- Page 1 Renogy Pure Sine Wave Inverter 700W/1000W/2000W/3000W VERSION A2 USER MANUAL...
- Page 3 All information in the user manual is subject to copyright and other intellectual property rights of Renogy and its licensors. The user manual may not be modified, reproduced, or copied, in whole or in part, without the prior written permissions of Renogy and its licensors.
-
Page 5: Table Of Contents
Table of Contents Important Safety Information ......................01 Symbols Used .......................... 01 General Safety Information ...................... 01 Introduction ............................. 03 General Information ......................... 03 Key Features ..........................03 Pure Sine Wave ........................04 Package Contents .......................... 05 Product Overview ........................... 06 700W Inverter ........................... - Page 6 1000W Inverter ........................27 2000W Inverter ........................28 3000W Inverter ........................28 Specifications ..........................29 General Data ..........................29 Electrical Data .......................... 29 Wired Remote Data ........................30 Technical Support ........................... 31...
-
Page 7: Important Safety Information
Important Safety Information Symbols Used General Safety Information Important Safety Information The user manual provides important installation, operation, and maintenance instructions for 12V 700W/1000W/2000W/3000W Pure Sine Wave Inverter. Please read the user manual carefully before installation and operation and save it for future reference. Failure to observe the instructions or precautions in the user manual can result in electrical shock, serious injury, or death, or can damage the inverter, potentially rendering it inoperable. - Page 8 Important Safety Information Symbols Used General Safety Information Do not let the positive (+) and negative (-) terminals of the battery touch each other. Use only deep-cycle sealed lead-acid, flooded, gel, or lithium batteries. Risk of explosion! Never install the inverter in a sealed enclosure with flooded batteries! Do not install in a confined area where battery gases can accumulate.
-
Page 9: Introduction
The inverter converts DC Power stored in batteries into usable AC Power for appliances. The advanced Renogy pure sine wave technology will allow you to power just about any AC appliance without risk of damage to even your most sensitive equipment. -
Page 10: Pure Sine Wave
Introduction General Information Key Features Pure Sine Wave Pure Sine Wave The inverter outputs a pure sine wave similar to the waveform of the grid power. In a pure sine wave, the voltage rises and falls in a smooth fashion with very low harmonic distortion and cleaner utility-like power. -
Page 11: Package Contents
USER MANUAL Wired Remote Control x 1 RJ11 Network Cable (5m) x 1 RMS-P2 Cable x 2 700W Inverter (RNG-INVT-700-12V-P2): 6 AWG @ 3 ft 1000W Inverter (RNG-INVT-1000- 12V-P2): 4 AWG @ 3 ft 2000W Inverter (RNG-INVT-2000- 12V-P2): 1/0 AWG @ 3 ft... -
Page 12: Product Overview
Product Overview 700W Inverter 1000W Inverter 2000W or 3000W Inverter Product Overview 700W Inverter AC Side View Part Description Power LED (Green) Indicates the operation status of the inverter. Indicates that the ground fault circuit has been interrupted. GFCI LED (Yellow) In such case, restart the inverter. - Page 13 Product Overview 700W Inverter 1000W Inverter 2000W or 3000W Inverter DC Side View Part Part Negative (-) DC Input, M8 Positive (+) DC Input, M8 Cooling Fan Ground, M4...
-
Page 14: 1000W Inverter
Product Overview 700W Inverter 1000W Inverter 2000W or 3000W Inverter 1000W Inverter AC Side View Part Description Connect to 115V AC devices operating at higher than 15 A or distributed wiring with multiple AC outlets. Remove the two screws on the protective cover to access the terminals. - Page 15 Product Overview 700W Inverter 1000W Inverter 2000W or 3000W Inverter Part Description ON/OFF/REM Switch Turns inverter ON, OFF, or REMOTE. 115V AC 60 Hz: Up to 15 A for 2000W and 3000W models AC Outlets Up to 8.7 A for 1000W models Up to 6.1 A for 700W models Supplies 5V/2.1 A for charging tablets, smartphones, USB Power Port...
-
Page 16: 2000W Or 3000W Inverter
Product Overview 700W Inverter 1000W Inverter 2000W or 3000W Inverter 2000W or 3000W Inverter AC Side View Part Description ON/OFF/REM Switch Turns inverter ON, OFF, or REMOTE. Power LED (Green) Indicates the operation status of the inverter. Indicates that the ground fault circuit has been interrupted. - Page 17 Product Overview 700W Inverter 1000W Inverter 2000W or 3000W Inverter Part Description Connect to 115V AC devices operating at higher than 15 A or distributed wiring with multiple AC outlets. Remove the two screws on the protective cover to access the terminals. High Output AC Terminal layout (facing the front panel) Terminals...
-
Page 18: Wiring Diagram
Wiring Diagram 700W Inverter 1000W Inverter 2000W or 3000W Inverter Wiring Diagram 700W Inverter AC Side View ▇ Wired Remote Loads Control (USB) AC Loads RMS-P2 Remote control... - Page 19 Wiring Diagram 700W Inverter 1000W Inverter 2000W or 3000W Inverter DC Side View ▇ Ground Battery Battery Fuse Positive (DC) Negative (DC) Ground...
-
Page 20: 1000W Inverter
Wiring Diagram 700W Inverter 1000W Inverter 2000W or 3000W Inverter 1000W Inverter AC Side View ▇ Sub-panel Wired Remote Loads AC Loads (optional) Control (USB) AC Loads RMS-P2 Live wire (AC) Remote control Neutral wire (AC) Ground... - Page 21 Wiring Diagram 700W Inverter 1000W Inverter 2000W or 3000W Inverter DC Side View ▇ Ground Battery Battery Fuse Positive (DC) Negative (DC) Ground...
-
Page 22: 2000W Or 3000W Inverter
Wiring Diagram 700W Inverter 1000W Inverter 2000W or 3000W Inverter 2000W or 3000W Inverter AC Side View ▇ Sub-panel Wired Remote Loads (optional) Control (USB) AC Loads AC Loads RMS-P2 Live wire (AC) Remote control Neutral wire (AC) Ground... - Page 23 Wiring Diagram 700W Inverter 1000W Inverter 2000W or 3000W Inverter DC Side View ▇ Ground Battery Battery Fuse Positive (DC) Negative (DC) Ground...
-
Page 24: Installation
Installation Plan an Installation Site Size a Battery Bank Ground DC Wiring AC Wiring Installation CAUTION Do not over-torque or overtighten the terminals. This could potentially damage the unit. Refer to the technical specifications for maximum wire sizes on the controller and for the maximum amperage going through wires. -
Page 25: Size A Battery Bank
Installation Plan an Installation Site Size a Battery Bank Ground DC Wiring AC Wiring Size a Battery Bank Battery types and capacity relate to the overall inverter performance. To size a proper battery bank, you need to identify the loads that you will be utilizing, as well as an estimate duration (hours/day) you will be using the load. -
Page 26: Ground
Installation Plan an Installation Site Size a Battery Bank Ground DC Wiring AC Wiring Ground If available, the chassis ground lug should be connected to a ground point such as a vehicle chassis or boat grounding system. In fixed locations, connect the ground lug to earth ground. The connections to ground must be tight and against bare metal. - Page 27 Installation Plan an Installation Site Size a Battery Bank Ground DC Wiring AC Wiring 2. On the DC side, remove the protection cap. 1.1.2 3. Unscrew Positive and Negative DC Input Terminals, connect a battery bank to the terminals, and tight the terminal screws.
-
Page 28: Ac Wiring
Installation Plan an Installation Site Size a Battery Bank Ground DC Wiring AC Wiring AC Wiring You can plug your AC loads directly into the receptacles on the inverter’s AC side. 1.2.1 You can also permanently connect the AC output from the AC hardwire terminal through the AC knockout into a load sub-panel or additional... - Page 29 Installation Plan an Installation Site Size a Battery Bank Ground DC Wiring AC Wiring Tested GFCI Models Manufacturer Model Number Leviton GFNT2 Hubbell GFP1305 Hubbell GF15WLA WARNING Risk of electrical shock. Use only ground-fault circuit interrupters [receptacle(s) or circuit breaker(s)] compatible with your inverter. CAUTION GFCIs shall be installed in a recreational vehicle’s wiring system to protect all branch circuits.
-
Page 30: Operation
Operation Operations on Inverter Wired Remote Control Operation Operations on Inverter After proper battery and AC load connections, you can operate the inverter. 1. On the AC side, rock the ON/OFF Switch to the ON position. 2. The inverter is operating normally. 3. -
Page 31: Led Overview
No sound GFCI protection appliances separately and see if the yellow LED of the inverter is always on. If not, it indicates a current leakage problem on the appliance. If it's always on, please contact Renogy to deal with it. -
Page 32: Troubleshooting
Troubleshooting Troubleshooting Indicator & Alarm Potential Issue Solution Input voltage is below 11V. Keep input voltage above 11V. Alarm beeps Input voltage is above 16.0V. Keep input voltage below 16.0V. Input voltage is below 10V. Keep input voltage above 10V. Input voltage is above 16.5V. -
Page 33: Dimensions
Dimensions 700W Inverter 1000W Inverter 2000W Inverter 3000W Inverter Dimensions CAUTION Dimension tolerance: ±0.2 in (0.5 mm) 700W Inverter 12.2in [310mm] 3.3in [84mm] 5.8in [148mm] 7.4in 700W [188mm] 1000W Inverter 12.9in [328mm] 3.3in [84mm] 5.8in [148mm] 6.8in 1000W [172mm]... -
Page 34: 2000W Inverter
Dimensions 700W Inverter 1000W Inverter 2000W Inverter 3000W Inverter 2000W Inverter 17.8in [451mm] 4.0in [102mm] 9.8in [248mm] 8.6in 2000W [218mm] 3000W Inverter 18.9in [480mm] 4.0in [102mm] 9.8in [248mm] 9.0in 3000W [229mm]... -
Page 35: Specifications
Specifications General Data Electrical Data Wired Remote Data Specifications General Data RNG-INVT-700- RNG-INVT-1000- RNG-INVT-2000- RNG-INVT-3000- Model 12V-P2 12V-P2 12V-P2 12V-P2 Output Waveform Pure Sine Wave 2 x AC Sockets AC Terminals 2 x AC Sockets 3 x AC Sockets + Terminal Block + Terminal Block DC Terminals M8 - 1.25 x 15 mm... -
Page 36: Wired Remote Data
Specifications General Data Electrical Data Wired Remote Data Battery Input Voltage 10V to 16V DC Range Maximum Continuous Battery 58.3A 83.3A 166.6A 250A Output Current Inverter Efficiency >90% Full Load Efficiency >85% Power Consumption <10W <12W <24W <30W Battery Overoltage 16.5V (±0.3V) DC Shutdown Battery Low Voltage... -
Page 37: Technical Support
Technical Support Technical Support For additional support, contact the Renogy technical support team through renogy.com/ contact-us. Have the following information available when contacting Renogy. Owner name Contact information Order number Purchase channel Serial number Brief description of the issue Renogy offers premium services worldwide: North America www.renogy.com... - Page 39 Renogy Power PLUS Renogy Power Plus allows you to stay in the loop with upcoming solar energy innovations, share your experiences with your solar energy journey, and connect with like-minded people who are changing the world in the Renogy Power Plus community.
- Page 40 "Contact Us". Renogy reserves the right to change the contents of this manual without notice. Join the Renogy Power Plus Community by downloading the DC Home App. Find your e-warranty here, and more.
