- Page 1 Operator’s Manual (SN21001-21999) Model HC1010 Hillco Flex Harrow 48’, 60’, 72’ & 84’ D-170412CMA01C D-170412CMA01C Hillco Technologies, Inc. July, 2021...
-
Page 2: Table Of Contents
Maintenance and Service 10 Hr Service 50 Hr Service Annual Service Tire Pressure Center Frame Adjustments Push-Rod Latch Mount Latch Spring Pull Pin Hitch Height Wing Wheel Inspection Intervals Bolt Torque SAE Torque Chart D-170412CMA01C Hillco Technologies, Inc. July, 2021... -
Page 3: Serial Number Tag
3. After the area has completely dried, peal the backing off the safety label and place it onto the cleaned area. 4. Make sure all areas of the label have adhered to the machine by pressing down on the entire face of the label, including the corners. D-170412CMA01C Hillco Technologies, Inc. July, 2021... - Page 4 1. USE SAFETY STOPS ON WING CYLINDERS (A) WHEN IN TRANSPORT MODE. 2. STORE SAFETY STOPS ON WHEEL PIVOT MOUNT (B) WHEN IN FIELD MODE. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH 155682 D-170412CMA01C Hillco Technologies, Inc. July, 2021...
-
Page 5: Connecting To The Harrow
Do not park the harrow on a steep incline with the harrow in the field position. It is possible that the center of gravity may be such that there is no tongue weight allowing the back of the harrow to sit on the ground. This will result in the tongue lifting upward. D-170412CMA01C Hillco Technologies, Inc. July, 2021... -
Page 6: Transport To Field Position
5. After the pull arms pins have made contact with the latching pocket, finish rotating the wing wheels so they are pointed the same direction as the cart tires (F). D-170412CMA01C Hillco Technologies, Inc. July, 2021... - Page 7 (A) and locks into place. IMPORTANT! Be sure to visually check that the lock arm has fully engaged the pull arm pin before driving forward. 7. Drive forward slowly and lower the harrow into the field position. D-170412CMA01C Hillco Technologies, Inc. July, 2021...
-
Page 8: Field To Transport Position
(B). 6. Inspect the two center sections and the sections closest to the hinge to make sure that they are lying properly so the harrow sections won’t bind when turning corners. D-170412CMA01C Hillco Technologies, Inc. July, 2021... -
Page 9: Operation
Center of the turning radius is at the edge of the wing. Not the wing wheels. If you pivot around the wing wheels damage will occur. Center of Turning Radius D-170412CMA01C Hillco Technologies, Inc. July, 2021... -
Page 10: Maintenance And Service
Prior to each use, check for loose bolts and replace lost or worn parts. 10 Hour Service Zerks on left side shown. Repeat for right side. 10 HRS Pull Pins 10 HRS 10 HRS Latching Mechanism (2 per side) Swing Arm Pivots D-170412CMA01C Hillco Technologies, Inc. July, 2021... -
Page 11: Hr Service
Zerks on left side shown. Repeat for right side. 50 HRS 50 HRS 50 HRS Center Section Cylinder Mounts (2 per side) Wing Pivots (2 per side) Access to these zerks is easiest in field postion. D-170412CMA01C Hillco Technologies, Inc. July, 2021... -
Page 12: Annual Service
Rating @ 40 MPH Maximum Speed) Tire Pressure (11L-15 IL 12-ply) • Recommended Minimum Tire Pressure - 45 PSI • Maximum Tire Pressure - 52 PSI (3,200 LB Load Rating @ 30 MPH Maximum Speed) D-170412CMA01C Hillco Technologies, Inc. July, 2021... -
Page 13: Center Frame
Each tire has a load rating of 3,200 lbs per tire at 52 psi. The gross weight allowed on the center 4 tires is 12,800 for carts with dual center wheels. On carts with single center tires the max gross weight is 6,400 lbs. D-170412CMA01C Hillco Technologies, Inc. July, 2021... -
Page 14: Adjustments
Loosen the jam nut (B) on the clevis end of the pushrod. Adjust the pushrod until the latch plate clears the pin by about 1/16” (C). Retighten the jam nut. Reconnect support arm to pull arm and reinstall collar and bolt. 1/16” D-170412CMA01C Hillco Technologies, Inc. July, 2021... -
Page 15: Latch Mount
(G) seats into the cradle Tighten the (6) latch mount bolts Reinstall the pull arm to the swing arm Reinstall the pull spring & eyebolt Reconnect support arm to pull arm and reinstall collar and bolt. D-170412CMA01C Hillco Technologies, Inc. July, 2021... -
Page 16: Latch Spring
To bring the wing back move bushings from the outside (H) to the inside (G). To move the wing forward move bushings from the inside (G) to the outside (H). Reinstall pin, collar and retaining bolt. Reinstall pull arm. D-170412CMA01C Hillco Technologies, Inc. July, 2021... -
Page 17: Hitch Height
Adjust the wing wheel base cylinder mount until the straight edge is parallel to the wing tube (B) Retighten the jam nuts. This process can also be done with the harrow in the field position. D-170412CMA01C Hillco Technologies, Inc. July, 2021... -
Page 18: Inspection Intervals
The following bolts are torqued to special specifications because of the application in which they are used: Lift Arm Mounting Bolts (5/8-inch) = 110 lb-ft. (A) Harrow Pull Mounting Bolts (5/8-inch) = 120 lb-ft D-170412CMA01C Hillco Technologies, Inc. July, 2021... - Page 19 (Chain Must Be Able to Swivel) Draw Ring Bolts (1-inch) = 150 lb-ft. (E) - Pull Pin Bolts (1-inch) = Tighten until the bolt just begins to deflect the plates. (F) Pull Pin Mounting Bolts (5/8-inch) = 120 lb-ft. D-170412CMA01C Hillco Technologies, Inc. July, 2021...
- Page 20 Wing Cylinder Base Mount Bolts (5/8-inch) = 120 lb-ft. (A) Pushrod Clevis Bolts (5/8-inch) (B) Tighten until the bolt just begins to deflect the plates. Latch Mount Bolts (5/8-inch) = 150 lb-ft (C) D-170412CMA01C Hillco Technologies, Inc. July, 2021...
-
Page 21: Sae Torque Chart
D-170412CMA01C Hillco Technologies, Inc. July, 2021... - Page 22 NOTES D-170412CMA01C Hillco Technologies, Inc. July, 2021...
