Safety Precautions

1.4. UL and cUL Installation

• This equipment is open-type and shall be installed in a tool only accessible enclosure suitable for
the environment.
• All devices have to be supplied by a Class 2 power supply.
• This equipment is suitable for use in Class I, Division 2, Groups A,B,C and D or non-hazardous
locations only.
• Temperature code of T4.
WARNING
• Do not separate when energized.
AVERTISSEMENT, NE PAS SEPARER SOUS TENSION.
• Only UL and cUL approved expansion units are allowed to be connected to the
port designated "EXPANSION". At the moment there are no such units evaluated or
allowed.
SEULES LES UNITÉS D'EXTENSION CERTIFIÉES UL ET cUL PEUVENT ÊTRE RACCORDÉES
AU PORT DÉSIGNÉ «EXPANSION». À L'HEURE ACTUELLE, AUCUNE UNITÉ DE CE TYPE
N'A ÉTÉ TESTÉE OU AUTORISÉE.
• Explosion hazard! Substitution of components may impair suitability for Class I,
Division 2.
RISQUE D'EXPLOSION! LA SUBSTITUTION DE COMPOSANTS PEUT NUIRE Á LA
CONFORMITÉ DE CLASSE I, DIVISION 2.
• Battery may explode if mistreated. Do not recharge, disassemble or dispose of in
fire.
LA BATTERIE PEUT EXPLOSER EN CAS DE MAUVAISE MANIPULATION. NE LA
RECHARGEZ PAS, NE LA DÉMONTEZ PAS ET NE LA JETEZ PAS DANS LE FEU.
• This product contains a battery; this must only be changed in an area known to be non-hazardous.
• Replace the battery with a BR2032 battery. Use of another type of battery may present a risk of
fire or explosion.
• For use on a flat surface of a type 4X enclosure indoor use only.
• Use minimum 75°C copper conductors only.
• To make wiring connections to the power supply connector, follow the table with cable and torque
specifications below:
Terminal Block Connector
X1/X100 Phoenix connectors
X1/X100 Anytek connectors
X1/X100 DECA connectors
• These devices are Class 2 supplied programmable controllers (industrial PCs) for the use in
industrial control equipment and are intended to be (front) panel mounted (Type 12 and 4x for
indoor use only).
2023-09
Wire Size AWG
AWG 30 – 12
AWG 24 – 12
AWG 24 – 12
6 Beijer Electronics, MAEN275
Torque (Lb.In.)
5 – 7
3.5
7
