Termix VVX-IV - 7 Series DS Fully insulated

Functional specification

The HIU is intended for connecting to a heat network for the production of
both domestic hot water and space heating.
The unit must be connected to the household installation in a frost-free
location.
Technical specifications
Specifications:
Max. working pressure:
Max. temperature:
Power connection: 230 V AC
Sound level: ≤ 55 dB
Ambient temp: 0 - 40°C
(in continuous use)
Dimensions for connections:
DHF + DHR + HFL + HRL + DCW + DHW:
Weight:
Net weight: 24 - 29 kg
Dimensions:
Dimensions: H 710 mm x W 530 mm x D 270 mm
The recommended operational parameters must not be exceeded.

Personal protective equipment

Gloves
It is recommended that suitable work
gloves are used in connection with
handling and lifting of the HIU.

Warning of dangerous situations that can arise with reasonably foreseeable misuse

The risk of personal injury or product damage increases considerably if the
recommended operational parameters are exceeded.
The unit must always be equipped with safety valves in accordance with
local regulations.
6 | © Danfoss | 2022.02
See the unit label on the HIU
See the unit label on the HIU
G ¾" (internal thread)
LGB55001
