Hardware Installation and Reference Guide
3. LEDs
Table 1-10
Silkscreen
Label
Status
1F to 53F
(excluding
multiples
of 3)
3F to 54F
(only
multiples
of 3)
LEDs
LED Description
Solid green: The expansion module is operating normally.
Blinking green: The expansion module is starting up.
Expansion
Continuous blinking indicates an anomaly.
module
Solid red: The expansion module is resetting or not
status LED
functioning properly.
Off: The expansion module is not receiving power.
Solid green: The port has made a successful 100/200 Gbps
link.
Blinking green: The port is sending and receiving traffic at
100/200 Gbps.
Off: No link is detected for the port.
QSFP28
port LED
Solid green: The port has made a successful 100/200 Gbps
link.
QSFP56
Blinking green: The port is sending and receiving traffic at
port LED
100/200 Gbps.
Off: No link is detected for the port.
Caution
The QSFP28 port can be split or aggregated, as shown in
Table 1-9.

When a port split from the QSFP28 port has made a
successful link, the LED is solid green. When a port
split from the QSFP28 port is sending and receiving
traffic, the LED is blinking green.

If the aggregated QSFP28 port is available, the LED
indicates the status of the 200GE QSFP28 port. If
not, the LED is off.
