pyroscience FireSting pro User Manual

Fiber-optic multi-analyte meter
Hide thumbs Also See for FireSting pro:
Table of Contents

Advertisement

Quick Links

Download this manual
FireSting pro
F
-
M
-A
M
IBER
OPTIC
ULTI
NALYTE
ETER
U
M
SER
ANUAL
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FireSting pro and is the answer not in the manual?

Questions and answers

Related Manuals for pyroscience FireSting pro

Summary of Contents for pyroscience FireSting pro

  • Page 1 FireSting pro IBER OPTIC ULTI NALYTE ETER ANUAL...
  • Page 2 Document Version 1.0111 FireSting pro is manufactured by PyroScience GmbH Hubertusstr. 35 52064 Aachen Germany Phone +49 (0)241 5183 2210 +49 (0)241 5183 2299 Email info@pyroscience.com Internet www.pyroscience.com Registered: Aachen HRB 17329, Germany...
  • Page 3 4 analog outputs and a broadcast-mode. The new innovative and user-friendly Pyro Workbench allows operation of several FireSting pro meters in parallel as a scalable multi-channel system. More information concerning our products can be found at www.pyroscience.com or contact us at info@pyroscience.com.
  • Page 4 2 Introduction to the FireSting pro Meter FireSting pro comes with 1, 2, or 4 channels (optical sensor ST-connectors 1 to 4) for up to 4 fiber-optic sensors and one connector (T) for an external Pt100 temperature probe. The optical...

  • Page 5: Quick Start

    PyroScience website: https://www.pyroscience.com/downloads.html Unzip and start the installer, and follow the instructions. Step 2: Connect the FireSting pro meter with the micro-USB cable to the Windows PC/laptop (Windows 7, 8, 10). Step 3: Connect appropriate PyroScience sensor(s) to the optical sensor connectors 1 to 4 at the device (see 4).

  • Page 6: Connecting Sensors

    4 Connecting Sensors The fiber-optic oxygen, pH and temperature sensors, as well as optical fibers needed for read-out of contactless sensors are connected to the ST-connectors of the FireSting pro (1 to 4) with a male fiber plug. • Remove the black caps from the plug of the sensor / fiber.

  • Page 7: Optical Sensors

    5 Optical sensors FireSting pro is compatible with a broad range of optical oxygen, pH and temperature sensors from PyroScience. For an overview of available optical sensor types, please see the PyroScience website: https://www.pyroscience.com/products.html...
  • Page 8 6 Specifications of the FireSting pro Dimensions 68 x 120 x 22 mm (housing) 78 x 120 x 24 (total) Weight ca. 290 g Interface USB 2.0 Power supply USB-powered (max 50mA at 5V) Supported operating systems Windows 7, 8, 10 Operating temperature 0 to 50°C...

  • Page 9: Related Documents

    7 Related documents Detailed instructions for using the Pyro Workbench and application of optical oxygen, pH and temperature sensors.  Manual for logger software "Pyro Workbench" (Windows)  manuals for optical sensors from PyroScience (oxygen, pH, temperature)

  • Page 10: Warnings And Safety Guidelines

    8 Warnings and Safety Guidelines Before using the FireSting pro and its sensors, read carefully the instructions and user manuals. In case of problems or damage, disconnect the instrument and mark it to prevent any further use! Consult PyroScience advice! There are no serviceable parts inside the device. Please...
