- Page 1 Solar 440W 3.84kWh Extension Solution VERSION A0...
-
Page 2: Before Getting Started
Renogy is not responsible or liable for any failure, damage, or injury resulting from repair attempts by unqualified personnel, improper installation, or inappropriate operation. -
Page 3: System Wiring
100Ah Lithium Inverter Battery 300A ANL Fuse Starter Battery 2. Get to Know Renogy Solar 440W 3.84kWh Extension Solution Battery █ 100Ah Lithium Battery × 3 4 AWG 1 ft Battery 4/0 AWG 5 ft Battery Cables Interconnect Cable × 4 (Battery to Busbar) ×... -
Page 4: Solar Panels
Solar Panels █ × 4 × 4 × 8 × 4 × 8 × 4 × 8 220W Bifacial Solar Panel × 2 Solar Panel Mounting Z Bracket × 2 20A Solar Connector Fuse × 2 Solar Branch Connector (MMF + FFM Pair) × 1 Solar Entry Gland ×... -
Page 5: Battery Monitor
Battery Monitor █ RMS-LFPS Monitoring Screen for Smart RJ45 Communication Cable × 2 Lithium Battery × 1 4P Busbar Pair █ 4P Busbar Pair (Red and Black) × 1 3. Required Tools & Accessories Insulating Phillips Wrench Wrench Ground Fault Circuit Gloves Screwdriver (#2) (7/16 in) - Page 6 4. How to Install the Solar Panel Mounting Z Bracket 70.8-106.2 in·lbs (8-12 N•m) Solar Panel Solar Panel Note: To ensure optimal performance of the bifacial solar panels, you can install the panels with a Solar Panel Flat Roof Tilt Mount. For details, see renogy.com/solar-panel-flat-roof-tilt-mount/. — 06 —...
- Page 7 5. How to Install the Solar Entry Gland 12 AWG 10 ft Solar Panel to Charge Controller Adapter Kit Run the Adapter Kit Drill a hole in the RV roof. through the hole. Do not move the entry Apply MS gland before the MS adhesive to adhesive is fully dry.
- Page 8 6. How to Install the 3/8 in Lugs (M8 Ring Terminals) 0.4 in (10 mm) 12 AWG 10 ft Solar Panel to Battery Charger Adapter Kit — 08 —...
- Page 9 Step 1. Connect the Batteries in Parallel Step-1 Ensure that all batteries are in shelf mode. Shelf Active Mode Mode 100Ah Lithium Batteries RS485 UP 4 AWG 1 ft Battery Interconnect Cables Step-2 Connect the batteries in parallel. 88.5 in·lbs (10 N·m) 88.5 in·lbs (10 N·m)
- Page 10 Step 2. Connect the Battery Charger to the Batteries Note: Connect the batteries first and then the solar panels to avoid irreversible damage to the battery charger. 50A DC-DC Battery Charger with MPPT STEP-1 Install the cables on the battery charger. 4 AWG 8 ft Double Ring Tray Cables STEP-2 Install a 60A ANL fuse...
- Page 11 Step 3. Connect the Bluetooth Module to the Battery Charger BT-2 Bluetooth Module POWER LINK BT-2 Bluetooth Module 50A DC-DC Battery Charger with MPPT My Renogy My Renogy HUB Mode RBC50D1S-G1 Searching for device Please make sure your phone’s Bluetooth is turned on properly; the device is running properly and the device’s Bluetooth is...
- Page 12 Step 4. Connect the Solar Panels to the Battery Charger Note: Connect the batteries first and then the solar panels to avoid irreversible damage to the battery charger. STEP-1 Install 20A Solar Connector Fuses 220W Bifacial Solar Panels 20A Solar Connector Fuse STEP-2 Connect the solar panels in parallel.
- Page 13 Step 5. Connect the Battery Charger to the RV Starter Battery 50A DC-DC Battery Charger with MPPT STEP-1 Install the cable on the battery charger. 4 AWG 8 ft Double Ring STEP-2 Install the cable on the RV starter battery. Tray Cables Signal Wire...
- Page 14 Step 6. Install the Inverter Charger and Loads DC Input Wiring █ Busbar Pair STEP-1 Install the cables on the busbar pair. 4/0 AWG 1 ft ANL Fuse Cable STEP-2 Install a 300A ANL fuse 300A Fuse 4/0 AWG 5 ft Battery 70.8 in·lbs Inverter (8 N·m)
-
Page 15: Ac Output Wiring
AC Output Wiring █ STEP-1 Install the bare wires on the inverter charger. 3000W PCL1 Inverter Charger AC Output Terminal Block Open Closed 1 in (25 mm) Bare Wires (8 AWG) STEP-2 Install the bare wires on the GFCI. Ground Fault Circuit Interrupter... - Page 16 Step 7. Communication and Monitoring Wiring Step-1 Ensure that all batteries are in active mode. Monitoring Screen Active Shelf for Smart Lithium Battery Mode Mode RMS-LFPS Step-2 Install the monitoring screen on the first battery. RMS-LFPS RJ45 Communication Cable RS485 UP Step-3 Install the communication cables on the batteries.
- Page 17 To explore more possibilities of solar systems, visit Renogy Learning Center at: renogy.com/learning-center For technical questions about your product in the U.S., contact the Renogy technical support team through: renogy.com/contact-us 1(909)2877111 For technical support outside the U.S., visit the local website below: Canada ca.renogy.com...
-
Page 18: Safety Information
Safety Information General z Wear proper protective equipment and use insulated tools during installation and operation. Do not wear jewelry or other metal objects when working on or around the devices. z Keep the devices out of the reach of children. z Do not dispose of the devices as household waste. - Page 19 Save 105 gallons of water from being consumed Renogy Power PLUS Renogy Power Plus allows you to stay in the loop with upcoming solar energy innovations, share your experiences with your solar energy journey, and connect with like-minded people who are changing the world in the Renogy Power Plus community.
