The TPS6120xEVM-179 is specially designed and optimized to operate from a
single-cell, two-cell, or three-cell alkaline, NiCd or NiMH, as well as a one-cell Li-Ion or
Li-polymer battery. It is also used in single-cell fuel cell or solar cell battery applications
where the input voltage is as low as 0.3V.
The TPS6120xEVM-179 operates from a 0.3V to 5.5V (starts up ≥ 0.5V) input rail and
provides a single output voltage up to 5.5V.
The TPS6120xEVM-179 has three orderable EVMs shown in
Build
EVM
-001
TPS61200EVM-179
-002
TPS61201EVM-179
-003
TPS61202EVM-179
...................................................................................................................
1
2
3
4
Schematic and Bill of Materials
1
Maximum Output Current vs VBAT
2
Efficiency vs Output Current
3
.....................................................................................................................
4
5
6
1
EVM Description
2
Specification Summary
3
Default Jumper Settings
4
SLVU207 - April 2007
Submit Documentation Feedback
Table 1. EVM Description
Note
Evaluates the TPS61200. Adjustable output voltage version which default output voltage is 3.3V.
Evaluates the TPS61201. Fixed 3.3V_output voltage version
Evaluates the TPS61202. Fixed 5.0V_output voltage version
........................................................................................................
.................................................................................................................
............................................................................................
.......................................................................................
................................................................................................
.........................................................................................................
.................................................................................................................
............................................................................................
.............................................................................................................
......................................................................................................
....................................................................................................
...............................................................................................................
TPS6120xEVM-179
Table
Contents
List of Figures
List of Tables
User's Guide
SLVU207 - April 2007
1.
TPS6120xEVM-179
2
2
5
7
4
4
5
6
6
7
1
2
2
8
1
Advertisement
Table of Contents
Related Manuals for Texas Instruments TPS6120 EVM-179 Series
Summary of Contents for Texas Instruments TPS6120 EVM-179 Series
-
Page 1: Table Of Contents
User's Guide SLVU207 – April 2007 TPS6120xEVM-179 The TPS6120xEVM-179 is specially designed and optimized to operate from a single-cell, two-cell, or three-cell alkaline, NiCd or NiMH, as well as a one-cell Li-Ion or Li-polymer battery. It is also used in single-cell fuel cell or solar cell battery applications where the input voltage is as low as 0.3V. -
Page 2: Introduction
www.ti.com Introduction Introduction This chapter contains background information for the TPS6120xEVM-179 evaluation module. Specifications Table 2 provides a summary of the TPS6120xEVM-179 performance specifications. All specifications are given for an ambient temperature of 25°C. Table 2. Specification Summary Voltage Range Current Range Build Specification... - Page 3 www.ti.com Setup and Operation JP2 - PS: This jumper enables or disables the power save mode at light load. Place a shunt across the VBAT and PS pins of JP2 to disable power save mode. Place a shunt across the GND and PS pins of JP2 to enable power save mode.
- Page 4 www.ti.com Setup and Operation Maxim um Output Current vs Input Voltage TPS61200/01_3.3Vout TPS61202_5Vout Input Voltage (V) Figure 1. Maximum Output Current vs VBAT Efficiency vs Output Current at Vin=1.8V, Pow er Save Disabled 100% TPS61202_5Vout TPS61200/01_3.3Vout 0.001 0.01 Output Current (A) Figure 2.
-
Page 5: Board Layout
www.ti.com Board Layout Board Layout This chapter provides board layout recommendations as well as figures of the EVM board layers. Board Layout Recommendations As for all switching power supplies, the layout is an important step in the design, especially at high peak currents and high switching frequencies. -
Page 6: Top Layer
www.ti.com Board Layout Figure 4. Top Layer Figure 5. Bottom Layer TPS6120xEVM-179 SLVU207 – April 2007 Submit Documentation Feedback... -
Page 7: Tps6120Xevm-179 Schematic
www.ti.com Schematic and Bill of Materials Schematic and Bill of Materials Schematic Figure 6. TPS6120xEVM-179 Schematic SLVU207 – April 2007 TPS6120xEVM-179 Submit Documentation Feedback... -
Page 8: Bill Of Materials
www.ti.com Schematic and Bill of Materials Bill of Materials Table 4. Bill of Materials Count RefDes Value Description Size Part Number -001 -002 -003 10µF Capacitor, Ceramic, 10V, X5R, 10% 0805 GRM21BR61A106KE19L muRata C2,C3 0.1µF Capacitor, Ceramic, 16V, X7R, 10% 0603 C1608X7R1C104K Open... - Page 9 EVALUATION BOARD/KIT IMPORTANT NOTICE Texas Instruments (TI) provides the enclosed product(s) under the following conditions: This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR EVALUATION PURPOSES ONLY and is not considered by TI to be a finished end-product fit for general consumer use. Persons handling the product(s) must have electronics training and observe good engineering practice standards.
- Page 10 TI as compliant with ISO/TS 16949 requirements. Buyers acknowledge and agree that, if they use any non-designated products in automotive applications, TI will not be responsible for any failure to meet such requirements. Following are URLs where you can obtain information on other Texas Instruments products and application solutions: Products...
