Type
CONTACT TIP M8 CUCRZR
D0.8
CONTACT TIP M8 CUCRZR
D0.9
CONTACT TIP M8 CUCRZR
D1.0
SD M8X30 1,2MM CUCRZR
CONTACT TIP M8 CUCRZR
D1,4
CONTACT TIP M8 CUCRZR
D1,6
CONTACT TIP M8 CUCRZR
D2,0
CTH 500W M8
GASNOZZ NW15,5 15.5MM
72.5MM
RGN 500W S3 K15/-1.1
75.5mm
SPLS 500W HD
LST RED EWM RT 3603.20m
0.8-1.2mm
LST RED EWM RT 3605.00m
0.8-1.2mm
LST BLUE EWM RT
3603.20m 1.4-1.6mm
LST BLUE EWM RT
3605.00m 1.4-1.6mm
NLS RED 195mm 1.0-1.2mm
0/22DG
NLS 0/22° 1,4-1,6MM
L=195MM
NLS RED 217mm 1.0-1.2mm
35/45DG
NLS BLUE 217mm 1.2-1.6mm
35/45DG
NLB AL 195mm 0.8-1.0mm
0/22DG
NLB AL 195mm 1.2-1.6mm
ROB TS
NLB AL 217mm 0.8-1.0mm
ROB TS
NLB AL 217mm 1.2-1.6mm
ROB TS
099-500073-EW501
22.02.2023
Designation
Contact tip
Contact tip
Contact tip
Contact tip
Contact tip
Contact tip
Contact tip
Nozzle holder, M8
Gas nozzle, bottle-shape
Gas nozzle, bottle-shape
Splash protection, high-temperature-resistant
Steel liner
Steel liner, red
Steel liner
Steel liner, blue
Liner BSLred for steel, 0°/22°
BSLblue liner for steel 0°/22°
Liner BSLred for steel, 35°/45°
BSLblue liner for steel 35°/45°
Brass liner for aluminium 0°/22°
Brass liner for aluminium 0°/22°
Brass liner for aluminium 35°/45°
Brass liner for aluminium 35°/45°
Replaceable parts
General
Item no.
094-005409-00000
094-005410-00000
094-005225-00000
094-013113-00000
094-005411-00000
094-005412-00000
094-005413-00000
094-009896-00500
094-010220-00500
094-016512-00500
094-013862-00000
094-011627-00500
094-012655-00500
094-010579-00500
094-012640-00500
094-016521-00500
094-016522-00500
094-016523-00500
094-016524-00500
094-016525-00000
094-016526-00000
094-016527-00000
094-016528-00000
