AI Auto Tracking PTZ Camera
TR310/ TR311/TR313/TR331/TR333
*NDI model: TR311HN/TR311N/
TR313N/TR331N/TR333N
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TR311N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AVer TR311N

Summary of Contents for AVer TR311N

  • Page 1 AI Auto Tracking PTZ Camera TR310/ TR311/TR313/TR331/TR333 *NDI model: TR311HN/TR311N/ TR313N/TR331N/TR333N User Manual...
  • Page 2 FCC NOTICE (Class A) This device complies with Part 15 of the FCC Rules. The operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 COPYRIGHT ©2021 AVer Information Inc. All rights reserved. All rights of this object belong to AVer Information Inc. Reproduced or transmitted in any form or by any means without the prior written permission of AVer Information Inc. is prohibited. All information or specifications are subject to change without prior notice.
  • Page 4 WARNING  To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. Warranty will be void if any unauthorized modifications are done to the product.  Do not drop the camera or subject it to physical shock. ...

  • Page 5: Table Of Contents

    Contents Package Contents ...................... 1 Product Introduction ....................2 Sources ......................... 2 Overview ....................... 2 LED Indicator ......................3 Pan and Tilt Angle ....................3 Dimension ......................4 Device Connection ....................5 Video Output Connection ..................6 RS232 and RS422 Connection ................7 Audio Input Connection ..................11 PoE Connection ....................11 Install Cable Fixing Plate ..................
  • Page 6 Network ......................21 System ......................22 Web Setup ......................23 Using the AVer IPCam Utility to Find the Camera ..........23 Using AVer PTZ Management Software to Find the Camera ....... 24 Make a Connection to the Camera via Browser ..........25 Live View ......................
  • Page 7 VISCA RS232 Command Table ................47 Visca over IP Settings ..................48 CGI command ..................... 49 Specification ......................51 TR311 ........................51 TR311HN ......................54 TR311N ....................... 57 TR313 ......................... 61 TR313N ....................... 64 TR331 ......................... 68 TR331N ....................... 71 TR333 ......................... 75...

  • Page 8: Package Contents

    Package Contents Package Contents Camera unit Remote control Cable ties(x5) Quick Start Guide Cable Fixing M2 x 4mm Power adapter & 1/4”-20L=6.5mm plates(x2) Screw(x4) Power cord Screw(x3) Ceiling mount M3 x 6mm bracket(x2) Screw(x3) *The power cord will vary depending on the standard power outlet of the country where it is sold. Optional accessory RS232 Din8 to Wall mount...

  • Page 9: Product Introduction

    Product Introduction Sources TR311 Intro Video https://www.youtube.com/watch?v=j25xQbkSmPc TR311 Series Feature Video https://www.youtube.com/watch?v=VJh1m5RWhLw AVer Tech (Setup) https://www.youtube.com/channel/UC8rQt7Pe3_4Rh-K4p1eXfNw Overview (5) (6) (7)(8)(9) (11) (10) (12) (1) Tally Lamp (*1) (5) PoE+ IEEE 802.3AT (9) USB 3.0 Port (Type C) (2) IR Sensor...

  • Page 10: Led Indicator

    LED Indicator Status Blue(Solid) Normal Operation Blue(Blinking) Auto Tracking On Orange(Blinking) Camera Initialization Orange(Solid) Standby Red(Blinking) FW Updating Pan and Tilt Angle 90° 170° 170° 30°...

  • Page 11: Dimension

    Dimension Unit: mm...

  • Page 12: Device Connection

    Device Connection Joystick (Camera control) Laptop (Management/Presentation/ Video Conference) Microphone Audio input RS232, RS422 or IP 3G-SDI Monitor/TV PoE+ (Display) HDMI Lecture capture system Camera (Record) Web application (Remote Management)

  • Page 13: Video Output Connection

    Video Output Connection  HDMI Use the HDMI cable to connect with monitor or TV for video output. HDMI cable Monitor/TV  3G-SDI Connect to 3G-SDI monitor for video output. (This feature “3G-SDI” is not supported on TR311 & TR311HN.) 3G-SDI cable (Not inculded) SDI Monitor...

  • Page 14: Rs232 And Rs422 Connection

    RS232 and RS422 Connection Connect through the RS232 or RS422 for camera control.  RS232 RS232(VISCA) cable (Not inculded) Joystick Laptop...
  • Page 15 ● RS232 Port Pin Definition Mini DIN9 Function I/O Type Signal Description PIN # Output Data Terminal Ready Input Data Set Ready VISCA IN Output Transmit Data Input Receiver Data Output Data Terminal Ready Input Data Set Ready VISCA OUT Output Transmit Data Input...
  • Page 16 Mini DIN8 Cable Pin Definition Signal ● Din8 to D-Sub9 Cable Pin Definition...
  • Page 17  RS422 RS422 cable (Not inculded) Joystick Laptop [Note] Use cat5e splitter for multi-camera connection. RS422 Pin Cat5e splitter pin assignment: Camera Camera/Joystick Camera/Joystick...

  • Page 18: Audio Input Connection

    Audio Input Connection Connect the audio device for audio receiving. [Note] Line input level: 1Vrms (max.). Mic input level: 50mVrms (max.); Supplied voltage:2.5V. Microphone Auido mixer...

  • Page 19: Poe Connection

    PoE Connection Connect the camera to the router or switch through the PoE+ port. [Note] Only support IEEE 802.3AT PoE+ standard. Ethernet cable (Not inculded) Router/PoE Switch...

  • Page 20: Install Cable Fixing Plate

    Install Cable Fixing Plate Secure the cable fixing plate to the camera with screws. Screw: 4screws, M2 x 4mm(Included in the package) Using cable ties to secure Plug-in cables. the cable and cable fixing plate.

  • Page 21: Ceiling Installation

    Ceiling installation 1. Secure the mount bracket on the ceiling. 2. Install the mount bracket on the camera. Screw: 4 screws, M4 x 10mm(Not Included Screw: 3 screw , 1/4"-20 L=6.5mm(Included in the package) in the package) 3. Slide the mount bracket with the camera 4.

  • Page 22: Installation For Auto Tracking Performance

    Installation for Auto Tracking Performance • Maximum/Minimum distance from the camera to tracking target Upper body tracking Full body tracking TR311 1.3~16 meters 2.2~28 meters TR331 1.4~44 meters 2.5~76 meters • Installed 2~3 meters high from the floor. • No human-outline figure on posters/screens/monitors/TVs in the background.

  • Page 23: Remote Control

    Remote Control (10) (12) (11) (14) (13) (15) (17) (16) (19) (20) (18) (21) (22) (24) (23) Name Function Turn the unit on/standby. (1) Power Open and exit the OSD menu. (2) Menu CAM1 to CAM3 button (3) Camera Select Selects a camera to operate.
  • Page 24 Name Function Left and right orientation setting. (12) L/R DIR Press and hold “L/R DIR” button + number button “1” to set the direction of the camera panning movement opposite to that indicated by the arrow of the / buttons. Press and hold“L/R DIR”...

  • Page 25: Setup The Camera

    Setup the Camera OSD Menu Press button on the remote controller to call out the OSD menu and use ▲ , ▼ , ,  and button to operate the OSD menu. Setup IP Address of the Camera Static IP 1.

  • Page 26: Dhcp

    DHCP 1. Press button on the remote controller to call out OSD menu. 2. Go to Network > DHCP > On. 3. After turn the DHCP on, the user can go to System > Information to view IP address.

  • Page 27: Osd Tree

    OSD Tree Camera Setup camera parameters – Exposure mode, White balance, Pan-Tilt Zoom, Noise reduction, Frequency, Saturation, Contrast, Sharpness, Mirror, and Flip. Camera Exposure Mode Full Auto Exposure Value/Gain Limit Level/Slow Shutter Shutter Priority Exposure Value/Shutter Speed/Gain Limit Level Iris Priority Exposure Value/Iris Level/Gain Limit Level/Slow Shutter Manual Iris Level/Shutter Speed/Gain Level...

  • Page 28: Advanced Setting

    Advanced Setting Advanced Setting Audio Input Type Mic in/Line in Auto Gain Control OFF/ON Noise Suppression OFF/Low/Normal Audio Volume 0 ~ 10 Control Type RS232/RS422 Protocol VISCA/Pelco-P/ Pelco-D Camera Address Baud Rate 2400/4800/9600/38400 Tracking ON/OFF Video Output Select video resolution.(2160p is supported on TR313 and TR333 only) Priority Mode 2160P/1080P Frequency...

  • Page 29: System

    System  Status OSD: Enable/disable Preset status (Save Preset, Call Preset, Cancel Preset) display on the screen.  Camera Selector: Set the camera ID 1~3 for using remote controller on multiple cameras control (also see (2) Camera select in Remote Control chapter). ...

  • Page 30: Web Setup

    Web Setup Connect the camera from a remote site through the internet. Using the AVer IPCam Utility to Find the Camera To find the IP address of your cameras, you can execute the IPCam Utility installer. Follow the below steps to find the IP address of the camera.

  • Page 31: Using Aver Ptz Management Software To Find The Camera

    Using AVer PTZ Management Software to Find the Camera To find the IP address of your cameras, you can download the install the AVer PTZ Management Software. Follow the below steps to find the IP address of the camera. 1. Download the AVer PTZ Management Software from https://www.aver.com/download-center 2.

  • Page 32: Make A Connection To The Camera Via Browser

    Find the IP address of the camera. Call out OSD menu and select “System” > “Information” Or use AVer IPCam utility to find the IP address of the camera. 2. Open the browser and enter the IP address of the camera. The PC/laptop is required an internet access.

  • Page 33: Live View

    Live View In live view, the user can setup Camera Control (zoom in/out, focus, camera direction control), Preset setting, and Tracking Control(on, off, tracking mode). Pan-Tilt-Zoom Control To operate the PTZ Camera motion. , and to adjust the camera view position and use to zoom.

  • Page 34: Focus

    Focus Switch to auto (AF) or manual (MF) focus. The manual focus use + and – to adjust focus. Press “+” to adjust focus to the far end and focusing on a far subject; press “-“to adjust focus to near end and focusing on a near subject.

  • Page 35: Preset Setting

    Preset Setting Setup preset position and view preset position. 1. Select the “Preset” tab in live view interface. 2. Use , and to adjust camera view position. 3. Enter preset position number (0~255) in Save Preset column and select “Save” to save the position.

  • Page 36: Click Tracking Function

    Click Tracking Function This function allows user to change tracking object while auto tracking. 1. Select Click Track button. A red frame is targeted on the tracking object and a blue frame is targeted on another object on the live screen. 2.

  • Page 37: Camera Settings

    Camera Settings Exposure Setup the exposure type -- Full auto, Iris priority, Shutter priority, or manual. Image Process Setup the white balance, saturation, contrast, sharpness, noise filter, power frequency, flip, and mirror. Select the “Image Process” tab in camera setting interface.

  • Page 38: Video & Audio

    Video & Audio The user can setup Video Mode, Video output, Framerate, Bitrate, I-VOP internal, Encode type, Rate control, Audio input type, Audio volume, and Sampling Rate. Video mode in the stream only, the frame rate is up to 60fps and in USB+ Streaming mode is up to 30fps.
  • Page 39 Setup NDI Function NDI service only support on NDI models: TR311HN/TR311N/ TR313N/TR331N/TR333N. 1. Enable NDI mode by selecting “NDI” as video mode in Video & Audio page. To disable the NDI function, select other mode. The camera will reboot after selecting NDI mode.
  • Page 40 3. Set the identity name for display on NDI interface. Select System > Camera ID(NDI). Enter the name as user wanted. The maximum character is 10. After entering the name, select the Set button to save and manually restart the PTZ camera for the settings to take effect. The following characters can be displayed for camera ID: Numeric characters 0123456789...

  • Page 41: Network

    “Confirm” to apply settings. Hostname: To change the display of Hostname, allow to name the camera in other device ex IP Router. The default Hostname of camera is AVer. RTMP Setting Setup for uploading the camera’s live view to the broadcasting platform (ex: Youtube).

  • Page 42: Using Rtsp Connect To Camera

    Using RTSP Connect to Camera To use RTSP player connecting to the camera; please enter the following RTSP URL in your application such as VLC, PotPlayer or Quick Time. “rtsp://IP address of camera/live_st1” For Example: rtsp://192.168.1.168/live_st1 (the camera default IP address: 192.168.1.168) Enable/disable RTSP security function if needed.

  • Page 43: Srt Stream

    SRT Stream Example 1 vMix: Set the workstation and the TR311 camera in the same network. Check the workstation’s IP address (Destination IP). Example: Select SRT(Listener) from Stream Type in vMix Input Select window. Enter the information into the SRT Settings TR311 web interface, then click on “Start Stream”, Connect Status shows “Connected”.
  • Page 44 Example2 OBS (Open Broadcaster Software) Set the workstation and the TR311 camera in the same network. Check the workstation’s IP address (Destination IP). Example: Open OBS, add a scene, add a source, enter srt://Work Station IP:port?mode=listener Example: srt://10.100.105.127:8889?mode=listener [Note] If there is no image, please try right click on the source->Transform->Fit to screen to re-scale image.

  • Page 45: Tracking Setting

    Tracking Setting Set up Tracking mode – Presenter, Zone, and Hybrid mode. Presenter Mode Camera will start tracking when object enters the tracking point (preset point). to adjust the camera to tracking point (preset position). Then, select Save to Preset 1 to save the tracking point. Tracking Sensitivity: Set the sensitive level of tracking.
  • Page 46 Effect Tracking Area: When Effective Tracking Area function is on, camera only tracks around the selected area. Check the box to turn on the Effective Tracking Area function then click Set to configure the targeted area in the live view. Move the upper left corner and the lower right corner of the red solid frame to define the targeted area.

  • Page 47: Zone Mode

    Zone Mode Setup the block area for the camera to detect object and follow-up the object to move the camera when the object is in block area that user has set. Select the Blocks (2, 3, or 4). Each block is corresponding to one preset position. The maximum is 4 blocks (4 preset positions).
  • Page 48 [Note] Set each preset overlapping the next preset view (one man width overlap), no or less zoom between presets. Examples below: [Note] Set the preset view to clearly see at least 60% upper body of the preseter to ensure tracking accuracy. Make sure there is no any other human-outline poster/TV/moniter in the background.

  • Page 49: Hybrid Mode

    Hybrid Mode This function allows the user to use two types of tracking modes: “Presenter mode” and “Zone mode” at the same time. When the presenter enters selected preset points, it will change to Zone position; when the presenter leaves the preset points, camera will follow presenter to do Auto Tracking function. 1.
  • Page 50 5. When losing tracking target and going back to Tracking Point. 6. Presenter size, Full body will show the whole Body on screen and Upper will only show half body.

  • Page 51: Quick Setup For Tracking

    Quick Setup for Tracking Presenter Mode Use IR remote to adjust the camera view properly then save to preset1 as the initial position Press tracking “On” button on IR remote, here you go! Press “UPPER BODY” key to get closer view (up to 60% body), or FULL BODY to see entire presenter in the view.

  • Page 52: System

    System  System information: It displays Model Name, IP Address, Serial Number, MAC Address and Firmware Version.  Factory Default: Reset the camera back to factory default value.  Login in: The default login in name and password are admin/admin. User can change if needed. ...

  • Page 53: Upgrade Firmware

    Upgrade Firmware 1. Download the newest firmware from http://www.aver.com/download-center 2. Connect to the camera through the browser. 3. Select System > Browse the FW file > Upgrade firmware 4. Select the firmware and select the “Upgrade” button. 5. After updating, refresh the browser.

  • Page 54: Visca Rs232 Command Table

    VISCA RS232 Command Table Command Set Command Command Packet Comments 8x 01 04 00 02 FF CAM_Power Power ON/OFF 8x 01 04 00 03 FF Stop 8x 01 04 07 00 FF CAM_Zoom Tele(Variable) 8x 01 04 07 2p FF p=0 (Low) to 7 (High) Wide(Variable) 8x 01 04 07 3p FF...

  • Page 55: Visca Over Ip Settings

    Inquiry Command Command Packet Reply Packet Comments y0 50 02 FF CAM_PowerInq 8x 09 04 00 FF y0 50 03 FF y0 50 00 FF Auto y0 50 01 FF In Door y0 50 02 FF Out Door CAM_WBModeInq 8x 09 04 35 FF y0 50 03 FF One Push WB y0 50 04 FF...

  • Page 56: Cgi Command

    CGI command CGI List for Video Transmission CGI item name Command Parameter Name Parameter value Description Get JPEG /snapshot 1280x720 jpg Get RTSP stream rtsp://ip/live_st1 CGI List for Camera Control Parameter Parameter CGI item name Command Description Name value up start /cgi-bin?SetPtzf= 1,0,1&(random) up end...
  • Page 57 contrast /cgi-bin?Set= img_contrast,3,N&(random) value 0 ~ 4 N : value Tracking on: /cgi-bin?Set= trk_tracking,3,1&(random) Tracking off: /cgi-bin?Set= trk_tracking,3,0&(random) Tracking Presenter Mode: /cgi-bin?Set= trk_mode,3,1&(random) Tracking Zone Mode: /cgi-bin?Set= trk_mode,3,2&(random)

  • Page 58: Specification

    Specification TR311 Camera Image Sensor 1/2.8” 1080p Exmor CMOS Effective Picture Elements 2 Megapixels Auto 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, Output Resolutions 1080p/29.97, 1080p/25, 720p/60, 720p/59.94, 720p/50, 720p/30, 720p/29.97, 720p/25 Minimum Illumination 0.4 lux (IRE50, F1.6, 30fps) S/N Ratio ≥ 50 dB Gain Auto, Manual TV Line...
  • Page 59 Pan / Tilt Speed (Manual) Pan : 0.1° to 100° / sec, Tilt : 0.1° to 100° / sec Preset Speed Pan : 200° / sec, Tilt : 200° / sec Preset Positions 10 (IR), 255 (RS-232) Camera Control - Interface RS-232 (DIN8), RS-422 (RJ45), IP Camera Control - Protocols VISCA / PELCO-D (RS-232 / RS-422 / IP), CGI (IP)
  • Page 60 Operating Conditions Temperature : 0 °C to +40 °C ; Humidity : 20% to 80% Storage Conditions Temperature : -20°C to +60°C ; Humidity: 20% to 95% IP Streaming Resolution 1080p 60fps Network Video Compress Formats H.264, H.265, MJPEG Maximum Frame Rate 1080p 60fps Bit-rate Control Modes VBR, CBR (selectable)

  • Page 61: Tr311Hn

    Warranty Camera 3 Years Accessories 1 Year TR311HN Camera Image Sensor 1/2.8” HD Exmor CMOS Effective Picture Elements 2 Megapixels Auto 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, Output Resolutions 1080p/29.97, 1080p/25, 720p/60, 720p/59.94, 720p/50, 720p/30, 720p/29.97, 720p/25 Minimum Illumination 0.4 lux (IRE50, F1.6, 30fps) S/N Ratio ≥...
  • Page 62 Camera Pan / Tilt Angles Pan : ±170°, Tilt : +90° / -30° Pan / Tilt Speed (Manual) Pan : 0.1° to 100° / sec, Tilt : 0.1° to 100° / sec Preset Speed Pan : 200° / sec, Tilt : 200° / sec Preset Positions 10 (IR), 255 (RS-232) Camera Control - Interface...
  • Page 63 Security Kensington Slot Remote Control Infrared Operating Conditions Temperature : 0 °C to +40 °C ; Humidity : 20% to 80% Storage Conditions Temperature : -20°C to +60°C ; Humidity: 20% to 95% IP Streaming Resolution 4K 30fps, 1080p 60fps Network Video Compress Formats H.264, H.265, MJPEG Maximum Frame Rate...

  • Page 64: Tr311N

    ® Device IP Searching, Configuration Tool Support Windows 7 or later Warranty Camera 3 Years Accessories 1 Year TR311N Camera Image Sensor 1/2.8” 1080p Exmor CMOS Effective Picture Elements 2 Megapixels Auto 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, Output Resolutions 1080p/29.97, 1080p/25, 720p/60, 720p/59.94, 720p/50, 720p/30, 720p/29.97, 720p/25...
  • Page 65 Digital Zoom Sensor Zoom DFOV : 78° (Wide) to 7° (Tele) Viewing Angles HFOV : 70° (Wide) to 6° (Tele) VFOV : 42° (Wide) to 3° (Tele) Focal Length f = 3.9 mm (Wide) to 46.8 mm (Tele) Aperture (Iris) F = 1.6 (Wide) to 2.8 (Tele) Minimum Working Distance 0.3 m (Wide), 1.5 m (Tele)
  • Page 66 Power Requirement AC 100 - 240V to DC 12V/2A and above Power Consumption PoE+ Dimensions (W x D x H) W180*D145*H183.5mm Net Weight 1.7 (±0.1) kg General Application Indoor Tally Security Kensington Slot Remote Control Infrared Operating Conditions Temperature : 0 °C to +40 °C ; Humidity : 20% to 80% Storage Conditions Temperature : -20°C to +60°C ;...
  • Page 67 Video Format MJPEG Maximum Video Resolution 1080p USB Video Class (UVC) UVC 1.1 Web UI Live Video Preview Camera PTZ Control Pan, Tilt, Zoom, Focus, Preset Control Camera / Image Adjustment Exposure, White Balance, Picture Network Configuration DHCP, IP Address, Gateway, Subnet Mask, DNS Software Tools ®...

  • Page 68: Tr313

    TR313 Camera Image Sensor 1/2.8” 4K Exmor CMOS Effective Picture Elements 8 Megapixels Auto 4K/30, 4K/29.97, 4K/25, 1080p/60, 1080p/59.94, Output Resolutions 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 720p/60, 720p/59.94, 720p/50, 720p/30, 720p/29.97, 720p/25 Minimum Illumination 0.4 lux (IRE50, F1.6, 30fps) S/N Ratio ≥...
  • Page 69 Camera Preset Speed Pan : 200° / sec, Tilt : 200° / sec Preset Positions 10 (IR), 255 (RS-232) Camera Control - Interface RS-232 (DIN8), RS-422 (RJ45), IP Camera Control - Protocols VISCA / PELCO-D (RS-232 / RS-422 / IP), CGI (IP) Image Processing Noise Reduction (2D / 3D), Flip, Mirror Power Frequency...
  • Page 70 General Remote Control Infrared Operating Conditions Temperature : 0 °C to +40 °C ; Humidity : 20% to 80% Storage Conditions Temperature : -20°C to +60°C ; Humidity: 20% to 95% IP Streaming Resolution 4K 30fps Network Video Compress Formats H.264, H.265, MJPEG Maximum Frame Rate 4K 30fps or 1080p 60fps...

  • Page 71: Tr313N

    Web UI Live Video Preview Camera PTZ Control Pan, Tilt, Zoom, Focus, Preset Control Camera / Image Adjustment Exposure, White Balance, Picture Network Configuration DHCP, IP Address, Gateway, Subnet Mask, DNS Software Tools Device IP Searching, Configuration Tool Support Windows® 7 or later Warranty Camera 3 Years...
  • Page 72 Optical Zoom Digital Zoom Sensor Zoom DFOV : 78° (Wide) to 7° (Tele) Viewing Angles HFOV : 70° (Wide) to 6° (Tele) VFOV : 42° (Wide) to 3° (Tele) Focal Length f = 3.9 mm (Wide) to 46.8 mm (Tele) Aperture (Iris) F = 1.6 (Wide) to 2.8 (Tele) Minimum Working Distance...
  • Page 73 Camera Preset Speed Pan : 200° / sec, Tilt : 200° / sec Preset Positions 10 (IR), 255 (RS-232) Camera Control - Interface RS-232 (DIN8), RS-422 (RJ45), IP Camera Control - Protocols VISCA / PELCO-D (RS-232 / RS-422 / IP), CGI (IP) Image Processing Noise Reduction (2D / 3D), Flip, Mirror Power Frequency...
  • Page 74 General Remote Control Infrared Operating Conditions Temperature : 0 °C to +40 °C ; Humidity : 20% to 80% Storage Conditions Temperature : -20°C to +60°C ; Humidity: 20% to 95% IP Streaming Resolution 4K 30fps Network Video Compress Formats H.264, H.265, MJPEG Maximum Frame Rate 4K 30fps or 1080p 60fps...

  • Page 75: Tr331

    Web UI Live Video Preview Camera PTZ Control Pan, Tilt, Zoom, Focus, Preset Control Camera / Image Adjustment Exposure, White Balance, Picture Network Configuration DHCP, IP Address, Gateway, Subnet Mask, DNS Software Tools Device IP Searching, Configuration Tool Support Windows® 7 or later Warranty Camera 3 Years...
  • Page 76 Optical Zoom Digital Zoom Sensor Zoom DFOV : 72.9° (Wide) to 2.64° (Tele) Viewing Angles HFOV : 65.1° (Wide) to 2.34° (Tele) VFOV : 38.4° (Wide) to 1.36° (Tele) Focal Length f = 4.3 mm (Wide) to 129 mm (Tele) Aperture (Iris) F = 1.6 (Wide) to 4.7 (Tele) Wide 0.01 m,...
  • Page 77 Video Outputs 3G-SDI, HDMI, IP, USB Audio Outputs 3G-SDI, HDMI, IP, USB Audio Inputs MIC in, Line in General Power Requirement AC 100 - 240V to DC 12V/2A and above Power Consumption PoE+ Dimensions (W x D x H) W180*D145*H183.5mm Net Weight 1.7 (±0.1) kg Application...

  • Page 78: Tr331N

    NDI® | HX Capability Connector USB 3.0 Video Format MJPEG Maximum Video Resolution 1080p USB Video Class (UVC) UVC 1.1 USB Audio Class (UAC) UAC 1.0 Web UI Live Video Preview Camera PTZ Control Pan, Tilt, Zoom, Focus, Preset Control Camera / Image Adjustment Exposure, White Balance, Picture Network Configuration...
  • Page 79 S/N Ratio ≥ 50 dB Gain Auto, Manual TV Line 900 (center/wide) Shutter Speed 1/1 to 1/32,000 sec Exposure Control Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR White Balance Auto, Manual Optical Zoom Digital Zoom Sensor Zoom DFOV : 72.9° (Wide) to 2.64° (Tele) Viewing Angles HFOV : 65.1°...
  • Page 80 AI Auto Tracking Functions Tracking Mode Presenter Mode, Zone Mode, Hybrid Mode Audio Channel 2ch Stereo Codec AAC-LC (48 / 44.1 / 32 / 24K), G.711, PCM (8K) Sample Rate 48 / 44.1 / 32 / 24 / 16 / 8 KHz Interface Video Outputs 3G-SDI, HDMI, IP, USB...
  • Page 81 Bit-rate Control Modes VBR, CBR (selectable) Range of Bit-rate Setting 512 Kbps to 32 Mbps Network Interface 10 / 100 / 1000 Base-T Multi-stream Capability (RTSP / Web Page), 1080p 60fps (max.) IPv6, IPv4, TCP, UDP, ARP, IMCP, IGMP, HTTP, Network Protocols DHCP, RTP / RTCP, RTSP, RTMP, VISCA over IP NDI®...

  • Page 82: Tr333

    TR333 Camera Image Sensor 1/2.5” 4K Exmor CMOS Effective Picture Elements 8 Megapixels Auto 4K/30, 4K/29.97, 4K/25, 1080p/60, 1080p/59.94, Output Resolutions 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 720p/60, 720p/59.94, 720p/50, 720p/30, 720p/29.97, 720p/25 Minimum Illumination 2.7 lux (IRE50, F1.5, 30fps) S/N Ratio ≥...
  • Page 83 Camera Preset Speed Pan : 200° / sec, Tilt : 200° / sec Preset Positions 10 (IR), 255 (RS-232) Camera Control - Interface RS-232 (DIN8), RS-422 (RJ45), IP Camera Control - Protocols VISCA / PELCO-D (RS-232 / RS-422 / IP), CGI (IP) Image Processing Noise Reduction (2D / 3D), Flip, Mirror Power Frequency...
  • Page 84 General Operating Conditions Temperature : 0 °C to +40 °C ; Humidity : 20% to 80% Storage Conditions Temperature : -20°C to +60°C ; Humidity: 20% to 95% IP Streaming Resolution 4K 30fps Network Video Compress Formats H.264, H.265, MJPEG Maximum Frame Rate 4K 30fps or 1080p 60fps Bit-rate Control Modes...
  • Page 85 Software Tools Device IP Searching, Configuration Tool Support Windows® 7 or later Warranty Camera 3 Years Accessories 1 Year...
