3. Technical Data
Parameter
Front panel, W×H×D
Standalone mounting
Sealing
Frame material
Weight
CPU
Serial port COM A
Serial port COM B
Ethernet
USB
Flash memory
(application memory)
Memory RAM
NVRAM
Real time clock
Battery
Power consumption at
rated voltage
Fuse
Power supply
Operating temperature
Storage temperature
Relative humidity in
operation
2023-09
130 × 89 × 35 mm
VESA 75 × 75
Note: Maximum screw length for VESA mounting is 4 mm. Usage of
longer screws may lead to damage.
IP20
Plastic (PC+ABS)
0.3 kg
400 MHz ARM9
Standard D-sub (9 Pin, female)
COM1: 1×RS-232 Rx/Tx with RTS/CTS
COM2: 1×RS-422 or 1×RS-485 or 1×CAN2.0B
*Not supported for X2 pro 7/10/15web or X2 extreme 7/12/15 HP
web.
M12 (8 pin, female)
Standard D-sub (9 Pin, female)
COM3: 1×RS-232 Rx/Tx with RTS/CTS
COM4: 1×RS-485
*Not supported for X2 control 7/10/15 web or X2 extreme 7/12/15
HP web.
10/100 Mbit Base-T (shielded RJ45 with LEDs)
Supports up to USB 2.0 High Speed
256 MB SSD (NAND Flash)
Application memory 200 MB
128 MB (DDR2)
N/A
Yes
Lithium ion, 3V / 200mAh
3 W
Internal DC fuse, 2.0 AT
CE: The power supply must conform with the requirements
according to EN/IEC 60950 and EN/IEC 61558-2-4.
UL and cUL: The power supply must conform with the requirements
for class 2 power supplies.
-10°C to +50°C
-20°C to +60°C
5 - 85% non-condensation
