TACO MA , TU NDR A & COLORA D O
BED R AC K HE ADACH E R AC K
I N STA L L INS TR UC TIO NS
Please read the mounting instructions below carefully before attempting to install.
Be sure to check out the install video on the product page, if available.
Thank you for purchasing from Victory 4x4! Checkout our website, victory4x4.com for other great off-road
products. Be sure to rate and review our product online. If you have any questions or are missing parts, please
don't hesitate to call us at 269-459-8447!
Advertisement
Related Manuals for Victory 4x4 VBR-HR
Summary of Contents for Victory 4x4 VBR-HR
- Page 1 Be sure to check out the install video on the product page, if available. Thank you for purchasing from Victory 4x4! Checkout our website, victory4x4.com for other great off-road products. Be sure to rate and review our product online. If you have any questions or are missing parts, please...
-
Page 2: Includ Ed Hardwar E
18-8 x 1/4” M6 x 25mm Flat Washer Button Head M6 Steel Serr Flange Nut Note: Some Victory 4x4/JCR Offroad/SquatchProof products share hardware kits. Any extra hardware you may recieve that is not listed above can be reurposed or discarded. -
Page 3: Included Parts
I NCLU D E D PARTS Panel Pieces Connector Bracket... -
Page 4: Installation
INSTA L L AT I ON Start by taking the (2) provided panel pieces and assembling them together using the connector bracket and the supplied M6 button heads, washers and flange nuts. Assemble together as shown in the orientation below. - Page 5 I NS TA LL ATI ON With the (2) panels assembled together as one, take (10) of the provided 5/16” button heads and flange nuts and secure the panel assembly to the back of your Bed Rack, as shown in the orientation below, with the connector bracket bolts facing the cab (viewed from the cab side of the rack).
- Page 6 INSTA L L AT I ON With your panel secure to your Bed Rack, make sure all of your hardware is tight to complete your install. And that’s it! You’re now equipped with a sturdy mounting location for your desired fast-access gear. Please visit us at www.victory4x4.com for other made-in-the-US armor and storage options.
