Quincy Compressor QOFT 20 Instruction Book page 54

12
14
16
18
Reference
8
9
10
11
12
13
14
15
52
Name
Automatic condensate outlet, intercooler
Automatic condensate outlet, aftercooler
Warning: under tension
Read Instruction book before starting the compressor
Lock out/ tag out
Before connecting the compressor electrically, consult the Instruction book for
the motor rotation direction (fixed speed compressors)
Torques for steel (Fe) or brass (CuZn) bolts
Consult the Instruction book for lubrication instructions
13
15
17
Instruction book
9829 3199 74
