The drains are connected to the side panel of the compressor as shown in the next figure:
Ref.
Designation
1
Automatic drain, aftercooler
2
Automatic drain, intercooler
9829 3199 74
Condensate drain connections
Ref.
3
4
Designation
Manual drain, intercooler
Manual drain, aftercooler
