Instruction book
Description
Reference Designation
(1) Add or select week
(2) Remove week
(3) Activate week timer
(4) Remaining running
time
(5) Add setting

3.10 Event history menu

Function
This screen is used to display the saved data in case of an alarm.
These submenus can be entered by tapping the icons.
Procedure
To enter the Event history menu screen:
1. Tap the Menu button
2. Tap the Event History icon
Description
9829 3199 74
Figure 17: Week timer menu screen
Function
If less than 4 weeks are programmed, tap the '+' button to add a
week.
Tap to remove a programmed week timer.
A selection screen pops up. The user can choose the correct week
by tapping '–' or '+' and can confirm by tapping 'V' or decline by
tapping 'X'.
A selection screen pops up. The user can change the remaining time
by tapping '–' or '+' and can confirm by tapping 'V' or decline by
tapping 'X'.
A selection screen pops up. The user can change the setting by
swiping up or down and confirm by tapping 'V' or decline by tapping
'X'.
Figure 18: Event history screen
