- Page 1 Off-grid Inverter SUN-3.6K-OG01LP1-EU-AM2 SUN-5K-OG01LP1-EU-AM2 SUN-6K-OG01LP1-EU-AM2 User Manual...
-
Page 2: Table Of Contents
Contents 1. Safety Introductions 01-02 ……………………………………………… 2. Product instructions 02-06 ……………………………………………… 2.1 Product Overview 2.2 Product Size 2.3 Product Features 2.4 Basic System Architecture 3. Installation 06-24 …………………………………………………………… 3.1 Parts list 3.2 Product handling requirements 3.3 Mounting instructions 3.4 Battery connection 3.5 Grid connection and backup load connection 3.6 PV Connection 3.7 Earth Connection(mandatory) -
Page 3: About This Manual
Documents must be stored carefully and be available at all �mes. Contents may be periodically updated or revised due to product development. The informa�on in this manual is subject to change without no�ce. The latest manual can be acquired via service@deye.com.cn 1. Safety Introduc�ons Labels descrip�on... - Page 4 · This chapter contains important safety and opera�ng instruc�ons. Read and keep this manual for future reference. · Before using the inverter, please read the instruc�ons and warning signs of the ba�ery and corresponding sec�ons in the instruc�on manual. · Do not disassemble the inverter. If you need maintenance or repair, take it to a professional service center.
-
Page 5: Product Overview
2.1 Product Overview 1: LCD display 7: BMS 485/CAN port 13: PV input 2: Func�on Bu�ons 8: Func�on port 14: Power on/off bu�on 3: Ba�ery input connectors 9: Grid 15: DC Switch (op�onal)* *Note: This component is op�onal, 4: Meter Port 10: GeneratorLoad please confirm whether you need it 5: Modbus Port... -
Page 6: Product Size
2.2 Product Size 306.00 mm Inverter Size 175.77 mm - 04 -... -
Page 7: Product Features
2.3 Product Features - Self-consump�on. - Auto restart while AC is recovering. - Programmable mul�ple opera�on modes: On grid, off grid and UPS. - Configurable ba�ery charging current based on applica�ons by LCD se�ng. - Compa�ble with voltage power or generator power. - Overload/over temperature/short circuit protec�on. -
Page 8: Parts List
3. Installa�on 3.1 Parts List Check the equipment before installa�on. Please make sure nothing is damaged in the package. You should have received the items in the following package: Stainless steel Stainless steel moun�ng Inverter Wall moun�ng hanger an�-collision bolt M6*60 screws M4*12 x10 User manual... -
Page 9: Product Handling Requirements
3.2 Product handling requirements Li� the inverter out of the packing box and transport it to designated installa�on loca�on. transport CAUTION: Improper handling may cause personal injury! • Arrange an appropriate number of personnel to carry the inverter according to its weight, and installa�on personnel should wear protec�ve equipment such as an�-impact shoes and gloves. - Page 10 Please AVOID direct sunlight, rain exposure, snow laying up during installa�on and opera�on. Before connec�ng all wires, please take off the metal cover by removing screws as shown below: Installa�ons Tools Installa�on tools can refer to the following recommended ones. Also, use other auxiliary tools on site.
- Page 11 Considering the following points before selec�ng where to install: · Please select a ver�cal wall with load-bearing capacity for installa�on, suitable for installa�on on concrete or other non-flammable surfaces,installa�on is shown below. · Install this inverter at eye level in order to allow the LCD display to be read at all �mes. ·...
- Page 12 5. Carry the inverter and holding it,align the hole of the hinge with the expansion bolts and screw the nuts of expansion bolts. 6. Fasten the nuts of expansion bolts to finish the moun�ng. ① ② ③ ④ Aperture: 8mm Hole depth: 62-70mm - 10 -...
- Page 13 3.4 Ba�ery connec�on For safe opera�on and compliance, a separate DC over-current protector or disconnect device is required between the ba�ery and the inverter. In some applica�ons, switching devices may not be required but over-current protectors are s�ll required. Refer to the typical amperage in the table below for the required fuse or circuit breaker size.
- Page 14 3.4.1 Func�on port defini�on ON DP 1 2 3 ATS Switch Parallel Inverter Switch G-start: 1,2 G-valve: 3,4 TEMP: 5,6 CT: 7,8 Meter Modbus 1 2 3 4 5 6 7 8 L ATS240V parallel_1 parallel_2 BMS 485/ Meter: For energy meter communica�on. Modbus: Reserved.
-
Page 15: Temp. Sensor
3.4.2 Temperature sensor connec�on for lead-acid ba�ery Inverter Temp. sensor - 13 -... - Page 16 3.5 Grid connec�on and backup load connec�on · Before connec�ng to the grid, a separate AC breaker must be installed between the inverter and the grid, and also between the backup load and the inverter. This will ensure the inverter can be securely disconnected during maintenance and fully protected from over current.
- Page 17 LOAD GRID LOAD GRID - 15 -...
-
Page 18: Pv Connection
Be sure that AC power source is disconnected before a�emp�ng to wire it to the unit. 3. Then, insert AC output wires according to polari�es indicated on the terminal block and �ghten terminal. Be sure to connect corresponding N wires and PE wires to related terminals as well. 4. - Page 19 3.6.1 PV Module Selec�on: When selec�ng proper PV modules, please be sure to consider below parameters: 1) Open circuit Voltage (Voc) of PV modules not exceeds max. PV array open circuit voltage of inverter. 2) Open circuit Voltage (Voc) of PV modules should be higher than min. start voltage. 3) The PV modules used to connected to this inverter shall be Class A ra�ng cer�fied according to lEC 61730.
- Page 20 Safety Hint: Please use approved DC cable for PV system. The steps to assemble the DC connectors are listed as follows: a)Strip off the DC wire about 7mm, disassemble the connector cap nut (see picture 3.3). �mm �mm Pic 3.3 Disassemble the connector cap nut b) Crimping metal terminals with crimping pliers as shown in picture 3.4.
- Page 21 d) Finally insert the DC connector into the posi�ve and nega�ve input of the inverter, shown as picture 3.6. Pic 3.6 DC input connec�on Warning: Sunlight shines on the panel will generate voltage, high voltage in series may cause danger to life. Therefore, before connec�ng the DC input line, the solar panel needs to be blocked by the opaque material and the DC switch should be 'OFF', otherwise, the high voltage of the inverter may lead to life- threatening condi�ons.
-
Page 22: Earth Connection(Mandatory)
3.7 Earth Connec�on(mandatory) Ground cable shall be connected to ground plate on grid side, this prevents electric shock if the original protec�ve conductor fails. Earth connec�on (Copper wires) Model Wire Size Cable(mm ) Torque value(max) 3.6/5/6kW 8AWG 1.2Nm Earth connec�on (Copper wires) (Bypass) Model Wire Size Cable(mm ) -
Page 23: Wiring System For Inverter
3.9 Wiring System for Inverter This diagram is an example for grid systems without special requirements on electrical wiring connec�on. Note: The load PE line and earthing bar must be grounded properly and DC Breaker effec�vely. Otherwise the back-up func�on may be abnormal when the grid fails. AC Breaker Load Battery... -
Page 24: Typical Application Diagram Of Diesel Generator
Remotely control signal line ① DC Breaker Generator Battery pack ① DC Breaker for battery SUN-3.6K-OG01LP1-EU-AM2: 120A DC breaker SUN-5K-OG01LP1-EU-AM2: 150A DC breaker Backup Load SUN-6K-OG01LP1-EU-AM2: 200A DC breaker ② AC Breaker for gen port SUN-3.6K-OG01LP1-EU-AM2: 40A AC breaker SUN-5K-OG01LP1-EU-AM2: 40A AC breaker SUN-6K-OG01LP1-EU-AM2: 40A AC breaker ③... -
Page 25: Single Phase Parallel Connection Diagram
BMS 485/ Ground Inverter Inverter ④ No.2 ① DC (slave) Breaker ⑤ ①②③ DC Breaker for battery SUN-3.6K-OG01LP1-EU-AM2: ② DC 120A DC breaker Breaker SUN-5K-OG01LP1-EU-AM2: ⑥ 150A DC breaker SUN-6K-OG01LP1-EU-AM2: 200A DC breaker ④⑥⑧ AC Breaker for grid port SUN-3.6K-OG01LP1-EU-AM2: ⑦... -
Page 26: Three Phase Parallel Inverter
3.12 Three phase Parallel Inverter ①②③ DC Breaker for battery SUN-3.6K-OG01LP1-EU-AM2: 120A DC breaker SUN-5K-OG01LP1-EU-AM2: 150A DC breaker SUN-6K-OG01LP1-EU-AM2: 200A DC breaker ⑤ AC Breaker for grid port SUN-3.6K-OG01LP1-EU-AM2: 40A AC breaker SUN-5K-OG01LP1-EU-AM2: 40A AC breaker SUN-6K-OG01LP1-EU-AM2: 40A AC breaker ④... -
Page 27: Operation
4. OPERATION 4.1 Power ON/OFF Once the unit has been properly installed and the ba�eries are connected well, simply press On/Off bu�on(located on the le� side of the case) to turn on the unit.When system without ba�ery connected, but connect with either PV or grid, and ON/OFF bu�on is switched off, LCD will s�ll light up(Display will show OFF), In this condi�on, when switch on ON/OFF bu�on and select NO ba�ery, system can s�ll work. -
Page 28: Lcd Display Icons
5. LCD Display Icons 5.1 Main Screen The LCD is a touchscreen, below screen shows the overall informa�on of the inverter. 2025-01-21 11:24:32 Tue 0.00 0.00 0.00/0.0V 0.00 1. The icon at the center of the screen indicates whether the system is under normal opera�on or not, displaying “ON”... -
Page 29: Work Mode
5.1.1 LCD opera�on flow chart Solar Graph Grid Grid Graph Information Main Screen Home Load Load Graph Battery BMS Graph Basic Setup Battery Setup Grid Setup Setting Gen PORT USE Work Mode Advanced Function - 27 -... -
Page 30: Solar Power Curve
5.2 Solar Power Curve This is Solar Panel detail page. Power: Current solar panel genera�on power. Power Today 0.0 kWh Today/Total: Today's and total genera�on energy. 0.00 kW Voltage,Curren,Power of each MPPT at current �me. Total 0.0 kWh PV1-V PV2-V PV1-I 0.0 A PV2-I... -
Page 31: Fault Code
Battery This is Ba�ery detail page. Ba�ery V: The ba�ery voltage uploaded by BMS. Charge I: The charging current requested by BMS. BMS: Discharge I: The discharging current requested by Battery V 0.0 V BMS. Charge I 0.0 A Charge V: The charging voltage requested by BMS. SOC: The SOC of ba�ery uploaded by BMS. - Page 32 5.3 Se�ng Menu Setting This is Se�ng page, including six items: Basic Setup, Ba�ery Setup, Grid Setup, Gen PORT USE, Work Mode, Advanced Func�on. Basic Setup Battery Setup Grid Setup Setting Swipe up and down on the screen to switch op�ons. Gen PORT USE Work Mode Advanced Function...
-
Page 33: Basic Setup Menu
5.4 Basic Setup Menu Basic Setup This is Basic Setup page. Time: To set the local day and �me for the inverter. Display: To control the opera�ng status of the 2025/01/21 Time buzzer and LCD screen. 11:32:13 Factory Reset: Reset all parameters of the inverter. Beep-On Display Auto Dim-On... -
Page 34: Factory Reset
Factory Reset Click the “Factory Reset” op�on on“Basic Setup” page, the LCD screen will turn to this page, an you can press the “Enter” bu�on to enter the verify page or press the “Esc” bu�on to back to the previous page. Confirm Factory Reset? Factory Reset Click “OK”... -
Page 35: Battery Setup Menu
5.5 Ba�ery Setup Menu Battery Setup This is Ba�ery Setup page. Batt Set1 Batt Set2 Batt Set3 Batt Set1 Ac�vate ba�ery: This feature will help recover a ba�ery that is over discharged by slowly charging from the solar array or grid. Activate Battery Mode Batt V... - Page 36 Parameters Ba� Capacity: The total capacity of ba�ery connected to this system, it can be used to calculated the SOC of ba�ery bank under the "Use AGM %" mode. Max A Charge/Discharge: Max ba�ery charging/ Batt Capacity discharging current. For AGM and Flooded, we recommend Ah ba�ery size x 20%= Charge/Discharge amps.
- Page 37 Batt Set3 When the “Ba� V” or “Ba� %” mode is selected, the content on the “Ba� Set3” page is shown as the figure on the le�. Float V 0.0 V 0.0V Shutdown Three stage charging strategy for lead-acid and imcompa�ble lithium ba�ery.
-
Page 38: Grid Setup Menu
5.6 Grid Setup Menu Grid Setup Mode: General Standard, UL1741 & IEEE1547, CPUC RULE21SRD-UL-1741, CEI 0-21, EN50549_CZ, Australia_A, Australia_B, Australia_C, Mode AS4777_NewZealand, VDE4105, OVE_Direc�ve_R25, General Standard EN50549_CZ_PPDS_L16A, NRS097, G98/G99, G98/G99_NI, ESB Networks(Ireland), C10/11. Frequency 50 Hz Please follow the local grid code and then choose the corresponding grid standard. -
Page 39: Gen Port Use Setup Menu
INV Output Voltage To set the rated output voltage of the inverter. 230V 220V 240V 200V 5.7 Gen PORT USE Setup Menu GEN port is a mul�func�onal port, but you can only Gen PORT USE choose one of the following two func�ons at a �me (Generator Input, SmartLoad Output). -
Page 40: Work Mode Setup Menu
5.8 Work Mode Setup Menu Work Mode Work Mode Energy pattern Zero Export To Load Batt First Load First Zero Export To CT Grid Peak Shaving Power Zero-export Power Max Solar Power Zero Export To Load: The AC output power will only supply the backup load and smart load(if any). -
Page 41: Advanced Function Setup Menu
5.9 Advanced Func�on Setup Menu BMS_Err_Stop: When it is ac�ve, if the ba�ery BMS Advanced Function failed to communicate with inverter, the inverter will stop working and report fault. BMS_Err_Stop Backup Delay: When the grid cuts off, the inverter will output power a�er this set �me. Backup Delay CT Ra�o: The ra�o of CT rated primary current to rated secondary current. -
Page 42: Advanced Function
Advanced Function Export power limter: It is used to setup the maximum output power allowed to flow to grid. Import power limiter: when it is ac�ve, the import Export power limiter Import power limiter power from grid will be limited. its priority is lower then “grid peak shaving”... -
Page 43: Mode
6. Mode Mode I: Zero export to Load AC cable DC cable Backup Load < Solar < Battery Grid Mode II: Zero export to CT AC cable DC cable Backup Load < Solar Battery On-Grid Home Load < Grid Mode III: Off-grid AC cable DC cable Backup Load... -
Page 44: Fault Information And Processing
Mode V: On-grid with generator AC cable DC cable Backup Load < Solar Battery Generator Grid < The 1st priority power of the system is always the PV power, then 2nd and 3rd priority power will be the ba�ery bank or grid according to the se�ngs. The last power backup will be the Generator (if any). - Page 45 Error code Description Solutions 1. When inverter is in Split phase(120/240Vac) or three-phase GFDI _Relay_Failure system (120/208Vac) system, the backup load port N line needs to connect ground; 2. If the fault still exists, please contact us for help. 1. When the grid type and frequency changed it will report F13; 2.
- Page 46 Error code Description Solutions 1. Check the backup load connected, make sure it is in allowed power range; ACOvercurrent fault 2. If the fault still exists, please contact us for help. No Utility 1. Please confirm grid is lost or not; No AC grid 2.
- Page 47 Under the guidance of our company, customers return our products so that our company can provide service of maintenance or replacement of products of the same value. Customers need to pay the necessary freight and other related costs. Any replacement or repair of the product will cover the remaining warranty period of the product.
-
Page 48: Datasheet
9. Datasheet SUN-3.6K- SUN-5K- SUN-6K- Model OG01LP1-EU-AM2 OG01LP1-EU-AM2 OG01LP1-EU-AM2 Battery Input Data Ba�ery Type Lead-acid or Lithium-ion Ba�ery Voltage Range(V) 40-60 Max. Charging Current(A) Max. Discharging Current(A) Charging Strategy for Li-Ion Ba�ery Self-adap�on to BMS Number of Ba�ery Input PV String Input Data Max. - Page 49 Equipment Protection DC Polarity Reverse Connec�on Protec�on AC Output Overcurrent Protec�on AC Output Overvoltage Protec�on AC Output Short Circuit Protec�on Thermal Protec�on DC Terminal Insula�on Impedance Monitoring DC Component Monitoring Ground Fault Current Monitoring Arc fault circuit interrupter (AFCI) Op�onal Power Network Monitoring Earth Fault Detec�on DC Input Switch...
- Page 50 10. Appendix I Defini�on of RJ45 Port Pin for BMS BMS 485/CAN Port BMS 485/CAN Pin BMS-485_B 1 2 3 4 5 6 7 8 BMS-485_A BMS-GND_485 CAN-H CAN-L BMS-GND_485 BMS-485_A BMS-485_B Defini�on of RJ45 Port Pin for Meter Meter Port Meter Pin Meter-485-B 1 2 3 4 5 6 7 8...
- Page 51 Add.: No.26 South YongJiang Road, Daqi, Beilun, NingBo, China. Tel.: +86 (0) 574 8622 8957 Fax.: +86 (0) 574 8622 8852 E-mail: service@deye.com.cn Web.: www.deyeinverter.com...
