INSTALLATION MANUAL
R-410A
OUTDOOR SPLIT-SYSTEM
AIR CONDITIONING
MODELS: 16 SEER - CZF / AC6B / AL6B SERIES
2 TO 5 TONS
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
UNIT INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
EVACUATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
ELECTRICAL CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . 5
Typical Installation with Required Clearances . . . . . . . . . . . . 3
Tubing Hanger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Underground Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Heat Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Typical Field Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Communications Harness Connection . . . . . . . . . . . . . . . . . . 6
CFM Selection Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Air Handler or Furnace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
R-410A Saturation Properties . . . . . . . . . . . . . . . . . . . . . . . . 12
TEST Input Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Operational Mode Display . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Status Code Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
SECTION I: GENERAL
The outdoor units are designed to be connected to a matching indoor
coil with sweat connect lines. Sweat connect units are factory charged
with refrigerant for the highest sales volume evaporator plus 15 feet of
field supplied lines.
Matching indoor coils are available with a thermal expansion valve or
an orifice liquid feed sized for the most common usage. The orifice size
and/or refrigerant charge may need to be changed for some system
combinations, elevation differences, or total line lengths. See tabular
data sheet provided in unit literature packet for charge requirements.
Refer to Application Data covering "General Piping Recommendations
and Refrigerant Line Length" (Part Number 247077).
TABLE OF CONTENTS
SYSTEM CHARGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
INSTRUCTING THE OWNER . . . . . . . . . . . . . . . . . . . . . . . 11
AC CONTROL BOARD FUNCTIONALITY . . . . . . . . . . . . . 12
WIRING DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
LIST OF FIGURES
or Furnace using Communicating Interface Control . . . . . . . . 7
(with AC control) - PSC Air Handler . . . . . . . . . . . . . . . . . . . . 8
(with AC control) - VS Air Handler . . . . . . . . . . . . . . . . . . . . . 9
(with AC control) - Modulating Furnace . . . . . . . . . . . . . . . . 10
Wiring Diagram (2 - 4 Ton) . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Wiring Diagram (5 Ton) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
LIST OF TABLES
Status Code Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Operational Fault Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Sensor or Switch Fault Codes . . . . . . . . . . . . . . . . . . . . . . . 14
Wiring Related Fault Codes . . . . . . . . . . . . . . . . . . . . . . . . . 14
SECTION II: SAFETY
This is a safety alert symbol. When you see this symbol on
labels or in manuals, be alert to the potential for personal
injury.
Understand and pay particular attention to the signal words DANGER,
WARNING, or CAUTION.
DANGER indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation, which, if not
avoided may result in minor or moderate injury. It is also used to
alert against unsafe practices and hazards involving only property dam-
age.
ISO 9001
Certified Quality
Management System
562156-UIM-A-0610
Advertisement
Table of Contents
Related Manuals for Johnson Controls 16 Seer-CZF Series
Summary of Contents for Johnson Controls 16 Seer-CZF Series
-
Page 1: Table Of Contents
INSTALLATION MANUAL R-410A OUTDOOR SPLIT-SYSTEM AIR CONDITIONING ISO 9001 Certified Quality Management System MODELS: 16 SEER - CZF / AC6B / AL6B SERIES 2 TO 5 TONS TABLE OF CONTENTS GENERAL ........1 SYSTEM CHARGE . -
Page 2: Unit Installation
Never leave a suc- observed to ensure a system that will give maximum performance tion-line drier in the system longer than 50 hours of run time. with minimum service. Johnson Controls Unitary Products... -
Page 3: Typical Installation With Required Clearances
Never install a suction-line filter drier in the liquid line of an R-410A system. Failure to follow this warning can cause a fire, injury or Filter-Drier death. Apply with Models Source 1 Part No. 029-22195-000 Johnson Controls Unitary Products... -
Page 4: Tubing Hanger
Do not leave the system open to the atmosphere. Unit damage could occur due to moisture being absorbed by the POE oil in the system. This type of oil is highly susceptible to moisture absorp- tion. Johnson Controls Unitary Products... -
Page 5: Evacuation
The complete connection diagram and schematic wiring label is located on the inside surface of the unit service access panel. In all cases, mount the TXV bulb after vapor line is brazed and has had sufficient time to cool. Johnson Controls Unitary Products... -
Page 6: Typical Field Wiring
NOTICE To eliminate erratic operation, seal the hole in the wall at the ther- mostat with Pergamum or equivalent to prevent air drafts affecting the operation of the thermostat. Johnson Controls Unitary Products... -
Page 7: Cfm Selection Board
Furnace using Communicating Interface Control desired set point of the dehumidification control, the variable speed blower motor will operate at lower speed until the dehumidification con- trol is satisfied. A 40-60% relative humidity level is recommended to achieve optimum comfort. Johnson Controls Unitary Products... -
Page 8: Thermostat Wiring - Single Stage Air Conditioner (With Ac Control) - Psc Air Handler
IRU : DQG : HOHFWULF WR ³(/(&´ KHDW VWDJLQJ RSWLRQV 3DUW 1XPEHUV 3DUW 1XPEHU 3DUW 1XPEHU /HJDF\ 6+8 FIGURE 10: Thermostat Wiring – Single Stage Air Conditioner (with AC control) – PSC Air Handler Johnson Controls Unitary Products... -
Page 9: Thermostat Wiring - Single Stage Air Conditioner (With Ac Control) - Vs Air Handler
-XPSHU PXVW EH VHW IRU : DQG : HOHFWULF WR ³(/(&´ KHDW VWDJLQJ RSWLRQV 3DUW 1XPEHU 3DUW 1XPEHU 3DUW 1XPEHU 6+8 FIGURE 11: Thermostat Wiring – Single Stage Air Conditioner (with AC control) – VS Air Handler Johnson Controls Unitary Products... -
Page 10: Thermostat Wiring - Single Stage Air Conditioner (With Ac Control) - Modulating Furnace
LI KXPLGLVWDW LV WR EH XVHG -XPSHU PXVW EH VHW WR ³*$6´ 3DUW 1XPEHU¶V 3DUW 1XPEHU 3DUW 1XPEHU 6+8 FIGURE 12: Thermostat Wiring – Single Stage Air Conditioner (with AC control) – Modulating Furnace Johnson Controls Unitary Products... -
Page 11: System Charge
Use a brush, vacuum cleaner attachment, or other the matched coil and follow guidelines in this instruction. suitable means. 2. The outdoor fan motor is permanently lubricated and does not require periodic oiling. Johnson Controls Unitary Products... -
Page 12: R-410A Saturation Properties
The control includes a TEST input connector that can be used for vari- tion (Y1 input signal energized). ous testing functions during installation and service. Table 2 summa- rizes the behavior of the control when the two TEST pins are connected. Johnson Controls Unitary Products... -
Page 13: Test Input Functionality
Control normal operation – with active communication present System is active and presently communicating successfully. 0.1 sec OFF Control powered – without active communication present System has 24 VAC present and the microprocessor is active. 2s ON / 2s OFF Johnson Controls Unitary Products... -
Page 14: Operational Fault Codes
(24 VAC) must be cycled to the control for the control to sense TABLE 8: Wiring Related Fault Codes the wiring change and clear the lockout condition. LED1 Flash LED2 Flash Description Code (Red) Code (Green) Compressor contactor miswire Y2 present without Y1 Johnson Controls Unitary Products... -
Page 15: Uim-A
It is used to display outdoor temperature to the home owner via the communicating thermostat. • Has no effect on operation. • Not required for operation, but a fault code will be displayed when sensor is not connected or if sensor is shorted. Johnson Controls Unitary Products... -
Page 16: Wiring Diagram
562156-UIM-A-0610 SECTION IX: WIRING DIAGRAM FIGURE 13: Wiring Diagram (2 - 4 Ton) Johnson Controls Unitary Products... -
Page 17: Wiring Diagram (5 Ton)
562156-UIM-A-0610 FIGURE 14: Wiring Diagram (5 Ton) Johnson Controls Unitary Products... - Page 18 NOTES Subject to change without notice. Published in U.S.A. 562156-UIM-A-0610 Copyright © 2010 by Johnson Controls, Inc. All rights reserved. Supersedes: Nothing Johnson Controls Unitary Products 5005 York Drive Norman, OK 73069...
