Table 7: Single Stage Physical Data
Component
Nominal Tonnage
ARI COOLING PERFORMANCE
Gross Capacity @ ARI A point (Btu)
ARI net capacity (Btu)
EER
SEER
Nominal CFM
System power (KW)
Refrigerant type
Refrigerant charge (lb-oz)
ARI HEATING PERFORMANCE
Heating model
Heat input (K Btu)
Heat output (K Btu)
AFUE %
Steady state efficiency (%)
No. burners
No. stages
Temperature Rise Range (ºF)
Gas Limit Setting (ºF)
Gas piping connection (in.)
DIMENSIONS (inches)
Length
Width
Height
OPERATING WT. (lbs.)
COMPRESSORS
Type
Quantity
CONDENSER COIL DATA
Face area (Sq. Ft.)
Rows
Fins per inch
Tube diameter (in.)
Circuitry Type
EVAPORATOR COIL DATA
Face area (Sq. Ft.)
Rows
Fins per inch
Tube diameter
Circuitry Type
Refrigerant control
CONDENSER FAN DATA
Quantity
Fan diameter (Inch)
Type
Drive type
No. speeds
Number of motors
Motor HP each
RPM
Nominal total CFM
DIRECT DRIVE EVAP FAN DATA
Quantity
Fan Size (Inch)
Type
Motor HP each
RPM
Frame size
FILTERS
Quantity - Size
14
DNY024 DNY036
2.0 3.0
24.3 35.6
23.8 34.6
11.1 11.0
14.0 14.0
800 1200
2.1 3.1
R-410A R-410A
5-0 7-8
36 56 36 56
45 70 45 70
36 56 36 56
80.0 80.0 80.0 80.0
80 80 80 80
2 3 2 3
1 1 1 1
25-55 30-60 25-55 25-55
140 160 140 160
1/2 1/2
49 1/8 49 1/8
47 1/4 47 1/4
33 1/2 33 1/2
400 440
Scroll 2-spd Scroll 2-spd
1 1
11.7 11.7
1 2
20 16
3/8 3/8
Interlaced Interlaced
3.4 3.4
2 3
15 13
3/8 3/8
Interlaced Interlaced
TXV TXV
1 1
22 22
Prop Prop
Direct Direct
1 1
1 1
1/4 1/4
1100 1100
2400 2400
1 1
10 x 8 11 x 10
Centrifugal Centrifugal
1/2 3/4
Variable Variable
48 48
1 - 20 x 20 x 1 1 - 20 x 20 x 1
Models
DNY048
4.0
50.0
48.0
11.0
14.0
1550
4.4
R-410A
9-8
72 65 90 110
90 80 108 135
72 64 87 108
80.0 80.0 80.0 80.0
80 80 80 80
4 3 4 5
1 1 1 1
30-60 25-55 35-65 45-75
160 150 175 160
1/2
49 1/8
47 1/4
41 1/2
500
Scroll 2-spd
1
14.7
2
20
3/8
Interlaced
4.4
3
16
3/8
Interlaced
TXV
1
22
Prop
Direct
1
1
1/3
1100
3000
1
11 x 10
Centrifugal
1
Variable
48
2 - 20 x 12 x 1
DNY060
5.0
59.6
56.5
10.6
13.7
1650
5.4
R-410A
10-0
65 90 110
80 108 135
64 87 108
80.0 80.0 80.0
80 80 80
3 4 5
1 1 1
25-55 35-65 45-75
150 175 160
1/2
49 1/8
47 1/4
41 1/2
540
Scroll 2-spd
1
14.7
2
20
3/8
Interlaced
4.4
3
16
3/8
Interlaced
TXV
1
22
Prop
Direct
2
1
1/3
850/1100
3000
1
11 x 10
Centrifugal
1
Variable
48
2 - 20 x 12 x 1
