Management Ethernet Port Pinouts

Table 13: Console Port Pinouts
Pin
1
2
3
4
5
6
7
8
Management Ethernet Port Pinouts
This following table summarizes the Management Ethernet port pinouts:
Table 14: Management and PTP Ethernet Port Pinouts
Pin
1
2
3
4
5
6
7
8

Timing Port Pinouts

The platform is capable of receiving or sourcing timing signals of 1 PPS & 10 MHz. These interfaces are
provided by two mini-coax 50-Ohm, 1.0/2.3 DIN series connector on the front panel. Similarly there are two
mini-coax 50-Ohm connectors provided in the front panel to output this 1PPS and 10MHz.
This table below summarizes the timing port pinouts:
Cisco Network Convergence System 540 Large Density Routers Hardware Installation Guide
72
Signal Name Direction
ACONS-TX Output
NC NA
CONS-TX Output
Gnd NA
Gnd NA
CONS-RX Input
ACONS-RTX Input
NC NA
Signal Name
TRP0+
TRP0-
TRP1+
TRP1-
TRP2+
TRP2-
TRP3+
TRP3-
Appendix
Description
Aux Consoles transmit output,
RS232
NA
Console RS232 transmit
Ground
Ground
Console RS232 receive
Aux Consoles receive input, RS232
NA
