Machine description – quick overview

Welding torch connection

4.3 Welding torch connection
4.3.1

Euro central connection

Item Symbol
1
2
3
4
5
16
Description 0
Euro central connection
Welding current and shielding included.
Air-blast hose
Quick connect coupling, red (coolant return)
Control lead cable plug
Quick connect coupling, blue (coolant supply)
Figure 4-3
099-500073-EW501
22.02.2023
