Design and function
Configure welding torch
Item Symbol
1
2
3
4
5
6
7
8
9
10
11
12
13
5.5.4

Guide spiral

Observe permissible torque!
Insert the grinded end towards the contact tip holder to ensure tight fit with the contact tip.
Always make sure the hose package is straight when replacing the wire guide.
28
Description 0
Gas nozzle
Contact tip
Contact tip holder
Torch neck 45°
Crown nut
O-ring
Collet
Combined liner
Euro central connection
Connecting sleeve
New combined liner
Liner sharpener > see 9 chapter
Guiding tube for welding torch Euro torch connector
Figure 5-15
