277832-YIM-E-0610
CONDENSATE
DRAIN 3/4" NPTF
Figure 4: Dimensions Front and Bottom
Figure 5: Dimensions Back and Bottom
8
HIGH VOLTAGE
CONN. 1-3/32"
DIA. KNOCKOUT
26-3/4
AIR OPENING
*CONDENSER
COIL
BOTTOM SUPPLY
AIR OPENING
1-3/4
15
15
28-9/16
11-7/8
8-7/8
6
SIDE SUPPLY
14-1/2
28-3/8
1-3/4
3-1/2
1-3/4
19-1/4
FRONT
GAS SUPPLY 1-5/8"
DIA. KNOCKOUT (1/2"
NPTF CONNECTION)
LOW VOLTAGE
CONN. 7/8" DIA.
KNOCKOUT
4-5/8
14-1/2
BACK
3-3/8
SIDE RETURN
AIR OPENING
14-1/2
4-1/4
4
15
BOTTOM RETURN
AIR OPENING
