Hillco JH7020 Operator's Manual

Hillside leveling system s660, s670, s680 & s690, s760, s770, s780 & s790
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
D-180215CMA01C
Operator's Manual
Model JH7020 & JH9020
Hillside Leveling System
S660, S670, S680 & S690
S760, S770, S780 & S790
WARNING
Read and understand
operator's manual prior to
operating this equipment.
Failure to follow operation
instructions could result in
personal injury or damage to
the equipment.
Hillco Technologies, Inc.
1
(SN23001-23999)
D-180215CMA01C
Sept. 2022

Advertisement

Table of Contents
loading

Related Manuals for Hillco JH7020

Summary of Contents for Hillco JH7020

  • Page 1 Operator’s Manual (SN23001-23999) Model JH7020 & JH9020 Hillside Leveling System S660, S670, S680 & S690 S760, S770, S780 & S790 D-180215CMA01C WARNING Read and understand operator’s manual prior to operating this equipment. Failure to follow operation instructions could result in personal injury or damage to the equipment.

  • Page 2: Table Of Contents

    Contents Model and Serial Number ....................1 Maximum Header Weights ....................1 Introduction .........................2 Safety ..........................3 Signal Words .....................3 Operation Safety ....................4 Hydraulic Safety....................4 Service and Maintenance Safety ...............5 Highway Operation and Transport Safety ............5 Safety Labels .....................6 Product Description ......................10 Controls and Components ................11 Leveling Control Switches &...
  • Page 3 Hydraulic Settings......................52 Hydraulic Hoses ......................52 Hydraulic Cylinder ......................52 Decal Placement ......................53 Header Compatibility Chart ................... 55 Leveling System Specifications ..................56 Electrical Schematics ....................58 Hydraulic Schematics ....................64 Notes ..........................71 D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 4 Hillco is for the sole purpose of identifying such goods and shall not create an express warranty that the goods shall conform to such description.

  • Page 5: Model And Serial Number

    Hillco does not guarantee any non-John Deere header applications and will not be responsible for any damage incurred from improper header configurations. Please call Hillco Technologies if you have any questions regarding the JH7020 & JH9020 or any other header configuration.

  • Page 6: Introduction

    Operator’s Manual. If extra copies of the operator’s manual are needed, contact Hillco at 1-800-937-2461 or download it from Hillco Technologies’ website at www.hillcotechnologies.com Keep this manual handy for frequent reference and to pass on to new operators or owners.

  • Page 7: Safety

    This Safety Alert symbol means ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! The Safety Alert symbol identifies important safety messages on the Hillco Leveling System and in the manual. When you see this symbol, be alert to the possibility of personal injury or death.

  • Page 8: Operation Safety

    6. Ensure all fittings and hoses are in good repair. 7. Do not make any repairs to the leveling system hydraulic system including: valves, hydraulic hoses, adapters, pumps, manifolds, or reservoirs without first contacting your authorized Hillco dealer. D-180215CMA01C Hillco Technologies, Inc.

  • Page 9: Service And Maintenance Safety

    3. Make sure the Auto/Off/Manual leveling toggle switch is in the “Off” position for all transport and highway travel situations. 4. Always travel at a safe speed. Use caution when making corners or meeting traffic. D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 10: Safety Labels

    3. After the area has completely dried, peal the backing off the safety label and place it onto the cleaned area. 4. Make sure all areas of the label have adhered to the machine by pressing down on the entire face of the label, including the corners. D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 11 LL20-100784 CAUTION This machine is equipped with a Leveling System. Make sure the Auto/Manual leveling control switch is in the manual position before starting machine. Read operator’s manual before operating this machine. LL20-100782 D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 12 Use caution when using ladder. LL20-100785 CAUTION LeveLing SyStem Hazard this machine is equipped with a leveling system. Combine chassis moves independent of carriage. read operator’s manual and be aware of hazardous areas at all times. LL20-100787 D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 13 DANGER AVOID CRUSHING INJURY Install safety stops on the main leveling cylinders before performing repair or maintenance on the leveling system to prevent accidental tipping of combine chassis. LL-143621 D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 14: Product Description

    Product Description The Hillco Hillside Leveling System is designed for John Deere S Series combines. Hillco designed the Hillside Leveling System to maintain the combine’s thrashing capacity and harvesting efficiency on contours of slopes up to 27%. This leveling system is designed to be installed with little modification to the combine.

  • Page 15: Controls And Components

    Manual Leveling Speed Joystick calibrations Auto/Manual Leveling Detail description of the monitor and adjustable settings are later in this manual. Manual Tilt Manual Tilt For operation of the leveling system see the Left Right Operation section. D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 16: Hydraulic Gear Pump

    (B). This valve is located on the left side of the combine below the cab. From this oil flows to the Hillco leveling valve located behind the inspection door on the operator’s platform. Oil is returned from the leveling valve to header height valve block.

  • Page 17: Leveling Controller

    The hydraulic valve fully integrates with the combine’s electronics to provide auto lateral tilt. If the combine was originally equipped with Contour Master then the stock valve is used to control the header tilt. B - Header Trim Manifold D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 18: Overcarriage Position Indicator

    B - Clinometer Transition The transition is added to the front of the feeder house to pivot the header and allow it to follow the contour of the ground. D - Transition D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 19: Header Position Sensor

    Make sure that the gas-charged struts (B) keep the ladder fully retracted. Replace the struts if they appear to be weak. If the ladder does not fully retract, permanent damage may occur during field operation. B - Gas-charged Struts D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 20: Mechanical Leveling Cylinder Stops

    1/4” between the driveshafts and the leveling system chassis. Add cylinder stops to prevent the cylinder from over-leveling the combine. Contact Hillco for these cylinder stops. A - Mechanical Leveling Cylinder Stops...

  • Page 21: Leveling Cylinder Safety Stops

    Because of the increased rotation of the rear axle it is necessary to space the rear wheels out to avoid interference with shields. See the Rear Axle Spacing Chart for more information. C - Drop Axle D - Drop Axle Wing D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 22: Header Tilt Control Switches

    In case the header contacts the ground, a relief valve prevents damage to the header and feeder house. C - Slave Cylinder D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 23: Operation, Setup, And Maintenance

    Do not unload grain from the combine while CAUTION operating the Leveling System in Automatic Mode. The chassis may tilt unexpectedly and cause damage to the unloading auger. D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 24: Leveling System Controls

    C - Auto/Manual Indicator D - Manual Left E - Manual Right Leveling Controls: Located on the right side of the JD monitor. These switches allow for Auto/Manual control (B) and Left/Right leveling (C, D). D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 25: Maximum Level

    TILT LEFT: Push the switch to the left to tilt the header counterclockwise. TILT RIGHT: Push the switch to the right to tilt the header clockwise Header Trim Switch D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 26: Rear Wheel Assist Warning Alarm

    4WD Alarm Slope: 1 Disengage 4wd before heading downhill. Menu When the 4WD Alarm Sounds and Warning is displayed WARNING IMMEDIATELY DISENGAGE the Rear Wheel Assist or Control of the Combine COULD be lost. D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 27: Operator Adjustments

    Menu. Scroll up and down using the up and down arrows. When the desired function is highlighted select the enter button. To go back to the main menu select Manual Leveling Speed the Back button. Screen Brightness Smart Unload D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 28 Slower Faster Display Backlight The brightness can be adjusted up and down. Use the Screen Brightness up and down arrows (B) to adjust the brightness and then hit Enter to save the setting. Night D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 29 Press the ESC button to return to the previous screen. Calibration From the main menu, using the up/down arrows (C), Main Menu highlight calibration. Press enter (D). Operator Settings Calibration Diagnostics Active Alarms Continued on next page. Dealer Settings D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 30 The carriage can rotate until the Fore/Aft Clinometer cylinders bottom out. With the Joystick in the center position press the Enter button (C). Joystick Step 1 of 3 Joystick Output: 2452 With the joystick centered press the enter button D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 31 Press the ESC button (C) to return to the calibration menu. Joystick Step 3 of 3 Joystick Output: 2452 Hold the joystick fully to the Saved left and then press enter. Home Enter Home Enter D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 32 Press ESC (C) to return to the calibration Left/Right Clinometer menu. Place a level crossways on the cab floor Manually lean the chassis until the cab Saved floor is level Press Enter to save the level calibration point D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 33 If Level Limit Stops are used be sure that the left limit sensor has been cali- brated with that stop in place. Damage to the cylinderts or other leveling system components may occur if sensors aren’t set properly. D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 34 If Level Limit Stops are used be sure that the left limit sensor has been cali- Notice brated with that stop in place. Damage to the cylinders or other leveling system components may occur if sensors aren’t set properly. D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 35 Main Menu. Fore/Aft Clinometer Place a level lengthwise on the cab floor Position the combine until the cab floor Saved is level Press the Enter button to save the calibration point D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 36 The value for Level Zero Setpoint and 4WD Zero 4WD Zero Setpoint 2510 Setpoint (D) are the current calibration values. These values are set in the Calibration screen under Left/Right Clinometer and Fore/Aft Clinometer. D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 37 Valve Coils Range is from 0-18000. Valve Coils Only one coil will be activated at a time. Left Coil Current: Right Coil Current: Joystick Range is from 500-4500. Joystick Joystick Output: 2510 D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 38 Operator Settings Calibration Diagnostics Active Alarms Dealer Settings If you have an Active Alarm the warning icon will appear on the home screen in the upper left corner. Home Slope: 1 ROAD Menu Menu D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 39 Press esc key to clear ROAD Menu Menu Clinometer Fault Home Clinometer Fault Output out of range Fore/Aft output Slope: 1 Left/Right output 4 Automatic Leveling Disabled ROAD Press esc key to clear Menu Menu D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 40 Dealer Settings is a password protected screen that is Main Menu for dealers to make adjustments to the leveling system. Operator Settings Calibration Diagnostics Active Alarms Dealer Settings Password protected page: Dealer Settings Enter the Dealer Password to Continue 0000 D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 41: Storage

    This will ensure that there are not any unexpected weight shifts during the loading process. In addition to the Tie Down locations on the combine, Hillco provides T-hook slots (B) on the undercarriage for securing combine to the trailer.

  • Page 42: Maintenance

    Grease on 50 hour interval with little to no slippage. Grease daily in adverse feeding conditions where slippage may occur more often. Pump until grease comes out. 50 HRS Master and Slave Cylinder Spherical Bearings 50 HRS D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 43: Hydraulic Filter

    50 HRS Left Paddle Beater Bearing Hydraulic Filter On JH7020 models replace the filter (B) after the first 100 hrs of service, then 400 hr intervals. Replace with John Deere Filter Part No AH128449. Driveline Maintenance Standard PTO Style Drive Shafts - These drive shafts utilize a single cross at each end of the drive shafts.

  • Page 44: Transition Drive Chain

    If this is not done and the lines are just capped oil from the master cylinder has no place to go when the combine is leveled and failure will occur. D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 45: 100 Hour - Annual Maintenance

    Ladder pivots and locks into place Moving step retracts fully and operates smoothly Rear Wheels are properly spaced Failure to conduct these inspections may result in serious damage to CAUTION the combine, leveling system or could result in injury. D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 46: Critical Joint Inspection

    A - Hillco Spacer to John Deere Chassis (4 bolts on MY15-18, 6 bolts MY14 and older) 235 lb-ft B - Hillco Pin (4 bolts) 235 lb-ft C - Cast Standoff to Hillco Spacer (4 Bolts) S600 ( -78500) 258 lb-ft, S600 (785001- ) & S700 236 lb-ft. D - Cross Bolt (1 Bolt) 152 lb-ft Note: If any bolts are loose, remove bolt and apply Loctite 242 to threads, install and torque.
  • Page 47 A - Axle Straps (2 bolts) 375 lb-ft Transition A - Mounting Bolts (4 bolts) 235 lb-ft B - Pivot Bolts (2 bolts) 235 lb-ft C - Bottom Lock Bolts (2 bolts) 460 lb-ft D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 48: Adjustments

    Rear Axle Spacing On a combine equipped with a Hillco Leveler the rear axle has a greater rotation range. As a result the rear axle spacing must be changed to prevent shield interference. Refer to the diagram below and the following charts for Hillco’s rear axle spacing recommendations.

  • Page 49: Over Rotation Stop

    Lower Feeder Drum Stop Adjustment be sure to release the tension on the transition drive chain. Failure The Hillco leveling system does not change the to release the tension may cause feeder drum stop adjustment. Refer to the John damage to the sprockets or chain.

  • Page 50: Lateral Tilt Flow Control Adjustment

    Lateral Tilt Flow Control Adjustment For JH7020 & JH9020 Leveling Systems the lateral tilt flow control valve adjusts the speed at which the header rotates. The header should rotate at the chassis’ rotation rate. The tilt speed is a compromise between manual tilt mode and automatic tilt mode.

  • Page 51: Mechanical Leveling Cylinder Stops

    Hillco strongly recommends that cylinder stops be installed on the leveling cylinders. Hillco is not responsible for chassis damage that occurs due to the lack of appropriate cylinder stops.

  • Page 52: Header Tilt Setup

    7. Scroll down and select address 111 Input 10001000 8. This popup screen will appear. Select the Value (A). Device: CAB.001 | Addresss: 111 Address Address Type Network Input Vehicle Value 10001000 Hide Diagnostics Center D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 53 9. Enter the value 10001000 and select OK (A). Value 10001000 + / - Cancel 10. You will get a popup that says “Calibration Procedures Problem”. Select OK as this will be resolved when calibrated. D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 54: Tread Width

    Model JH7020 & JH9020 Drive & Steer Tire Assemblies – Combines equipped with the Model JH7020 or JH9020 Leveling System are required to use tires and wheels that meet or exceed Tire & Rim Association standards for Hillside Combine applications. Contact Hillco for more information.

  • Page 55: Rear Axle Toe In

    When first operating the Model JH7020 or JH9020 Leveling System in hillside conditions, begin operation on gradual slopes and work up to more severe slopes only after you have determined that rear axle weighting is appropriate for downhill maneuvers. The first indication of insufficient rear axle weighting is sluggish or unresponsive steering while traveling down hill.

  • Page 56: Hydraulic Settings

    Hydraulic Settings Refer to the Hydraulic Safety section for precautions regarding the hydraulic system. The Model JH7020 Leveling System uses an auxiliary gear pump and single-station manifold for its leveling and a separate header trim manifold. The Model JH9020 Leveling System uses hydraulic flow from the closed center hydraulics of the combine.

  • Page 57: Decal Placement

    Hillco Leveling System Model To determine if a header kit is required or available for a specific leveling system model match the appropriate header with the corresponding leveling system model to determine availability. Contact Hillco for pricing as well 2975H JH7020 JH9020...

  • Page 58: Leveling System Specifications

    Leveling System Specifications D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 59 Integrated into Combine’s Closed Leveling Hydraulic System Gear Pump Center Hydraulics Header Lateral Tilt Control Hydraulic Master / Slave Cylinder w/ Auto/Manual Override Feeder Transition Paddle Beater Weight added to combine 4,100 lbs 4,100 lbs D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 60: Electrical Schematics

    Electrical Schematics X046 X006 X200 X203 X101 X104 X300 X310 X311 D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 61 D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 62 D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 63 D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 64 JS9020 Header Trim Electrical Schematic SN 22001-22999 For Combines Equipped with Hillco Header Tilt Valve WIRING HARNESS 1320731 WHITE X880 BLACK HEADER TRIM MANIFOLD LOCATED ON GREEN X879 LEFT SIDE OF FEEDERHOUSE BLACK WHITE GREEN JOHN DEERE PLUG X879 LOCATION: Left side of Feederhouse...
  • Page 65 Trim Left Ground X001 GREEN Trim Right Power X001 X005 X006 Wire Color Description Connector Wire Color Description Connector WHITE Trim Left Power Trim Right Ground BLACK Trim Left Ground GREEN Trim Right Power D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...

  • Page 66: Hydraulic Schematics

    Hydraulic Schematics D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 67 D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 68 D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 69 D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
  • Page 70 80 Degree Walterscheid Driveline Maintenance Guide D-160831CMA01 August, 2016 D-180215CMA01C D-150223CMA01 Hillco Technologies, Inc. Sept. 2022...
  • Page 71 Lack of proper lubrication is the most common cause of universal joint, center housings, and slip joint problems. Hillco works closely with driveline manufacturers to develop drivelines rated for the thrust load and angle demands of each diff erent header.
  • Page 72 5 pumps of grease (about 15 grams). Inner cross kit also lubricates the double yoke. Lubri- cate with about 15 pumps of grease (about 45 grams). Consult operator’s manual for additional information. D-180215CMA01C D-150223CMA01 Hillco Technologies, Inc. Sept. 2022...

  • Page 73: Notes

    Notes D-180215CMA01C Hillco Technologies, Inc. Sept. 2022...
