Termix VVX-IV - 7 Series DS Fully insulated
Expansion tank
Heat Exchanger
The heat exchanger is produced in acid-resistant, stainless steel
Double check valve
Fill/drain valve
Air vent, manual secondary side
Air vent, manual
Primary side.
