Assembly and adjustments

Measure the outer dimension at the TAS-UNI-DP (1) with a qualified measuring tool (6) e.g. yard stick (6) (or slide

gauge). This measure must be equal at the front side and back side (see ). → Figure 4 and Figure 5.

Tighten both nuts (2) again (tight) on the outer side at the TAS-UNI-DP. → Figure 6

Fig. 4

Also a roof profile with different lengths of

aluminium profiles is preparable.

→ see Figure A1

51000102

Fig. 5

(1)

(6)

Figure A (roof profile)

Remessure the actual

slope at the facing

bedding sand

1 %

Fig. 6

(6)

Reference level

Figure A1

10 / 18

(2)

1 %
