Hillco WTR410 Operator's Manual / Parts Book

Wrap twine remover
Hide thumbs Also See for WTR410:
Table of Contents

Advertisement

Quick Links

Download this manual
D-211027DMC01B
D-250113DMC01A WTR410&WTR510(Ver1.5).indd 1
D-250113DMC01A WTR410&WTR510(Ver1.5).indd 1
Operators Manual & Parts Book
Hillco Technologies, Inc. 1010 1st Ave. Nezperce, Idaho
Phone: 800.937.2461
www.hillcotechnologies.com
Wrap Twine Remover
WARNING
Read and understand the
operator's manual prior to
operating this equipment.
Failure to follow operation
instructions could result in
personal injury or damage to
the equipment.
Model WTR410
Model WTR510
Patent Pending
D-211027DMC01B
January, 2025
January, 2025
5/23/2025 7:40:25 AM
5/23/2025 7:40:25 AM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WTR410 and is the answer not in the manual?

Questions and answers

Related Manuals for Hillco WTR410

Summary of Contents for Hillco WTR410

  • Page 1 Failure to follow operation instructions could result in personal injury or damage to the equipment. Hillco Technologies, Inc. 1010 1st Ave. Nezperce, Idaho Phone: 800.937.2461 www.hillcotechnologies.com D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 1 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 1...

  • Page 2: Table Of Contents

    Hydraulic Junction Cylinders Decals Electrical Hydraulic & Electrical Schematics Troubleshooting Contact Information Hillco Technologies, Inc. Phone 800-937-2461 1010 1st Avenue www.hillcotechnologies.com Nezperce, Idaho 83543 email: support@hillcotechnologies.com January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 2 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 2 5/23/2025 7:40:25 AM 5/23/2025 7:40:25 AM...

  • Page 3: General Information

    “ASM” is shown unless otherwise noted). Some assemblies have parts that are sold separately, however some must be purchased as a single unit. Hillco Product Specialists will be able to assist you with any questions. “Not Shown” refers to a part that is not depicted in the illustration.

  • Page 4: Statement Of Limited Warranty

    Hillco is for the sole purpose of identifying such goods and shall not create an express warranty that the goods shall conform to such description.

  • Page 5: Safety

    NOTICE - is used to address practices not related to physical injury. NOTICE D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 5 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 5 5/23/2025 7:40:26 AM 5/23/2025 7:40:26 AM...

  • Page 6: Operation Safety

    4. Before operating the WTR, ensure that there are no obstructions between or around the arms. 5. Maintain proper hydraulic fluid levels. 6. Ensure all fittings and hoses are in good repair. January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 6 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 6 5/23/2025 7:40:26 AM 5/23/2025 7:40:26 AM...

  • Page 7: Servicing And Maintenance Safety

    Wrap Twine Remover. When a decal displays this symbol, refer to the Operator’s Manual for further instructions. D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 7 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 7 5/23/2025 7:40:26 AM 5/23/2025 7:40:26 AM...

  • Page 8: Safety Labels

    4. Make sure all areas of the label have adhered to the machine by pressing down on the entire face of the label, including the corners. January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 8 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 8 5/23/2025 7:40:26 AM 5/23/2025 7:40:26 AM...
  • Page 9 Avoid bodily injury from hydraulic oil under pressure. Shut off engine and remove key before inspecting or servicing the hydraulic system. Do not search for high-pressure hydraulic leaks without hand and face protection 155136 D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 9 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 9 5/23/2025 7:40:28 AM 5/23/2025 7:40:28 AM...
  • Page 10 Connect the electrical plug near the manifold and the system will be ready for use. January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 10 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 10 5/23/2025 7:40:30 AM 5/23/2025 7:40:30 AM...

  • Page 11: Operation

    If WTR power is connected to permanent power, leave NOTICE the switch in the center (rotate) position to avoid draining the battery. D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 11 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 11 5/23/2025 7:40:30 AM 5/23/2025 7:40:30 AM...

  • Page 12: Best Practices

    Select Rotate and rotate the arms upward to pull the wrap free from the bale. Then tip the bale downward and allow it to slide forward off the spears. Discard wrap/twine in garbage. January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 12 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 12 5/23/2025 7:40:31 AM 5/23/2025 7:40:31 AM...

  • Page 13: Adjustments

    Do not use an electric or air impact gun to Important adjust hooks. This will cause the hooks to bind. Use hand ratchet only. D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 13 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 13 5/23/2025 7:40:31 AM 5/23/2025 7:40:31 AM...

  • Page 14: Arm Position

    The chains limit however far the first cylinder moves increasing opening time to the desired width. Adjust the chains (B) so the arms open enough to easily handle the bales width. January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 14 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 14 5/23/2025 7:40:31 AM 5/23/2025 7:40:31 AM...

  • Page 15: Knife Replacement

    The struts will be removed with the knife cartridge. If the blade is cycled while NOTICE the safety pin is in place, irreparable damage will occur. D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 15 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 15 5/23/2025 7:40:35 AM 5/23/2025 7:40:35 AM...
  • Page 16 (C) that connect the knife holder to the cartridge. Slide the knife holder forward then rotate to remove the knife holder from the cartridge frame as shown. January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 16 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 16 5/23/2025 7:40:36 AM 5/23/2025 7:40:36 AM...
  • Page 17 Use locktite on all bolts and tighten them to 75 in- lbs. Assembly is the reverse of the process above. D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 17 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 17 5/23/2025 7:40:37 AM 5/23/2025 7:40:37 AM...

  • Page 18: Hook Replacement

    Disconnect the rod end of the cylinder from the hook cartridge. Remove the six bolts (B) from the inside face of the cartridge then remove the cartridge. January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 18 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 18 5/23/2025 7:40:38 AM 5/23/2025 7:40:38 AM...
  • Page 19 If the bolts to the actuation arm are too tight the mechanism can bind. Assembly is the reverse of the process above. D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 19 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 19 5/23/2025 7:40:39 AM 5/23/2025 7:40:39 AM...

  • Page 20: Spear Installation

    When reinstalling the spears it is recommended to put anti seize on tapered part of spear to prevent it from rusting into the housing. January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 20 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 20 5/23/2025 7:40:39 AM 5/23/2025 7:40:39 AM...

  • Page 21: Maintenance

    Grease pivot cylinder ends (D) every 200 bales. Annual Maintenance Inspect blade for damage/wear. Replace if damaged. Inspect hooks for damage. If bent straighten or replace hook. If broken replace hook. D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 21 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 21 5/23/2025 7:40:40 AM 5/23/2025 7:40:40 AM...

  • Page 22: Setup

    WTR. It is advisable to have these hoses made prior to beginning the system setup. Hillco recommends a 3/8 inch service hose with 90° -8 (1/2”) SAE Oring Face seal fittings on one end and the quick coupler option of your choice on the other end.
  • Page 23 The spear can rest against the ground to help sta- bilize the center assembly. D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 23 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 23 5/23/2025 7:40:41 AM 5/23/2025 7:40:41 AM...
  • Page 24 The hoses should exit under the right side of the manifold cover. (B) January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 24 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 24 5/23/2025 7:40:42 AM 5/23/2025 7:40:42 AM...
  • Page 25 Note: The skidsteer mount is shown, your kit may vary. Step 5: Pick up the center frame and secure it to your loader tractor. D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 25 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 25 5/23/2025 7:40:44 AM 5/23/2025 7:40:44 AM...
  • Page 26 Hooks Arm sit in the machine. They can be switched. If you prefer to switch them contact Hillco for an additional set of safety decals as the decals will be facing the other direction. Instances where operators have...
  • Page 27 Locate the (4) 3/4 x 2.5” bolts (A) and 3/4” stover nuts. Install arm to center frame using the 3/4” bolts and nuts. Torque to 380 ft-lbs D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 27 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 27 5/23/2025 7:40:45 AM 5/23/2025 7:40:45 AM...
  • Page 28 Note that the bolts must be left loose enough to al- low the guides to move freely as the arm extends and retracts. Repeat this process on the opposite side. January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 28 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 28 5/23/2025 7:40:46 AM 5/23/2025 7:40:46 AM...
  • Page 29 Note: You may need to loosen the opposite ends of these hoses to get any twists out. Zip tie the hoses to the guides then tighten all connections near the arm cylinder. D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 29 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 29 5/23/2025 7:40:46 AM 5/23/2025 7:40:46 AM...
  • Page 30 Ram mounts. You will need to provide 12 volts – 5 amps to the orange wire and ground to the black wire. Hillco recommends connecting the switch box to a keyed power source to avoid accidentally draining your tractor’s battery if the switches are left on.
  • Page 31 Be sure to secure the harness with zip ties so it won’t rub or pinch as the loader is used. D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 31 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 31 5/23/2025 7:40:49 AM 5/23/2025 7:40:49 AM...

  • Page 32: Startup

    This will provide access to remove the tape. Cycle the knife and hook 2 – 3 times to purge air from the system. Shut down the tractor engine and inspect the WTR for any oil leaks. Hillco also recommends checking the hydraulic fluid level on tractor.

  • Page 33: Specifications

    111.5” D - Rotation 90° Arm Rotation Upwards Weight 1,000 lbs 1,200 lbs Handling Capacity 3,000 lbs Spears Heat Treated and Forged Spear Adapters 1-1/4” Taper Threaded Style E - Lower Spear Mount Optional (up to 5 addtional spears) Tractor Adapters Euro John Deere 600 Skid Steer Wide Narrow Due to different variations in tractors and skid steers in hydraulic options hoses and couplers are not included. Two mounting options for arms Supply hoses from tractor to WTR are not included. Manifold fittings to widen or narrow squeeze are -8 (1/2”) flat face oring. Hydraulic Couplers not included. D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 33 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 33 5/23/2025 7:40:50 AM 5/23/2025 7:40:50 AM...
  • Page 34 WTR410 FOR 4’ DEEP ROUND BALES AND 4’ LARGE SQUARE BALES 48” 48” 60” - 111.5” 60” - 111.5” WTR510 FOR 5’ DEEP ROUND BALES 60” 60” - 111.5” January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 34 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 34 5/23/2025 7:40:50 AM 5/23/2025 7:40:50 AM...

  • Page 35: Parts Book

    Model WTR410 WTR510 Wrap Twine Remover Parts Manual D-211027DMC01 D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 35 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 35 5/23/2025 7:40:50 AM 5/23/2025 7:40:50 AM...

  • Page 36: Upper Frame

    SHIELD, MANIFOLD 257.006.016 SCREW, PHM, TX, 3/8-16 X 1" 216.006 216.006 188.012 NUT, HX,STV,GR8 3/4-10 1366162 ROTATE BUSHING 1361634 PIVOT CLAMP 269.012.024 SCREW,CAP,FERRY 3/4-10 X 1-1/2 January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 36 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 36 5/23/2025 7:40:51 AM 5/23/2025 7:40:51 AM...

  • Page 37: Lower Frame

    1383191 PAD, WEAR, ROUND 102.012.032 BOLT,HX,GR8 3/4-10X2 188.008 NUT,HX,STV,GR8 1/2 102.008.020 BOLT,HX,GR8 1/2-13X1-1/4 188.012 NUT,HX,STV,GR8 3/4 156048 BALE SPEAR, 49 INCH 1377391 LOWER SPEAR FRAME D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 37 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 37 5/23/2025 7:40:51 AM 5/23/2025 7:40:51 AM...

  • Page 38: Left Clamp Tube

    CHAIN, STRAIGHT LINK, ZINC PLATE GRADE 70, 5/16" 24 LINKS 133.008 WASHER, FLT L9, HD 1/2 102.008.024 BOLT,HX,GR8 1/2-13X1-1/2 1385871 MOUNT,CYLINDER, LEFT 119.008 NUT, HX, FL, SERR 1/2-13 1376743 CLAMP TUBE, LEFT January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 38 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 38 5/23/2025 7:40:51 AM 5/23/2025 7:40:51 AM...

  • Page 39: Right Clamp Tube

    NUT,HX,GR5 1/2-13 10250.05.00024 CHAIN, STRAIGHT LINK, ZINC PLATE GRADE 70, 5/16" 24 LINKS 1385821 CLAMP TUBE, RIGHT 119.008 NUT, HX, FL, SERR 1/2-13 1385891 MOUNT,CYLINDER, RIGHT D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 39 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 39 5/23/2025 7:40:52 AM 5/23/2025 7:40:52 AM...

  • Page 40: Hook Arm

    SCREW, PHM, TX, 3/8-16 X 1" 252.006.040 BOLT,HX,TAP,GR5 3/8-16X2-1/2 187.006 NUT,HX,NYL,GR8 3/8 155993 U-NUT,TINNERMAN,EXTRUDED3/8-16 1382111 COVER, ARM ACCESS 111.006.016 BOLT,HX,FL,GR5 3/8-16X1 1365472 HOOK MOUNT, 410 1376921 HOOK MOUNT, 510 January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 40 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 40 5/23/2025 7:40:52 AM 5/23/2025 7:40:52 AM...

  • Page 41: Hook Cartridge

    NUT,HEX,NYLOCK 1/4-20 COARSE THREAD PLATED 187.004 HOOK,HEAVY DUTY 1382611 BOTTOM CHANNEL, HOOK SUPPORT 510 1382231 SPACER, UNTHREADED ZINC PLATE 1/2" ID X 3/4" OD X 3/8"LONG 156082 D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 41 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 41 5/23/2025 7:40:53 AM 5/23/2025 7:40:53 AM...

  • Page 42: Knife Arm

    NUT,HX,NYL,GR8 1/2-13 187.008 HOLDER, KNIFE 410 1381971 HOLDER, KNIFE 510 1382161 KNIFE CARTRIDGE, 410 1381291 KNIFE CARTRIDGE, 510 1381261 SCREW, PHM, TX, 3/8-16 X 1" 257.006.016 January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 42 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 42 5/23/2025 7:40:53 AM 5/23/2025 7:40:53 AM...

  • Page 43: Knife Cartridge

    Knife Cartridge D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 43 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 43 5/23/2025 7:40:54 AM 5/23/2025 7:40:54 AM...
  • Page 44 NUT,HX,NYL,GR8 1/2-13 156018 SAWBLADE, SCALLOP, SINGLE EDGE DOUBLE BEVEL, 2382161 HOLDER, KNIFE 510 262.016.00056 PIN,HAIR, COTTER 1OD X 3-1/2" 133.016 WASHER, L9 HD FLT 1" January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 44 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 44 5/23/2025 7:40:54 AM 5/23/2025 7:40:54 AM...

  • Page 45: Manifold

    HOSE, GC387STANDARD,-04X12" -4FORS STR X -4FORS STR 1383241 HOSE, GC387STANDARD,-06X63-1/2 -6FORS STR X -6FORS 90° 1383221 HOSE, GC387 STANDARD,-04X63" -6FORS STR X -6FORS 90° 1383251 D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 45 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 45 5/23/2025 7:40:54 AM 5/23/2025 7:40:54 AM...

  • Page 46: Hydraulic Junction

    TEE STR, THD, RUN -8ORFS 1007.08 NUT, HX, FL, SERR 5/16-18 119.005 CLAMP, COVER PLATE 139231 CLAMP,TWIN, .500 DIAMETER 155531 BOLT, CARR, GR5 5/16-18 X 2" 107.005.032 January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 46 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 46 5/23/2025 7:40:55 AM 5/23/2025 7:40:55 AM...

  • Page 47: Cylinders

    142.003.056 PIN, COTTER, 3/16 X 3-1/2 WASHER, L9 HD FLT 1" 133.016 PIN, CYLINDER, 1OD X 2-15/16 L 156261 262.016.00056 PIN,HAIR, COTTER 1OD X 3-1/2" D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 47 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 47 5/23/2025 7:40:55 AM 5/23/2025 7:40:55 AM...
  • Page 48 HOOK CYLINDER BASE 1379431 UPPER TEE LEFT BRANCH HOOK CYLINDER ROD 1383211 MANIFOLD 3A CLAMP CYLINDER BASE TEE 1383221 MANIFOLD 3B CLAMP CYLINDER ROD TEE January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 48 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 48 5/23/2025 7:40:55 AM 5/23/2025 7:40:55 AM...

  • Page 49: Decals

    DECAL, LOAD LIMIT DECAL, OPERATORS MANUAL 156089 WTR SWITCH BOX DECAL 156047 156208 DECAL, HILLCO WTR 156209 DECAL, HILLCO WTR 1562010 DECAL, MADE IN AMERICA D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 49 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 49 5/23/2025 7:40:55 AM 5/23/2025 7:40:55 AM...

  • Page 50: Electrical

    SWITCH ACTUATOR, BLACK W/ RED LENS 156002 RAM HANDLEBAR U-BOLT BASE,1/2" TO 1-1/4" DIA 156084 RAM COMPOSITE DOUBLE SOCKET SWIVEL ARM 156085 CIRCUIT BREAKER-TYPE 1, 12VDC, 8AMP EC-145021 January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 50 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 50 5/23/2025 7:40:55 AM 5/23/2025 7:40:55 AM...

  • Page 51: Hydraulic & Electrical Schematics

    Hydraulic Schematic TO TRACTOR TO TRACTOR .062 ORIFICE ROTATE CYLINER KNIFE CYLINDER HOOK CYLINDER SQUEEZE CYLINDERS D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 51 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 51 5/23/2025 7:40:57 AM 5/23/2025 7:40:57 AM...
  • Page 52 In the picture above, if the green hoses are pressurized, the reaction will be to retract the arms, squeezing the bale. If the purple hoses are pressurized, the reaction will be to extend the arms, releasing the bale. January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 52 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 52 5/23/2025 7:40:57 AM 5/23/2025 7:40:57 AM...
  • Page 53 In the picture above, if the green hoses are pressurized, the arms will rotate up. If the purple hoses are pressurized, the arms will rotate down. D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 53 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 53 5/23/2025 7:40:57 AM 5/23/2025 7:40:57 AM...

  • Page 54: Direction Of Travel

    If the cover edge hook is present, it will retract at this time. January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 54 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 54 5/23/2025 7:40:58 AM 5/23/2025 7:40:58 AM...

  • Page 55: Electrical Schematic

    Note: Geen wire - Squeeze White Wire - Cut/Grab Red - Rotate Green White Orange A B C D Power Orange Black Ground Harness 1366311 D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 55 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 55 5/23/2025 7:40:58 AM 5/23/2025 7:40:58 AM...

  • Page 56: Troubleshooting

    Knife misses outermost string on square Twine is pulled tighter into bale than typical Increase squeeze force bales Install shim washers between outermost knife cartridge bolts and knife arm frame January, 2025 D-211027DMC01B D-250113DMC01A WTR410&WTR510(Ver1.5).indd 56 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 56 5/23/2025 7:40:58 AM 5/23/2025 7:40:58 AM...
  • Page 57 Notes: D-211027DMC01B January, 2025 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 57 D-250113DMC01A WTR410&WTR510(Ver1.5).indd 57 5/23/2025 7:40:58 AM 5/23/2025 7:40:58 AM...
