 Air Pressure Compensation ......................6 Included Accessories ........................6 Optional Accessories ........................7 Software Installation ..........................9 Configuration ............................10 Connecting the Sensor Head ...................... -
Page 4: Introduction
Logger platform offers one optical port for connection of a wide range of optical O - or pH- sensors from PyroScience. A fixed NTC temperature sensor provides automatic temperature compensation of the optical sensors. The integrated rechargeable LiPo battery offers stand-alone logging for up to 1 year. -
Page 5: Overview
AquapHOx® Logger | Manual OVERVIEW The front of the AquapHOx® Logger provides the port for connecting optical sensors using the PyroScience SUB-connector, the fixed NTC temperature sensor for automatic temperature compensation, and a mounting thread for calibration containers or protective cage during deployment/transport. The backside of the device provides the connector with the USB interface. -
Page 6: Air Pressure Compensation
AquapHOx® Logger | Manual Air Pressure Compensation APHOX devices, the Pyro Workbench offers two ways to compensate for deviating ambient air pressure at the water surface. The ambient air pressure can either be entered in "hPa" as fixed pressure (measured at the water surface), or in approx. -
Page 7: Optional Accessories
AquapHOx® Logger | Manual Optional Accessories Sensor protection cage with anti-(bio)fouling net (item: APHOX®-CAGE-AF). Anti-(bio)fouling net for underwater (-SUB) pH and oxygen sensor caps (item APHOX®-CAP-AF). For optimal protection, the anti-(bio)fouling net (copper alloy) for the sensor cap protection cage (item: APHOX®-CAP-AF) should be combined with the sensor protection cage for... - Page 8 AquapHOx® Logger | Manual Flow-through-cell (item: APHOX®-FTC). The flow-through cell allows to connect the APHOX® devices to a flow path. It can be used fully submerged, as well as in the laboratory, and can be combined with all PyroScience cap sensors with SUB-connector.
-
Page 9: Software Installation
AquapHOx® Logger | Manual SOFTWARE INSTALLATION AquapHOx® Logger is operated with the user-friendly software Pyro Workbench. This software offers comfortable settings and calibration wizards, as well as advanced logging features. Several devices can be operated in parallel within a single window. -
Page 10: Configuration
AquapHOx® Logger | Manual CONFIGURATION This chapter provides short instructions how to install, configure, and calibrate sensor heads to the AquapHOx® Logger. For in-depth information especially on sensor settings and sensor calibration, please refer to the respective Analyte Sensor Manual... -
Page 11: Sensor Settings
Enter all required parameters in the software, and perform a sensor calibration. 2-point calibration • For 0% calibration, use the 0% calibration capsules from PyroScience, giving 50mL 0% calibration standard (item no.: OXCAL). • For calibration using the calibration container, please dissolve 2 capsules in 100ml deion. water (NOT seawater). -
Page 12: Calibration Of Ph Sensors
AquapHOx® Logger | Manual Calibration of pH Sensors • A one-point calibration is obligatory to start measurements. • A two-point calibration is highly recommended before every measurement. • An additional pH offset-adjustment is recommended only for advanced applications, e.g. measurements in complex media. - Page 13 AquapHOx® Logger | Manual • Select the desired calibration against the integrated NTC Temperature Sensor or against a Fixed Reference Temperature. • Calibrate the optical temperature sensor. Important: When using the integrated NTC temperature sensor for the reference temperature, ensure that the connected optical temperature sensors is exposed to the same temperature as the NTC temperature sensor.
-
Page 14: Measurements
AquapHOx® Logger | Manual MEASUREMENTS After the device has been configured as described in the previous chapter, measurements and data logging can be started using the software Pyro Workbench. Online Measurements The main window of Pyro Workbench will automatically start with periodic measurements (indicated by "II") after a successful sensor calibration. -
Page 15: Charging The Battery
AquapHOx® Logger | Manual Stand-alone Logging does not require a connection the PC. The data are stored on the device. After completion of the experiment, the data are downloaded from the device to a PC. Important for Stand-alone Logging: Check the battery status. The battery is sufficient for >1-year deployment with 10 min sampling interval and is fully recharged within ca. -
Page 16: Data Retrieval
AquapHOx® Logger | Manual Data Retrieval After retrieving the logger, remove the dummy plug and connect the device to the PC with the included USB cable. • Start the Pyro Workbench software. • Click on Stop Logging • Download the recorded data to the PC by selecting the respective logfile from the list of Logfiles in device memory in the Stand-alone logging window and clicking on "Download". -
Page 17: Compensation Of Ph Sensor Drift
AquapHOx® Logger | Manual Compensation of pH Sensor Drift For long-term measurements of pH sensors, it is possible to perform a manual drift compensation using the Pyro Data Inspector. • After retrieving the logger, rinse the pH sensor with distilled water and put the sensor into a freshly prepared pH 2 (PHCAL2) calibration solution. -
Page 18: Appendix
AquapHOx® Logger | Manual APPENDIX Dimensions Device Specification For sensor specifications and response times, please refer to the webpages of the different sensor types. Specifications Item No. APHOX-LX APHOX-L-PH APHOX-L-O Dimensions 63 x 300 mm 63 x 300 mm Weight in air 1.35 kg... -
Page 19: Warnings & Safety Guidelines
AquapHOx® Logger | Manual Optical sensor port Compatible optical sensors Portfolio of optical sensors with underwater connector (-SUB) from PyroScience External temperature sensor NTC thermistor for temperature compensation Resolution 0.005°C Accuracy 0.05°C Typical response time 0.5 s Software Software Pyro Workbench... - Page 20 AquapHOx® Logger | Manual In case of problems or damage, disconnect the device and mark it to prevent any further use. Consult PyroScience for advice! There are no serviceable parts inside the device. Please note that opening the housing will void the warranty.
- Page 21 AquapHOx® Logger | Manual CONTACT PyroScience GmbH Tel.: +49 (0)241 5183 2210 Kackertstraße 11 Fax: +49 (0)241 5183 2299 52072 Aachen info@pyroscience.com Deutschland www.pyroscience.com www.pyroscience.com...
