- Page 1 SUN-3.6K-SG01LP1-US SUN-3.6K-SG01LP1-US-B SUN-5K-SG01LP1-US SUN-5K-SG01LP1-US-B SUN-6K-SG01LP1-US-B SUN-6K-SG01LP1-US SUN-7.6K-SG01LP1-US-B SUN-7.6K-SG01LP1-US SUN-8K-SG01LP1-US-B SUN-8K-SG01LP1-US...
-
Page 2: Table Of Contents
Contents Contents Contents 5.8 Grid Setup Menu 5.9 Generator Port Use Setup Menu 2.1 Product Overview 5.10 Advanced Function Setup Menu 2.2 Product Features 5.11 Device Info Setup Menu 2.3 Basic System Architecture 3.1 Parts list 3.2 Mounting instructions 3.3 Battery connection 3.4 AC Input/Output Connection 3.5 PV Connection 3.6 CT Connection... -
Page 3: Product Overview
1. Safety Introductions 2.1 Product Overview ・This chapter contains important safety and operating instructions. Read and keep this manual for future reference. ・Before using the inverter, please read the instructions and warning signs of the battery and corresponding sections in the instruction manual. ・Do not disassemble the inverter. -
Page 4: Product Features
2.2 Product Features AC cable DC cable WiFI ・ -220V Single phase,120V/240V Split phase Pure sine wave inverter. GPRS ・ - Self-consumption and feed-in to the grid. Cloud services phone ・ - Auto restart while AC is recovering. ・ - Programmable supply priority for battery or grid. Wind Solar Backup Load... -
Page 5: Mounting Instructions
・ The ambient temperature should be between -25~60℃ to ensure optimal operation. Current transformer (Optional) ・ Be sure to keep other objects and surfaces as shown in the diagram to guarantee Battery sensor sufficient heat dissipation and have enough space for removing wires. L-type Hexagon wrench Chart 3-1 Parts List 3.2 Mounting instructions... -
Page 6: Battery Connection
All wiring must be performed by a professional person. 14 mm (0.55 in.) Connecting the battery with a suitable cable is important for safe and 52~60mm efficient operation of the system. To reduce the risk of injury, refer to [(2.05 in.)to(2.36 in.)] Chart 3-2 for recommended cables. -
Page 7: Ac Input/Output Connection
3.3.2 Battery temperature connection 3.4 AC Input/Output Connection ・ Before connecting to AC input power source,please install a separate AC breaker between inverter and AC input power source.This will ensure the inverter can be securely disconnected during maintenance and fully protected from over current of AC input.The recommended of AC breaker is 50A for 5kw and 80A for 8KW. -
Page 8: Pv Connection
3.5.1 PV Module Selection: Be sure that AC power source is disconnected before attempting to wire it When selecting proper PV modules, please be sure to consider below parameters: to the unit. 1) Open circuit Voltage (Voc) of PV modules not exceeds max. PV array open circuit voltage of inverter. -
Page 9: Ct Connection
3.6 CT Connection (Region:EU) (Region:US) N L2 L1 Inverter Inverter N L2 L1 White wire Black wire White wire Black wire 3 4 5 6 Grid Grid 3.7 Earth Connection(mandatory) Ground cable shall be connecred to ground plate on grid side this prevents electric shock. if the original protective conductor fails. -
Page 10: Wiring System For Inverter(Region:eu)
3.9 Wiring System for Inverter (Region:EU) Inverter Ground Breaker Load Breaker Breaker Battery Solar Breaker Generator Microinverter Smart Load Earth-BAR - 15 - - 16 -... - Page 11 (Region:US) L2 L1 L2 L1 L2 L1 Inverter Ground Breaker Breaker Load Breaker Battery Solar Breaker Generator Generat Breaker Microinverter Smart Load Earth-BAR - 17 - - 18 -...
-
Page 12: Power On/Off
4. OPERATION 5. LCD Display Icons 5.1 Main Screen 4.1 Power ON/OFF Once the unit has been properly installed and the batteries are connected well,simply The LCD is touchscreen,below screen shows the overall information of the inverter. press On/Off button(located on the left side of the case) to turn on the unit.When system without battery connected,but connect with either PV or grid,and ON/OFF button is 05/28/2019 15:34:40 switched off,LCD will still light up(Display will show OFF),In this condition,when switch... -
Page 13: Main Screen
5.1.1 LCD operation flow chart 5.2 Solar Power Curve Solar This is Solar Panel detail page. Solar Panel Generation. Solar Page Solar Graph Power: 1560W Today=8.0 KWH Voltage,Current,Power for each MPPT. PV1-V: 286V PV2-V: 45V Total =12.00 KWH Solar Panel energy for Day and Total. PV1-|: 5.5A PV2-|: 0.0A P1: 1559W... -
Page 14: Curve Page-Solar & Load & Grid
Li-BMS 5.4 System Setup Menu Mean Voltage:50.34V Charging Voltage :53.2V Batt Total Current:55.00A Discharging Voltage :47.0V System Setup Data Mean Temp :23.5C Charging current :50A This is System Setup page. Total SOC :38% Discharging current :25A Stand-by Dump Energy:57Ah Details SOC: 36% System Work Mode Data... -
Page 15: System Work Mode Setup Menu
Battery Setting Lithium Mode--This is BMS protocol.default is 0 please reference the document（Approved Battery-Deye）. Lithium Mode Time of use Shutdown 10%--the inverter will shutdown if the SOC is Batt below this. -
Page 16: Grid Setup Menu
5.8 Grid Setup Menu 5.9 Generator Port Use Setup Menu Grid Setting GEN PORT USE Genertor Input:use Genertor Please select the correct Grid Mode in your local area. If Grid Mode General Standard Mode you are not sure, please choose General Standard. SmartLoad Output: if the SOC is up than Generator Input Gen connect to Grid input... -
Page 17: Device Info Setup Menu
PassWord Factory restart: 9999 Lock out all changes:7777 X--X--X--X AC cable DC cable Wind Backup Load On-Grid Home Load CANCEL Grid Battery 5.11 Device Info Setup Menu Li-BMS Li-BMS Device Info. This page show Inverter ID, Inverter version Inverter ID: 1601012001 Charge Charge Volt... - Page 18 1. Inverter serial number; 2. Distributor or service center of the inverter ; 3. On-grid power generation date; On-Grid+AC couple AC cable DC cable 4. The problem description (including the fault code and indicator status displayed on the LCD) is as detailed as possible. 5.
- Page 19 If any part of the product or product is replaced by the company itself during the INT_AC_OverCurr_Fault warranty period, all rights and interests of the replacement product or component belong to Ningbo Deye Inverter Technology Co., Ltd. INT_DC_OverCurr_Fault Factory warranty does not include damage due to the following reasons: AC_WU_OverVolt_Fault ・...
- Page 20 8.Limitation of Liability In addition to the product warranty described above, the state and local laws and regulations provide financial compensation for the product's power connection (including violation of implied terms and warranties). The company hereby declares that the terms and conditions Max.
- Page 22 Warning: 1. Please remove logger after power off. 2. Reset button supports direct press. Do not remove waterproof plug. Notice: Please read this manual carefully before using products and keep it in the place where O&M providers can easily find. Due to product upgrade and other factors, the content of this manual might change from time to time.
- Page 23 for iOS for Andriod for iOS for Andriod SOLARMAN for end user SOLARMAN PRO for business Scan QR code to get quick guide...
- Page 24 1. Stick Logger Installation Type 1 Step1: Assemble logger to the inverter communication interface as shown in the diagram. According to the arrow direction. Step2: Install/Remove Install Remove C l o c k w i s e r o t a t i o n C o u n t e r - c l o c k w i s e r o t a t i o n Warning: Please do not hold the logger body to rotate while...
- Page 25 Type 2 Step1: Assemble logger to the inverter communication interface as shown in the diagram. According to the arrow direction. Step2: Install/Remove Install Remove C l o c k w i s e r o t a t i o n C o u n t e r - c l o c k w i s e r o t a t i o n Warning: Please do not hold the logger body to rotate while...
- Page 26 2. Logger Status 2.1 Check Indicator light Lights Implication Status Description(All lights are single green lights.) 1.Light off: Connection to the router failed. 2.On 1s/Off 1s(Slow flash): Connection to the router succeeded. Communication 3.Light keeps on: Connection to the server succeeded. with router 4.On 100ms/Off 100ms(Fast flash): Distributing network fast.
- Page 27 Fault Description Fault Cause Solution READY 1.Check the con- nection between stick logger and inverter. Remove 1.Connection betw- the stick logger een stick logger and and install again. inverter loosen. Slow Communication with 2.Check inverter’s 2.Inverter does not state flash inverter abnormal communication match with stick log-...
- Page 28 Fault Description Fault Cause Solution READY 1.Connection betw- 1.Check the con- een stick logger and nection, remove the inverter loosen or stick logger and in- Power supply abnormal. stall again. abnormal 2.Inverter power in- 2.Check inverter ou- sufficient. tput power. 3.Stick Logger abn- 3.Contact our cust- ormal.
- Page 29 4. Usage methods and notices for Reset button 4. Usage methods and notices for Reset button Usage: Press Notice: Do not remove waterproof plug.
- Page 38 Warning: Please make sure the stick logger is working properly before you leave the site. If there is anything abnormal, please do not leave the site and contact customer service at the first time. Customer service number: 400-181-0512 If you have any technical queries about our products, please contact us and provide the following information: 1.
- Page 40 Dear Customers, Thank you very much for using our products. In order to provide you with better service, please fill in the warranty card and reserve it carefully. User Name Customer Address Failure Cause and Treatment...
- Page 41 Warranty Policy If there is any breakdown which caused by the product‘s own quality, customers can send the warranty card with the product to our Customer Service Center. 1.According to the prescription, the warranty period is 5 years(From the day when you receive the product). During the warranty period, we provide free maintenance service to solve all non-artifical quality problems if the product is under normal usage circumstance.
