3. Technical Data

Parameter
Front panel, W×H×D
Standalone mounting
Sealing
Frame material
Weight
CPU
Serial ports
Serial port COM B
Ethernet LAN A
Ethernet LAN B
USB
External storage media
Flash memory
(application memory)
Memory RAM
NVRAM
Real time clock
Battery
Power consumption at
rated voltage
Fuse
Beijer Electronics, MAEN275
128 × 101 × 39 mm
VESA 75 × 75
Note: Maximum screw length for VESA mounting is 4 mm. Usage of
longer screws may lead to damage.
IP20
Powder-coated aluminum
0.4 kg
i.MX 6 DualLite Single ARM Cortex-A9 Core 1.0 GHz 512 kB L2 cache
Standard D-sub (9 Pin, female)
COM1: RS-232 with RTS/CTS
COM2: RS-422/RS-485
COM3: RS-485
1×RS-232 Rx/Tx with RTS/CTS and 1×RS-422 or 2×RS-485 or 1x
CAN2.0B.
M12 (8 pin, female)
Standard D-sub (9 Pin, female)
COM3: 1×RS-232 Rx/Tx with RTS/CTS
COM4: 1×RS-485
*Not supported for X2 control 7/10/15 web or X2 extreme 7/12/15
HP web.
10/100 Mbit Base-T (shielded RJ45 with LEDs)
10/100 Mbit Base-T (shielded RJ45 with LEDs)
1 × USB Host 2.0, max output current 500 mA
Supports up to USB 2.0 High Speed
1 × SD card
1.5 GB SSD (eMMC)
1 GB (DDR3)
128 kB
Yes
BR 2032 lithium battery
replaceable
5 W
Internal DC fuse, 3.14 AT, 5 × 20 mm
