E R R O R I N D I C A T I O N ( V - S H A P E D L E D )
F A U LT S T A T U S
Control pilot fault
Input UVP (Under Voltage Protection)
Input OVP (Over Voltage Protection)
OTP (Over Temperature Protection)
OCP (Over Current Protection)
Ground fault
Relay fault
RCD (Residual Current Device) Abnormal
RCD self-test fault
1 flash followed by 2 seconds off, repeating
2 flashes followed by 2 seconds off, repeating
3 flashes followed by 2 seconds off, repeating
4 flashes followed by 2 seconds off, repeating
5 flashes followed by 2 seconds off, repeating
6 flashes followed by 2 seconds off, repeating
7 flashes followed by 2 seconds off, repeating
Blinking
Solid
R E D L E D
