Description (cont.)
Cover/Housing O-Ring
4
Single, Double, T riple and Thru-drive Pumps Overhaul Service Manual V-PUVN-TS001-E October 2002
Figure 1b.
Cutaway View of Typical High Performance VMQ Double Vane Pump
Cutaway View of Typical High Performance VMQ Triple Vane Pump
Figure 1c.
Outlet Cover
Inlet Housing
Housing/Body O-Ring
Outlet Section
