277832-YIM-E-0610
In Canada:
1. Canadian Electrical Code, CSA C22.1
2. Installation Codes, CSA - B149.1.
3. Local plumbing and waste water codes, and
4. Other applicable local codes.
Refer to unit application data found in this document.
After installation, gas fired units must be adjusted to obtain a
temperature rise within the range specified on the unit rating plate.
Blow-Through Design With
Reliable Aluminized Steel
Tubular Heat Exchangers
Rear and Bottom Return Air
and Supply Airduct Openings
Removable Base Rails
Direct Drive Blower Motor With
Figure 1: Component Location
Table 1: Unit Limitations
Size
(Tons)
024
(2.0)
036
(3.0)
048
(4.0)
060
(5.0)
4
Long Lasting Powder
Paint Finish
Heavy Gauge
Slide-Out Blower Assembly
Power Draft Motor
Unit Voltage
208/230-1-60
208/230-1-60
208/230-3-60
460-3-60
208/230-1-60
208/230-3-60
460-3-60
208/230-1-60
208/230-3-60
460-3-60
If components are to be added to a unit to meet local codes,
they are to be installed at the dealer's and/or customer's
expense.
Size of unit for proposed installation should be based on heat
loss/heat gain calculation made according to the methods of Air
Conditioning Contractors of America (ACCA).
This furnace is not to be used for temporary heating of buildings
or structures under construction.
Condenser Fan Motor
Highly Efficient Enhanced Copper
Tube/Aluminum Fin Evaporator Coil
Self-Diagnostic Controls
Automatic Gas Valve (1/2" - NPTF)
High Voltage
Terminal Block

Unit Limitations

Applied Voltage
Min Max
187 252
187 252
187 252
432 504
187 252
187 252
432 504
187 252
187 252
432 504
Direct Drive
Highly Efficient Enhanced Copper
Tube/Aluminum Fin Condenser Coil
Decorative Protective
Coil Guard
High Efficiency
Compressor Rigidly
Mounted
Pilot Assembly
High Grade Aluminized In-Shot Burners
Low Voltage Terminal Block
Outdoor DB Temp
Max (°F)
115
115
115
115
115
115
115
115
115
115
