QOF 150V, QOF 175V, QOF 200V
Instruction book

Advertisement

loading
Need help?

Need help?

Do you have a question about the QOF 150V and is the answer not in the manual?

Questions and answers

Related Manuals for Quincy Compressor QOF 150V

Summary of Contents for Quincy Compressor QOF 150V

  • Page 1 QOF 150V, QOF 175V, QOF 200V Instruction book...
  • Page 3 Quincy QOF 150V, QOF 175V, QOF 200V Instruction book Original instructions COPYRIGHT NOTICE Any unauthorized use or copying of the contents or any part thereof is prohibited. This applies in particular to trademarks, model denominations, part numbers and drawings. 2023-06 No.
  • Page 4 Instruction book Table of contents Safety precautions......................5 ........................... 5 AFETY ICONS ......................5 AFETY PRECAUTIONS GENERAL ................... 6 AFETY PRECAUTIONS DURING INSTALLATION ....................7 AFETY PRECAUTIONS DURING OPERATION ................8 AFETY PRECAUTIONS DURING MAINTENANCE OR REPAIR General description...................... 10 ..........................10 NTRODUCTION ............................
  • Page 5 Instruction book 3.13 ..........................45 CCESS LEVEL Installation........................47 ........................47 IMENSION DRAWING ........................49 NSTALLATION PROPOSAL ....................51 LECTRIC CABLE SECTION AND FUSES ........................53 LECTRIC CONNECTION .......................54 UALITY OF SAFETY COMPONENTS ..........................54 ICTOGRAPHS Operating instructions....................56 ..........................56 NITIAL START ..........................60 EFORE STARTING ...........................63...
  • Page 6 Instruction book Servicing procedures....................73 .............................73 IR FILTERS .........................74 IL AND OIL FILTER CHANGE ..........................75 AFETY VALVES Problem solving......................76 ..........................76 ROBLEM SOLVING Technical data.......................79 ............................79 EADINGS ......................79 ETTINGS OF SAFETY VALVES ......................79 IRCUIT BREAKERS AND FUSES ........................80 EFERENCE CONDITIONS ............................ 80 IMITATIONS ..........................81 OMPRESSOR DATA...
  • Page 7 Instruction book Safety precautions Safety icons Explanation Danger to life Warning Important note Safety precautions, general General precautions 1. These recommendations apply to machinery processing or consuming air. Processing of any other gas requires additional safety precautions typical to the application, which are not included herein. In addition to normal safety rules, which should be observed with stationary air compressors and equipment, the following safety directions and precautions are of special importance.
  • Page 8 Instruction book 11. Any modification to the compressor should only be performed in agreement with Quincy and under supervision of authorized, competent personnel. 12. If any statement in this book, especially with regard to safety, does not comply with local legislation, the stricter of the two shall apply.
  • Page 9 Instruction book 13. Never drill holes in an electrical cabinet. Small metallic burrs can cause short-circuits in electrical components. 14. Make sure to avoid condensation on electrical components (e.g. cubicle, electronic regulator and frequency converter). 15. To preserve the protection degree of the electric cubicle and to protect its components from dust from the environment, it is absolutely necessary to use a proper cable gland when connecting the power supply cable to the compressor.
  • Page 10 Instruction book 4. Never operate the machine when there is a possibility of taking in flammable or toxic fumes, vapors or particles. 5. Never operate the machine below or in excess of its limit ratings. Check the Limitations or Compressor Data section for the ratings. 6.
  • Page 11 Instruction book 4. All maintenance work, other than routine attention, shall only be undertaken when the unit is stopped, the main power supply is switched off and the machine has cooled down. 5. Take precautions to ensure that the unit cannot be started inadvertently. 6.
  • Page 12 Instruction book General description Introduction General views view of QOF 150V-200V view of QOF 150V-200V 9829 3243 20...
  • Page 13 Instruction book Reference Name Air filter Inlet Valve Cooling fan Safety Valves CSt1 Compressor stage 1 CSt2 Compressor stage 2 Electrical cabinet Q-Control Touch Emergency Stop Gearbox Sight-glass Motor Coupling Motor Oil filter (for bearing lubrication) Pulsation damper, Compressor stage 1 Pulsation damper, Compressor stage 2 QOF compressors are air-cooled.
  • Page 14 Instruction book • Automatically restarts the compressor after voltage failure (ARAVF), when ARAVF mode is checked • Allows communication with external process control systems Kit for purge of dry air during standstill When frequent and long standstills occur, it's recommended to install a kit for purge of dry air to guarantee the life time of the oil-free screw elements.
  • Page 15 Instruction book Air system Flow diagram Flow diagram 9829 3243 20...
  • Page 16 Instruction book Reference Name Air to gearbox breathing system from air outlet From transducers, sensors To solenoid valves Air inlet Air outlet Air filter Inlet baffle grating Air hose Inlet valve Low pressure compressor stage Compensator Pulsation damper 1 Safety valve Intercooler Water separator 110a...
  • Page 17 Instruction book Reference Name Electric motor (compressor stages and oil pump) Motor coupling Electrical cabinet / cubicle Breather ESHH91 Q-Control - Indication of drive motor shutdown due to overload relay KSH48 Q-Control counter - oil filter service interval (8000 h) KSH49 Q-Control counter - oil service interval (16000 h) KSH93...
  • Page 18 Instruction book Reference Name TT18 Temperature sensor - Compressor stage 2 inlet TT21 Temperature sensor - Compressor stage 2 outlet TT29 Temperature sensor - Compressor outlet TT44 Temperature sensor - Bearing lubrication oil Solenoid valve - Load/unload Solenoid valve - Blow-off Description Air drawn through air filter (100) and inlet valve (103) is compressed in the low pressure compressor stage (104).
  • Page 19 Instruction book Flow diagram please check section Air System for entire legend Air cooling system The compressor unit is equipped with oil cooler (132), intercooler (108b) and aftercooler (116). Most heat exchangers are cooled by an air flow generated by a large axial fan (153) mounted on the air inlet on the roof.
  • Page 20 Instruction book Oil system Flow diagram Flow diagram please check section Air System for entire legend Description The compressor is equipped with 2 oil-free screw compressor stages so no air-oil contact is allowed during compression. However oil is used to: •...
  • Page 21 Instruction book Regulating system General The Q-Control controller keeps the net pressure within programmable pressure boundaries by automatically loading and unloading the compressor depending on the air consumption. During unloading If the air consumption is below the compressed air delivery, the net pressure increases. When the net pressure exceeds the upper limit of the working pressure (unloading pressure), solenoid valve (Y1) is de- energized.
  • Page 22 Instruction book The compressor runs unloaded causing zero air delivery. During loading Once the net pressure is below the lower limit of the working pressure (loading pressure), solenoid valve (Y1) is energized. This forces the plunger of solenoid valve (Y1) against spring force, opening the control air supply port to unloader (UA).
  • Page 23 Instruction book Additional attention Breather /PSTST air • Customer must install an extra air supply (press. 4 - 11 bar (g), normal capacity 30-70 l/min). • Air must be clean and dry. • Customer should install pressure gauges on the conduit where air is supplied (1), to ensure the pressure when the compressor starts.
  • Page 24 Instruction book 3. Q-Control Touch 3.1 Controller Figure 1: Q-Control Touch Introduction The controller has following functions: • Controlling the unit • Protecting the unit • Monitoring components subject to service • Automatic restart after voltage failure (ARAVF) Automatic control of the unit The controller maintains the net pressure between programmable limits by automatically loading and unloading the unit (fixed speed units) or by adapting the motor speed (units with frequency converter).
  • Page 25 Instruction book Protecting the unit Shutdown Several sensors are provided on the unit. If one of the measured signals exceeds the programmed shutdown level, the compressor will be stopped. Example: If the element outlet temperature exceeds the programmed shutdown level, the unit will be stopped.
  • Page 26 Instruction book Control panel Figure 2: Control Panel Parts and functions Reference Designation Function Touchscreen Shows the unit operating condition and a number of icons to navigate through the menu. The screen can be operated by touch. Warning sign Flashes in case of a shut-down, is lit in case of a warning condition.
  • Page 27 Instruction book Icons used Menu icons Menu Icon Menu Icon Menu Icon Data Status Inputs Outputs Counters Aux. Equipment Converters Parameters Service Service Overview Service Plan Service History Service functions Clean Screen Week Timer Week Remaining Running Time Event History Saved Data 9829 3243 20...
  • Page 28 Instruction book Menu Icon Menu Icon Menu Icon Machine Alarms Settings Regulation Control Parameters Aux. Equipment Converter(s) Parameters Auto Restart Controller Network Ethernet Settings Settings Settings CAN Settings Localisation Language Date/Time Units User Password Help Information Status icons Icon Description Motor Stopped 9829 3243 20...
  • Page 29 Instruction book Motor Stopped Wait Running Unloaded Manual Unload Running Unloaded Wait Running Loaded Failed to Load Running Loaded Wait Manual Stop Machine Control Mode, Local Machine Control Mode, Remote Machine Control Mode, LAN Automatic Restart After Voltage Failure Week Timer Active System icons Icon Description...
  • Page 30 Instruction book Antenna 50% Antenna 75% Antenna 100% Change between screens (indication) Energy recovery Element Drain(s) Analogue Output Menu Reset Auto Restart Filter(s) Cooler Valve(s) Power Meter Input icons Icon Description Pressure 9829 3243 20...
  • Page 31 Instruction book Temperature Special Protection Open Closed This chapter gives a general survey of available icons. Not all icons mentioned in this chapter are applicable to every machine. Main screen Function The Main screen is the screen that is shown automatically when the voltage is switched on. It is switched off automatically after a few minutes when there is no touch input.
  • Page 32 Instruction book Reference Designation Function Alarm button The alarm button can be tapped to show the current alarms. If an alarm occurs, the icon on the button will be red. Service button The service button can be tapped to show the service information.
  • Page 33 Instruction book Function Description Setpoints Several setpoints can be modified by tapping this icon. Control mode The control mode can be changed by tapping this icon. • Local control via start/stop buttons • Remote control via digital input(s) • LAN control via the network. When in Remote or LAN control, the start/stop buttons on the controller will not work.
  • Page 34 Instruction book Reference Designation Function Week timer Multiple Week timers and a Remaining running time can be set through this menu. Event history In case of an alarm, the Status information of the unit is saved and can be viewed through this menu. Machine settings Alarms settings, Regulation settings and Control parameters can be changed through this menu.
  • Page 35 Instruction book Data menu Function This screen is used to display the following submenus: • Status • Inputs • Outputs • Counters • Aux. Equipment These submenus can be entered by tapping the icons. Procedure To enter the Data menu screen: 1.
  • Page 36 Instruction book Figure 8: Status menu screen This menu shows the current status of the unit. If an alarm is active, it can be viewed by tapping the alarm message. To reset an alarm, tap the reset button (1). Before remedying, consult the Safety precautions.
  • Page 37 Instruction book Voltage-free outputs may only be used to control or monitor functional systems. They should NOT be used to control, switch or interrupt safety related circuits. Check the maximum allowed load on the label. Stop the unit and switch off the supply before connecting external equipment. Check the Safety precautions.
  • Page 38 Instruction book Procedure To enter the Service menu screen: 1. Tap the Menu button 2. Tap the Service icon Description Figure 13: Service menu screen Reference Designation Service Service functions (Only visible as advanced user) Clean screen Service menu Tap the Service icon to enter the Service menu. Figure 14: Service menu screen This menu shows the remaining Running Hours and the remaining Real Time Hours until the next service.
  • Page 39 Instruction book Service functions (Only visible as advanced user) Tap the Service Functions icon to enter the Service Functions menu. Figure 15: Service function screen Depending on the machine, this menu can have a different set of functions. Many of them are password protected, as they are only accessible for authorized personnel.
  • Page 40 Instruction book Description Figure 17: Week timer menu screen Reference Designation Function Add or select week If less than 4 weeks are programmed, tap the ‘+’ button to add a week. Remove week Tap to remove a programmed week timer. Activate week timer A selection screen pops up.
  • Page 41 Instruction book Description Figure 18: Event history screen Reference Designation Saved Data Saved data Tap the Saved Data icon to enter the Saved Data menu. Figure 19: Saved data screen Scroll through the items swiping up and down in this list. The event date and time is shown at the right side of the screen.
  • Page 42 Instruction book Procedure To enter the Machine settings menu screen: • Tap the Menu button • Tap the Machine Settings icon Description Reference Designation Alarms menu Regulation menu Control Parameters menu Aux. Equipment Parameters menu Auto Restart menu Alarms menu Tap the Alarms icon to enter the Alarms menu.
  • Page 43 Instruction book Setpoints or pressure bands can be modified through this menu. Modify a setting When tapping a list item, a selection screen pops up. The user can modify the setting by tapping ‘–’ or ‘+’ and can confirm by tapping ‘V’ or decline by tapping ‘X’. Change a selection When tapping a list item, a selection screen pops up.
  • Page 44 Instruction book Modify a setting When tapping a list item, a selection screen pops up. The user can modify the setting by tapping ‘–’ or ‘+’ and can confirm by tapping ‘V’ or decline by tapping ‘X’. Auto restart menu Tap the Auto restart icon to enter the Auto Restart menu.
  • Page 45 Instruction book Description Reference Designation Network Settings menu Localisation menu User Password menu Help menu Information menu Network settings menu Tap the Network Settings icon to enter the Network Settings menu. Ethernet Settings The list of Ethernet Settings is shown. When ethernet is turned off, the settings can be modified. CAN Settings The list of CAN Settings is shown.
  • Page 46 Instruction book Language The language setting of the controller can be modified through this menu. Date/Time The date and time settings of the controller can be modified through this menu. Units The units displayed can be modified through this menu. Modify a setting When tapping a list item, a selection screen pops up.
  • Page 47 Instruction book This menu can show a link to the web page of your supplier, a helpdesk phone number or other helpful information. Information menu Tap the Information icon to enter the Information menu. This menu shows information about the controller. 3.13 Access level Function Through this pop-up screen the access level settings can be viewed or changed.
  • Page 48 Instruction book Reference Designation Function User A basic set of parameters is visualized, no password required. Service A basic set of parameters can be modified, no password required. Full This access level is not accessible to end users. Decline Tap to decline the selected user level. Confirm Tap to confirm the selected user level.
  • Page 49 Instruction book Installation Dimension drawing Dimensions Dimension drawing 9829 3243 20...
  • Page 50 Instruction book Reference Name Front view Cooling air outlet Left side view Cooling air inlet Center of gravity Motor cooling air inlet Cooling air cubicle outlet Cooling air cubicle inlet Right side view Electrical cable entry for Fixed Speed Top view Compressed air outlet Openings for transportation 4 slotted holes for pulling unit out of container...
  • Page 51 Instruction book Installation proposal Compressor room example Installation proposal 9829 3243 20...
  • Page 52 Instruction book Reference Name Minimum free area to be reserved Ventilation proposal Description The compressor should only be moved or lifted as described in the section Initial start-up. Check balloon references in drawing for explanation underneath: 1. Install the compressor unit on a levelled floor (maximum tolerance 3 mm/m) suited for taking its weight.
  • Page 53 Instruction book cooling air ducts shouldn't exceed 4.35x10 psi. If ventilation proposal Alt. 1 is applied, the required ventilation capacity to limit compressor room temperature can be calculated as follows: Qv = 0.92 N/dT Qv = 2617.4N / dT Symbol Explanation Temperature increase in compressor room (in ˚C) Temperature increase in compressor room (in ˚F)
  • Page 54 Cable section and fuses for compressors designed to operate at ambient temperature up to 40 ˚C (104 ˚F) CSA/UL Mains + earth cable Max. fuse ratings gL/gG Compressor Voltage (V) (mm²) (UL) Type 2 (A) QOF 150V 3XAWG-4/0+AWG-1/0 3x 400 QOF 175V 3XAWG-4/0+AWG-1/0 3x 500 QOF 200V 2X(3XAWG-2/0+AWG-1/0) 3x 500...
  • Page 55 Attention For the selection of the correct cables, check: Electric cable size and fuses. Electric connection Electric diagram, QOF 150V-200V Name Customer's installation Main motor Fan motor Use the Lock Out Tag Out procedure to de-energise the machine for maintenance...
  • Page 56 Instruction book Quality of safety components When installing a remote emergency button or a motor contactor, the following B10d values are advised: • Emergency stop button: 500 000 • Main contactor: 1 333 333 Pictographs Q-Control Touch Reference Designation Function Touchscreen Shows the compressor operating condition and a number of icons to navigate through the menu.
  • Page 57 Instruction book Pictographs at other locations Reference Description Automatic condensate drain Automatic condensate drain for optional oil/water separator (type OSD) Manual condensate drain Stop the compressor before maintenance or repair Warning: under tension Read Instruction book before starting the compressor Switch off the voltage and depressurize the compressor before maintenance or repair Before connecting the compressor electrically, consult the Instruction book for the motor rotation direction...
  • Page 58 Instruction book Operating instructions Initial start-up Safety precautions The operator must apply all relevant Safety precautions. Outdoor operation The compressor is not designed for outdoor use. Even if the compressor is installed inside, measures must be taken if the ambient temperature might drop below 0˚C / 32 ˚F. If this is the case, consult your Customer Centre.
  • Page 59 Instruction book Transport spacers and bolts on the gear casing side A transport support (1) is fitted to the gear casing. Remove the support. On the motor side, the damper is secured by means of bolts/spacers (1). Please remove these before running the compressor.
  • Page 60 Instruction book Intercooler water separator: position of silica gel bags Remove flange (1) and remove the silica gel bags. Refit the flange. Oil circuit Position of oil level sight-glass Check the oil level in sight-glass (SG). 9829 3243 20...
  • Page 61 Instruction book Start-up Electrical cabinet of the compressor, QOF 150V-200V 1. Check that the voltage selecting wires on transformer T1 are connected correctly. An instruction label is provided. 2. Check that the electrical installation meets local regulations. 3. Check the gear casing oil level, air inlet/out and all connections on irregularities.
  • Page 62 Instruction book Reference Name IDOR Indicated Direction Of Rotation 6. Run the compressor for 2 minutes. 7. Stop the compressor and check the oil level. Once the compressor has stopped running and the oil level has stabilized, the oil level should be in the middle of the sight-glass (in the case of longer standstill, the oil level in the sight-glass may increase).
  • Page 63 Instruction book Oil level Oil system components The oil level must be in the middle of the sight-glass (SG) after stopping (in case of longer standstill, the oil level may increase in the sight-glass). Top up, if necessary, with the correct type of oil. 9829 3243 20...
  • Page 64 Instruction book Condensate drains Drain connections Reference Description Compressed air outlet Automatic drain, intercooler Manual drain, intercooler Automatic drain, aftercooler Manual drain, aftercooler 9829 3243 20...
  • Page 65 Instruction book Routine starting Procedure • The operator must apply all relevant safety precautions. • When the compressor is stopped and automatic operation sign (4) is alight, the compressor may start automatically. • If the start/stop timer is active, the compressor may start automatically, even if it was stopped manually.
  • Page 66 Instruction book Starting after emergency stop or shutdown Control panel Q-Control Touch Procedure Step Action Press the emergency stop button (if not yet done). Switch off the voltage and then depressurize the compressor. Remedy the fault. Unlock the emergency stop button by pulling it back. Reset the protection warning in the Q-Control Touch controller.
  • Page 67 Instruction book During operation Procedure • Before starting any maintenance or repairs, stop the compressor, wait until the compressor has stopped and open the isolating switch (customer's installation) to switch off the voltage to the compressor. • Repairs inside the start and speed regulation cabinet may only be carried out by Quincy.
  • Page 68 Instruction book Checking the display Control panel Q-Control Touch Procedure 1. Regularly check the display for readings and messages. Normally, the main display is shown. 2. Always check the display and remedy the trouble if warning sign (2) is alight or blinks. The display will show a service message if a service plan interval has been exceeded or if a service level for a monitored component has been exceeded.
  • Page 69 Instruction book Stopping Procedure Q-Control Touch The operator must apply all relevant Safety precautions. Frequently stopping the compressor using the emergency stop button may damage the compressor. Only use the emergency stop button in case of emergency. Step Action Press stop button (6). The compressor will stop and warning sign (2) will fade. Close the air outlet valve.
  • Page 70 Instruction book Taking out of operation Procedure Step Action Close the air outlet valve and stop the compressor. Switch off the voltage. On VSD compressors, wait at least 6 minutes as hazardous high voltage remains on the condensers of the start and speed regulation unit. Disconnect the compressor from the mains.
  • Page 71 Instruction book Maintenance Preventive maintenance schedule Safety precautions Before carrying out any maintenance, repair or adjustment work, stop the compressor and press the emergency stop button. Switch off the voltage and close the air outlet valve. Push the test buttons on top of the Electronic Water Drains (EWD). Open and lock the isolating switch.
  • Page 72 Instruction book Period Running hours Operation Daily Before stopping: • drain the aftercooler drain receiver • drain the intercooler drain receiver Weekly Check the oil level. See section Before starting. Weekly Drain condensate from the air receiver (if installed). Weekly Check for leaks.
  • Page 73 Instruction book Activities Level A Level B Level C Take and record all S.P.M. readings Inspect electrical contactors Check all electrical connections Overhaul check valve Airclean electrical cabinet cubicle with clean, dry air (max. 1 bar) Check condition of air intake chamber Grease main drive motor bearings According to motor data plate Motor greasing...
  • Page 74 Instruction book Storage after installation Run the compressor, e.g. twice a week, until warm. If the compressor is going to be stored without running from time to time, protective measures must be taken. Consult Quincy. Service kits Service kits comprise all parts needed for servicing components and offer the benefits of genuine Quincy parts while keeping the maintenance budget low.
  • Page 75 Instruction book Servicing procedures Air filters Location of the air filters Procedure The filters must be serviced regularly; consult section Preventive maintenance schedule. Never install damaged or clogged filters. Step Action Stop the compressor as described in section Stopping. Switch off the voltage and press the emergency stop button. Open the door of the air filter compartment.
  • Page 76 Instruction book Oil and oil filter change Oil system Procedure Step Action Run the compressor until warm. Stop the compressor as described in section Stopping. Switch off the voltage and press the emergency stop button. The filler plug and drain points are painted yellow. Remove filler plug (FC).
  • Page 77 Instruction book Safety valves Testing The valves can be tested on a separate compressed air line. If a valve does not open at the pressure specified in Settings of safety valves, consult Quincy. Never run the compressor without safety valves. No adjustments are allowed.
  • Page 78 Instruction book Problem solving Problem solving • The operator must employ safe working practices and observe all related local work safety requirements and regulations. • Maintenance must only be performed by authorized, trained and specialized personnel. • Before maintenance, repair work, adjustment or any other non-routine checks, stop the compressor, press the emergency stop button, close the air outlet valve and depressurize the air system.
  • Page 79 Instruction book Control panel Q-Control Touch Faults and remedies Condition Fault Remedy Compressor starts running, Pressure in air net is above Compressor will load when pressure in air but does not load after a delay pre-set loading pressure net drops to pre-set loading pressure time Loading solenoid valve Check and replace the valve as necessary...
  • Page 80 Instruction book Condition Fault Remedy Insufficient cooling air or cooling air temperature too Check and correct. high Condensate is not discharged from condensate traps during Drain/pipe clogged Check and correct operation Frozen drain piping Check and correct Venting lines not/badly Check and correct assembled Only on IC drain : intercooler...
  • Page 81 Opening pressure pressure Safety valve(s) for low-pressure compressors 3.7 bar(e) 54 psig Safety valve(s) for high-pressure compressors 9.3 bar(e) 135 psig Circuit breakers and fuses 60 Hz compressors Compressor Voltage F1/F2 F4/F5 QOF 150V QOF 175V QOF 200V 9829 3243 20...
  • Page 82 Instruction book Reference conditions Item Condition Absolute inlet pressure 1 bar(a) 14.5 psi Relative air humidity Air inlet temperature 20 ˚C 68 ˚F Nominal effective working pressure Compressor data. Cooling medium inlet temperature 20 ˚C 68 ˚F Limitations Pressure limitations Item Limit Limit...
  • Page 83 Compressor data Important note The values below are valid at reference conditions. See Reference conditions. The sound pressure level is measured according to ISO 2151: 2004 using ISO 9614-2. QOF 150V QOF 175V QOF 200V Unit Nominal working pressure bar(e)
