Grid-connected PV Inverter
SUN-3.6K-G05P1-EU-AM2
SUN-4.2K-G05P1-EU-AM2
SUN-5K-G05P1-EU-AM2
SUN-6K-G05P1-EU-AM2
User Manual
R
SUN-4K-G05P1-EU-AM2
SUN-4.6K-G05P1-EU-AM2
SUN-5.2K-G05P1-EU-AM2
SUN-6.2K-G05P1-EU-AM2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUN-4K-G05P1-EU-AM2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Deye SUN-4K-G05P1-EU-AM2

Summary of Contents for Deye SUN-4K-G05P1-EU-AM2

  • Page 1 Grid-connected PV Inverter SUN-3.6K-G05P1-EU-AM2 SUN-4K-G05P1-EU-AM2 SUN-4.2K-G05P1-EU-AM2 SUN-4.6K-G05P1-EU-AM2 SUN-5K-G05P1-EU-AM2 SUN-5.2K-G05P1-EU-AM2 SUN-6K-G05P1-EU-AM2 SUN-6.2K-G05P1-EU-AM2 User Manual...

  • Page 2: Table Of Contents

    Contents 1. Introduction - 1 - 1.1 Appearance Introduction - 1 - 1.2 Labels description - 2 - 1.3 Parts list - 2 - 1.4 Product handling requirements - 3 - 2. Safety warnings and instructions - 4 - 2.1 Safety signs - 4 - 2.2 Safety instructions - 4 -...
  • Page 3 6. Startup and Shutdown - 27 - 6.1 Start up the inverter - 27 - 6.2 Inverter Shutdown - 27 - 6.3 Anti-PID Function(optional) - 28 - 7. Zero-export function via energy meter - 29 - 7.1 Use of zero-export function - 38 - 7.2 Sensor Clamp(optional) - 38 -...

  • Page 4: About This Manual

    Documents must be stored carefully and be available at all times. Contents may be periodically updated or revised due to product development. The information in this manual is subject to change without notice.The latest manual can be acquired via service@deye.com.cn Photovoltaic Grid-connected System...

  • Page 5: Labels Description

    1.2 Labels description Description Label Caution, risk of electric shock symbol indicates important safety instructions, which if not correctly followed, could result in electric shock. The DC input terminals of the inverter must not be grounded. CE mark of conformity Please read the instructions carefully before use.

  • Page 6: Product Handling Requirements

    DDSU666 DIN-RAIL METER 230V 5(60) A 800imp/kWh Solar Photovoltaic Connector Special Spanner x1 Meter(optional) x1 Sensor Clamp(optional) x1 1.4 Product handling requirements Lift the inverter out of the packaging box and transport it to the designated installation location. transport CAUTION: Improper handling may cause personal injury! Arrange an appropriate number of personnel to carry the inverter according to its weight, and installation personnel should wear protective equipment such...

  • Page 7: Safety Warnings And Instructions

    2. Safety warnings and instructions Improper use may result in potential electric shock hazards or burns. This manual contains important instructions that should be followed during installation and maintenance. Please read these instructions carefully before use and keep them for future reference. 2.1 Safety signs Safety symbols used in this manual, which highlight potential safety risks and important safety information, are listed as follows:...

  • Page 8: Notes For Using

    Warning: Inverter adopts non-isolated topology structure, hence must insure DC input and AC output are electrical isolated before operating the inverter. Shock Hazard: Prohibit disassembling inverter case, there existing shock hazard, which may cause serious injury or death, please ask qualified person to repair. Shock Hazard: When PV module is exposed to sunlight, the output will generate DC voltage.

  • Page 9: Operation Interface

    3. Operation Interface 3.1 Interface View Normal Alarm Pic 3.1 Front panel display 3.2 Status Indicator There are four LED status indicator lights in the front panel of the inverter. Please see table 3.1 for details. Indicator status Explanation Inverter detects DC input ●...

  • Page 10: Buttons

    3.3 Buttons There are four keys in the front panel of the Inverter(from left to right): Esc, Up, Down and Enter keys. The keypad is used for: ● Scrolling through the displayed options (the Up and Down keys); ● Access to modify the adjustable settings (the Esc and Enter keys). Down Enter 3.4 LCD Display...

  • Page 11: Product Installation

    4. Product installation 4.1 Select installa�on loca�on To select a location for the inverter, the following criteria should be considered: WARNING: Risk of fire ● Do not install the inverter in areas containing highly flammable materials or gases. ● Do not install the inverter in potentially explosive atmospheres. ●...
  • Page 12 ● Install on a wall or strong structure capable of bearing the weight. ● Install vertically with a maximum incline of +15°. If the mounted inverter is tilted to an angle greater than the maximum noted, heat dissipation can be inhibited, and may result in less than expected output power.

  • Page 13: Installations Tools

    ≥500mm ≥500mm Pic 4.3 Installation Gap 4.2 Installations Tools Installation tools can refer to the following recommended ones. Also, use other auxiliary tools on site. table 4-1 Tool specification Protective goggles Anti-dust mask Earplugs Work gloves Work shoes Utlity Knife Slotted screwdriver Cross screwdriver Percussion drill...

  • Page 14: Inverter Installation

    4.3 Inverter Installa�on The inverter is designed according to the wall mounted type installation, please use the wall mounted (the brick wall of the expansion bolt) when installing. Anchoring Mounting bracket Stainless steel screws Inverter Pic 4.4 Inverter Installation - 11 -...
  • Page 15 Procedure shows below: 1. Locate on the appropriate wall according to the bolt position on the mounting bracket, then mark the hole.On the brick wall, the installation must be suitable for the expansion bolt installation. Pic 4.5 Inverter hanging plate installation 2.

  • Page 16: Electrical Connection

    5. Electrical Connection 5.1 PV Module Selection: When selecting proper PV modules, please be sure to consider below parameters: 1) Open circuit Voltage (Voc) of PV modules not exceeds max. PV array open circuit voltage of inverter. 2) Open circuit Voltage (Voc) of PV modules should be higher than min. start voltage. 3) The PV modules used to connected to this inverter shall be Class A rating certified according to lEC 61730.
  • Page 17 Safety Hint: Please use approved DC cable for PV system. Cross section（mm ） Cable type Range Recommended value Industry generic PV cable 2.5-4 2.5(12AWG) (model: PV1-F) (12-10AWG) Table 5.1 DC Cable Specifications The steps to assemble the DC connectors are listed as follows: a)Strip off the DC wire about 7mm, disassemble the connector cap nut (see picture 5.3).

  • Page 18: Ac Input Terminal Connection

    DC input current should be 20A. if exceeds, it may damage the inverter and it is not covered by Deye warranty. 5.3 AC input terminal connection Do not close the DC switch immediately after the DC terminal has been connected. Connect the AC wires to the AC terminals on the AC side of the inverter.

  • Page 19: The Connection Of The Ground Line

    Cable CSA Breaker Model Max cable length SUN-6K-G05P1-EU-AM2 4.0mm 40A/400V Outside cable (L+N+PE)20m SUN-6.2K-G05P1-EU-AM2 4.0mm 40A/400V Table 5.2 Cable information 5.4 The connection of the ground line Good grounding is good for resisting surge voltage shock and improving EMI performance. Therefore, before connecting AC, DC and communication cables, you need to ground the cable firstly.

  • Page 20: Max. Over Current Protection Device

    In order to protect the inverter AC connection, it is recommended to install a circuit breaker to prevent overcurrent. See table 5.3 below. Rated output Rated output Current for protection Inverter voltage(V) current(A) device(A) SUN-3.6K-G05P1-EU-AM2 220/230 16.4/15.7A SUN-4K-G05P1-EU-AM2 220/230 18.2/17.4A SUN-4.2K-G05P1-EU-AM2 220/230 19.1/18.3A SUN-4.6K-G05P1-EU-AM2 220/230 21.0/20.0A SUN-5K-G05P1-EU-AM2 220/230 22.8/21.8A 220/230 SUN-5.2K-G05P1-EU-AM2...

  • Page 21: Monitoring Platform

    5.7 Monitoring Platform This series has built-in WIFI modular which is able to connect router Single-phase inverter directly. For WIFI configuration, please check the manual of “Built-in WIFI modular Single-phase inverter WIFI configuration Manual” . Web monitoring address: https://pro.solarmanpv.com;(for Solarman distributor account) https://home.solarmanpv.com(for Solarman end user account) For mobile phone monitoring system, scan the QR code to download the APP.

  • Page 22: How To Connect The Single-Phase Inverter To The Router Via Web

    :3907047089 Also, the default password can be changed. If forgetting the modified password, please contact service@deye.com.cn for help. 3. Open a browser and enter 10.10.100.254. Both username and password are "admin". (Recommended browser: IE 8+, Chrome 15+, Firefox 10 + ).
  • Page 23 Status Help Inverter information Wizard Inverter serial number Quick Set Firmware version(main) The device can be used as Advanced Firmware version(slave) a wireless access point(AP mode) to facilitata users to Upgrade Inverter model configure the device, or it can also be used as a Rated power Restart wireless information terminal...
  • Page 24 6. Enter the password and click Next. Status Help Wizard Quick Set Please fill in the following information: Most systems support the Advanced function of DHCP to obtain IP address automatically. Upgrade Please select disable and Password(8-64 bytes) add it manually if your router Restart (Note: case sensitive) does not support such...
  • Page 25 Status Wizard Help Setting complete! Quick Set After clicking OK,the system will restart Advanced Click OK, the settings will take effect and the system will immediately. Upgrade restart immediately. Restart If you leave this interface without clicking OK, the settings will Reset be ineffective.

  • Page 26: How To Connect In App

    5.9 How to connect in APP 1. Registration Open the app of SOLARMAN Smart and register an account. Click "Register" and create your account here. Register English SOLARMAN Smart Phone Number E-mail E-mail Phone Number Username E-mail E-mail Please enter E-mail E-mail Password Verification Code...
  • Page 27 3. Add a Logger Optional 1: Enter the logger SN manually. Optional 2: Click the icon in the right and scan the QR code to enter logger SN. You can find logger SN on the carton packaging or on the logger body. MY Plants Add a Logger Create a Plant...

  • Page 28: User Manual For Solarman Smart App

    5.10 USER MANUAL for SOLARMAN Smart APP 1.Add a Logger Method 1: Enter logger SN manually. Method 2: Click the icon in the right and scan to enter logger SN You can find logger SN in the external packaging or on the logger body. MY Plants Add a Logger Create a Plant...
  • Page 29 Step 2: Please wait for a few minute. Then click "Done" and view plant data. Device Configuration Countdown Configurtion succeeded Device data will be displayed in 10 mins. After that, you can check device status in device list. Done Please shorten the distance between the device, router and phone.

  • Page 30: Startup And Shutdown

    6. Startup and Shutdown Before starting the inverter, make sure that the inverter can meet the following conditions, otherwise it may result in fire or damage to the inverter. In this case, we do not undertake any responsibility. At the same time, to optimize the system configuration, it is recommended that the two inputs be connected to the same number of photovoltaic modules.

  • Page 31: Anti-Pid Function(Optional)

    6.3 Anti-PID Function(option) Inverter The Anti-PID module repairs the PID effect of the PV module at night.The PID module always runs when connected to AC. If maintenance is required and turn off the AC switch can disable the Anti-PID function. WARNING: The PID functionality is automatic.When the DC bus voltage is below 50VDC, the PID module will create 450VDC between the PV and ground.No control and equipment are required.

  • Page 32: Zero-Export Function Via Energy Meter

    7. Zero-export function via energy meter When you are reading this, we believe that you have completed the connection according to the requirements of chapter 5, if you have been running your inverter at this time, and you want to use the zero-export function, please turn off AC and DC switch of the inverter, and wait for 5 minutes unti the inverter completely discharged.
  • Page 33 Inverter WIFI Breaker Solar Panel array Family load 230V/2T meter RS 485 connector Limiter B GND 1+COM Grid 485_A 485_B Pic 7.2 Connection diagram of EASTRON meter Meter SN:2 Pic 7.3 Parameter setting When the EASTRON meter connected Power: successfully, it will shows SN: 2 Safety Hint: Ensuring grid input cables connect 1&3 port of energy meter, and inverter AC output cables connect 2&4 port of energy meter when connecting.
  • Page 34 Grid voltage sample RS 485 9 10 EASTRON SPLIT CORE CT ESCT TA16 600v,CAT II I，50-60Hz Accuracy:0.5% White S Black Rated Input 120A Rated Output 40mA ZR20220513 SDM120CTM-40mA (ESCT-TA16 120A/40mA) Pic 7.4 EASTRON meter Inverter WIFI Breaker Solar Panel array Family load RS 485 connector...
  • Page 35 System connection diagram for the CHNT meter Grid Load/Inverter RS 485 DDSU666 DIN-RAIL METER 230V 5(60) A 800imp/kWh CHNT DDSU666 Pic 7.6 CHNT meter Inverter WIFI Breaker Solar Panel array Family load Limiter RS 485 connector meter 485_A 485_B Grid Pic 7.7 Connection diagram of CHNT meter Pic 7.8 Parameter setting Meter...
  • Page 36 white blue DDSU666 RS 485 Input Single-Phase Smart Meter Grid voltage sample 230V 100A/40mA 50/60Hz Current Transformer 5 6 24 25 CTF16-2k5-100 In:100A DDSU666-CT (CTF16-2K5-100A) Pic 7.9 CHNT meter Inverter WIFI Breaker Solar Panel array Family load meter RS 485 connector Limiter blue...
  • Page 37 System connection diagram for the Eastron meter Grid Load/Inverter RS 485 230V/2T 1+COM EASTRON SDM230 Pic 7.11 EASTRON meter Master(Mst) RS485 Limiter Grid L N PE 485_A 485_B Grid meter Limiter Limiter Slave1(Slv1) Slave2(Slv2) RS485 RS485 AC Breaker Master(Mst) load AC Breaker WIFI Solar Panel array...
  • Page 38 Grid voltage sample RS 485 9 10 EASTRON SPLIT CORE CT ESCT TA16 600v,CAT II I，50-60Hz Accuracy:0.5% White S Black Rated Input 120A Rated Output 40mA ZR20220513 SDM120CTM-40mA (ESCT-TA16 120A/40mA) Pic 7.13 EASTRON meter Master(Mst) Limiter RS485 Grid L N PE 485_A 485_B Grid meter...
  • Page 39 Grid Load/Inverter RS 485 DDSU666 DIN-RAIL METER 230V 5(60) A 800imp/kWh CHNT DDSU666 Pic 7.15 CHNT meter Master(Mst) AC Breaker WIFI Ground Solar Panel array Slave1(Slv1) AC Breaker WIFI Solar Panel array Slave2(Slv2) AC Breaker WIFI Solar Panel array AC Breaker load Master(Mst) RS485...
  • Page 40 white blue DDSU666 DDSU666 RS 485 Input Single-Phase Smart Meter Grid voltage sample 230V 100A/40mA 50/60Hz Current Transformer 5 6 24 25 CTF16-2k5-100 In:100A DDSU666-CT (CTF16-2K5-100A) Pic 7.17 CHNT meter Master(Mst) AC Breaker WIFI Solar Panel array Ground Slave1(Slv1) AC Breaker WIFI Solar Panel array AC Breaker...

  • Page 41: Use Of Zero-Export Function

    7.1 Use of zero-export function When the connection is completed, the following steps should be refered to use this function: 1. Turn on the AC switch. 2. Turn on the DC switch, waiting for the inverter's LCD is turned on. 3.
  • Page 42 7.2.1 Zero-export function via CT When you are reading this, we believe that you have completed the connection according to the requirements of chapter 5, if you has been running your inverter at this time, and you want to use the limiter function, please turn off AC and DC switch of the inverter, and wait for 5 minutes until the inverter completely discharged.

  • Page 43: Use Of Limiter Function

    7.3 Use of limiter function When the connection is completed, the following steps should be refered to use this function: 1. Turn on the AC switch. 2. Turn on the DC switch, waiting for the inverter's LCD is turned on. 3.

  • Page 44: How To Browse The Load Power Of Your Pv Grid-Tieplant On Monitoring Platform

    7.4 Notes while using zero export function For your safety and the operation of limiter function of the inverter, we put forward the following suggestions and precautions: Safety Hint: Under zero export mode we strongly recommend that the two PV arrays are formed by the same number of PV panels of the same size, which will make the inverter more responsive to limit the power.
  • Page 45 And then choose your system type as “Self-consumption” Edit Plant Cancel Done Address : Basic Info YongJiang Road, Beilum,NingBo, 315806, China System Info Yield Info Coordinates : Owner Info Longitude 19.03 Latitude 36.11 ” ” Time Zone : Creation Time : 2020/04/08 (UTC+08:00) Beijing,Chongqing,Hong Kong,Urumqi System Info...

  • Page 46: General Operation

    8. General Operation During normal operation, the LCD shows the current status of the inverter, including the current power, total generation, a bar chart of power operation and inverter ID, etc. Press the Up key and the Down key to see the current DC voltage, DC current, AC voltage, AC current, inverter radiator temperature, software version number and Wifi connection state of the inverter.

  • Page 47: The Initial Interface

    8.1 The initial interface From the initial interface, you can check PV power, PV voltage, grid voltage, inverter ID, model and other infomation. Power: Power: State: Standby State: Com.Error Total DC Power: Pic 8.2 The initial interface Press UP or Down, you can check inverter DC voltage, DC current, AC voltage, AC current and inverter radiator temperature(Temperature can only be seen by long pressing the button [ESC].

  • Page 48: Submenus In The Main Menu

    ExpEp: Daily energy sold to grid; ExpEp: 0.00KWh Total: Total energy sold to grid. Total : 0.00KWh Pic 8.8 Electrical energy Load Power: Pic 8.9 Load power LoadEp: Daily consumption; LoadEp: 0.00KWh Total: Total energy consumption. Total : 0.00KWh Pic 8.10 Load consumption E-Day: Daily generation;...

  • Page 49: Fault Record

    8.2.2 Fault Record It can keep eight fault records in the menu including time, customer can deal with it depends on the error code. Device Info. 1 F35 220209 02 Fault Record << 2 F35 220120 08 Pic 8.13 Fault Record 8.2.3 ON/OFF setting ON / OFF <<...

  • Page 50: System Param Setting

    8.2.4 Parameter setting There are four submenus in the setup.Setting includes system param, run param, protect param, comm.param. All of these information for maintenance reference. Setup << System Param << Param Protect Param Comm. Param << Pic 8.15 Submenus of the parameter setup 8.3 System param setting System Param includes time set, language set, display set and factory reset.

  • Page 51: Running Param Setting

    20200522 OK English << 08:11:21 Cancel Polski Pic 8.17 Time P CCK << Bright Kepp << Nederland Delay time 05S Pic 8.18 Language Pic 8.19 LCD Screen settings Confirm Reset << Delay time 05S Cancel OK << Cancel Pic 8.21 Reset to factory setting Pic 8.20 Delay time set I Confirm <<...
  • Page 52 8.4.1 ActiveP setting ActiveP: Adjust the output active power in % ActiveP QMode --- << Pic 8.24 Vref ReactiveP: Adjust reactive power output in % ReactP 0.0% << Pic 8.25 PF:Power Fator -1.000 Fun_ISO: Insulation resistance detection Fun ISO OFF << Pic 8.26 Fun_RCD: Residual current detection Fun RCD...
  • Page 53 Exp Mode Exp Mode CT Ratio 1 << CT Ratio 1 << AUTO<- ACREL<- Back << Back << EASTRON<- CHNT<- Back << Back << Pic 8.29 Meter Feed_In %: it is used to deploy how much Limiter ON << power can be feed into grid. For example, Feed_in=50% of the 6W model, Feed-in which means Max.
  • Page 54 0.0V <- V10: 0.0V <- 0.0A 0.0A V12: 0.0V <- V11: 0.0V <- 0.0A 0.0A DC1->Wind OFF Cancel << DC1->Wind OFF Pic 8.31 WindTurbine OFDerate --- <- Pic 8.32 Arc-Fault Detection OFDerate:Over Frequency Derate OFDerate --- UFUprate:Under Frequency Uprate UFUprate --- << WGra WGraStr --- <<...

  • Page 55: Protect Param Setting

    8.5 Protect Param setting Warning: Engineer Only. We will set the param depends on the safety requirements, so customers don't need to reset it. The password is same as 8.4 Running param PassWord GridStanderd << Advanced Back << Pic 8.34 Password Brazil EN50438 EN50549-1-PL <<...
  • Page 56 OverVolt OverVolt Point 240.0V << Delay 1000ms << OverVolt OverVolt Point 240.0V << Delay 1000ms << OverVolt OverVolt Point 240.0V << Delay 1000ms << UnderVolt UnderVolt Point 235.0V << Delay 1000ms << UnderVolt UnderVolt Point 235.0V << Delay 1000ms << UnderVolt UnderVolt Point...

  • Page 57: Comm. Param Setting

    UnderFreq Lv2 UnderFreq Lv2 Point 48.00Hz << Delay 1000ms << UnderFreq Lv3 UnderFreq Lv3 Point 48.00Hz << Delay 1000ms << Reconnection Reconnection --- << Vdown --- << Reconnection Reconnection --- << Fdown --- << OV 10 Minutes 10 Minutes Enable --- <<...

  • Page 58: Repair And Maintenance

    Check the solar panel output connection. Failure in reading memory (EEPROM). Restart the inverter if the Read the memory error fault still exists, contact your installer or Deye service. Failure in writing memory (EEPROM). Restart the inverter if the Write the memory error fault still exists, contact your installer or Deye service.
  • Page 59 AC over current fault of hardware 2. Restart the inverter or factory reset, if the error still exists, please contact your installer or Deye service. 1. When inverter is running, wifi plug plugin,will occur F19. 2. Restart the inverter or factory reset, if the error still exists, All hardware failure synthesis please contact your installer or Deye service.
  • Page 60 3. Check if the software is not suitable for this inverter. (Old AC main contactor failure inverter not have relays detection function) 4. restart the inverter, if the fault still exists, contact your installer or Deye service. Dc boost soft start Not avaiable. Inverter 2 dc high fault Hardly appear the code.
  • Page 61 F56, maybe Loss of driver or need update DC busbar voltage is too low firmware. 3. Restart the inverter, if the fault still exists, contact your installer or Deye service. AC reverse irriga�on. AC reverse irrigation AC grid U over current Hardly appear the code.

  • Page 62: Specification

    11.Specification SUN-3.6K- SUN-4K- SUN-4.2K- SUN-4.6K- Model G05P1-EU-AM2 G05P1-EU-AM2 G05P1-EU-AM2 G05P1-EU-AM2 PV String Input Data Max. PV Input Power(kW) Max. PV Input Voltage(V) Start-up Voltage(V) PV Input Voltage Range(V) 80-550 MPPT Voltage Range(V) 70-500 Rated PV Input Voltage(V) Full Load MPPT Voltage Range(V) 130-500 145-500 150-500...
  • Page 63 Interface RS485 Communication Interface GPRS/Bluetooth/4G/WIFI Monitor Mode Display LCD+LED General Data Operating Temperature Range (°C) -25 to +60℃,>45℃ derating Permissible Ambient Humidity 0-100% Permissible Altitude (m) 3000m Noise (dB) ≤ 35dB Ingress Protection(IP) Rating IP 65 Inverter Topology Non-Isolated Over Voltage Category OVC II(DC),OVC III(AC) Cabinet Size（W*H*D）[mm] 305×280×180（Excluding connectors and brackets）...
  • Page 64 SUN-5K- SUN-5.2K- SUN-6K- SUN-6.2K- Model G05P1-EU-AM2 G05P1-EU-AM2 G05P1-EU-AM2 G05P1-EU-AM2 PV String Input Data Max. PV Input Power(kW) Max. PV Input Voltage(V) Start-up Voltage(V) PV Input Voltage Range(V) 80-550 MPPT Voltage Range(V) 70-500 Rated PV Input Voltage(V) Full Load MPPT Voltage Range(V) 180-500 190-500 215-500...

  • Page 65: Eu Declaration Of Conformity

    ・ Radio Equipment Directive 2014/53/EU (RED) ・ Restriction of the use of certain hazardous substances 2011/65/EU)(RoHS) NINGBO DEYE INVERTER TECHNOLOGY CO.,LTD. confirms herewith that the products described in this document are in compliance with the fundamental requirements and other relevant provisions of the above mentioned directives. The entire EU Declaration of Conformity and certificate can be found at https://www.deyeinverter.com/download/#string-inverter.
  • Page 66 2024-08-21 Ver: 2.5 - 63 -...
  • Page 67 Add. : No.26 South YongJiang Road, Daqi, Beilun, NingBo, China. Tel. : +86 (0) 574 8622 8957 Fax. : +86 (0) 574 8622 8852 E-mail : service@deye.com.cn Web. : www.deyeinverter.com...

This manual is also suitable for:

Sun-4.6k-g05p1-eu-am2Sun-5.2k-g05p1-eu-am2Sun-6.2k-g05p1-eu-am2Sun-6k-g05p1-eu-am2Sun-5k-g05p1-eu-am2Sun-4.2k-g05p1-eu-am2 ... Show all
