Titan 680 Installation, Maintenance & Parts Manual
Titan 680 Installation, Maintenance & Parts Manual

Titan 680 Installation, Maintenance & Parts Manual

Multi-strand chain conveyor

Advertisement

Quick Links

Industrial Conveyor Specialists
Installation, Maintenance & Parts Manual
For
MODEL 680
Multi-Strand Chain Conveyor
Titan Conveyors
735 Industrial Loop Road
New London, WI 54961
920-982-6600
800-558-3616
FAX 920-982-7750
E-mail: sales@titanconveyors.com
Website: www.titanconveyors.com
Serial No.
Go to Table of Contents

Advertisement

loading
Need help?

Need help?

Do you have a question about the 680 and is the answer not in the manual?

Questions and answers

Summary of Contents for Titan 680

  • Page 1 Industrial Conveyor Specialists Installation, Maintenance & Parts Manual MODEL 680 Multi-Strand Chain Conveyor Titan Conveyors 735 Industrial Loop Road New London, WI 54961 920-982-6600 800-558-3616 FAX 920-982-7750 E-mail: sales@titanconveyors.com Website: www.titanconveyors.com Serial No. Go to Table of Contents...
  • Page 2 (D) No representative of TITAN has been conferred with any authority to waive, alter, vary or add to the terms of warranty state herein, without prior authorization in writing executed by an officer of the company.
  • Page 3 V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S...
  • Page 4 Titan at 920-982-6600. I. RECEIVING Upon delivery of your Titan conveyor, check the packing slip or bill of lading accompanying the unit. If any components are missing, contact Titan IMMEDIATELY with a description of the missing components along with the conveyor serial number(s).
  • Page 5 V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S V E Y O R S...
  • Page 6 2. VENTILATION - During normal operation gear reducers build up heat and pressure that MUST be vented to protect the seals and gears. If not installed at Titan, a brass vent plug contained in a small plastic bag, will be put in a box or larger bag along with fasteners sent loose for use during field installation.
  • Page 7 BEARINGS 1. LUBRICATION - Bearings used on Titan Conveyors are normally pre-lubed for life. If customer requested, re-lube bearings are provided, the use of a #2 consistency lithium based grease is advised. Greasing Frequency should be as many times as necessary to maintain a small film of grease leaking at the seals. This will protect against foreign materials entering the bearing.
  • Page 8 SAE 40 120 degrees - 140 degrees F SAE 50 REMEMBER - ALL GUARDS AND BOTTOM PANS, IF PROVIDED, MUST BE REPLACED BEFORE RUNNING CONVEYOR. TITAN INDUSTRIES IS NOT DANGER RESPONSIBLE FOR INJURIES CAUSED BY NOT COMPLYING WITH SAFETY INSTRUCTIONS.
  • Page 9 V E Y O R S V E Y O R S V E Y O R S MODEL 680 MULTI STRAND CHAIN CONVEYOR Model 680 Multi-Strand Chain Conveyor DRIVE SHAFT 16. FRAME SPREADER CHAIN 17. FRAME WELDMENT R/H CHAIN DRIVE SPROCKET 18.
