Design and function
Wire feed
Item Symbol
1
2
3
4
5
The pressure force of the pressure roller has been factory pre-set. Do not
change the contact pressure by bending leaf spring, but only via the fine
adjustment, if required.
• Remove cap
• Insert the wire in the wire feed unit as specified by the manufacturer.
• Relieve the leaf spring tension and swing out the pressure roller.
• Press button, wire inching.
• Assemble by following these steps in the reverse order
40
Description 0
Pressure roller
Changeable body MTR500W > see 5.5.1 chapter
Wire inching key button
Flat spring
Slotted screw
